D
USB Insulator
(Portion 2)
USB Insulator
(Portion 1)
USB Metal Shell
(Portion 2)
Cable Fitting
(Plastic or Metal)
USB Type A
Plug Housing
(Plastic or Metallized)
17.9
Coupling Ring
Bayonet Locking Type
(Plastic or Metallized)
D
d
USB Metal Shell
(Portion 1)
C
n
31.5
21
C
e
Interfacial Seal
Notes:
B
1. Electrical Specifications:
- Meets USB 2.0 Specification
- Contact Resistance: 30 mOhm max.
- Insulation Resistance: 1000 MOhm min. @ 100 VDC
- Current Rating: 1.5 A max. at 25
~
C
- Working Voltage: 30 V (RMS) max.
- DWV: 500 VAC/60s at sea Level
- Operating Temperature: -40
~
C to +85
~
C
2. Material and Finish:
- Coupling Ring and Plug Housing: Polyester (Black), UL94 V-0
or Metallized ABS (Nickel Plated), UL94 V-0
- Interfacial Seal: Silicon, Color: White
- Cable Fitting: PA (Black), UL94 V-0
- Cable Fitting Rubber Ring: NBR, Color: Black
- USB Metal Shell: SPCC, Nickel Plated
- USB Insulator: PBT, UL94 V-0, White
- USB Contacts: Copper Alloy,
- USB Contact Finish: 30 u" Gold min. over Nickel for mating area, Tin over Nickel for solder cup
3. USB Type A Plug accepts AWG28 to AWG24 wires, Cable OD of 4.0 mm to 5.5 mm
4. IP67 rated when fully mated with the appropriate mating connector
c
e
61.8 REF.
HEX 19
B
Version
Plastic Version
Metallized Plastic Version
Part Number
17-200121
17-200131
THIS DRAWING MAY NOT BE COPIED OR REPRODUCED
IN ANY WAY, AND MAY NOT BE PASSED ON TO A THIRD
PARTY WITHOUT WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC CORPORATION
DOT NOT ALTER CAD DRAWING BY HAND
Customer:
Approval Date
Unless otherwise specified
Tolerance
Name
Title
0 PLC
1 PLC
2 PLC
3 PLC
ANGLES
`
0.50
`
0.38
`
0.25
`
0.10
`
3
~
Scale: 1.5:1
Autodesk
Inventor
Name
Vincent Ke
J. Chaudry
Dim. in mm
Material: See Notes
Title:
2008
Date
Sept. 09
Sept. 09
A
f
f
e
d
c
b
a
Rev.
RoHS Compliant
4
1xf
2xe
1xd
1xc
1xb
original
Changes
Apr/21/2017 Vincent
Jun/23/2014 Vincent
Jan/06/2012 Vincent
Mar/18/2010 Vincent
Jun/01/2009 Vincent
Date
Name
Ke
Ke
ke
ke
ke
Draw.
Appd.
Norm
D-old
IP67 USB
USB 2.0 Type A Plug Assembly Kit
Solder Cup Version
A
DIN
R
Drawing No.: 39K1A364
Part No.: SEE PART NUMBER TABLE
A3
Sheet
1/1
