DUAL-IN-LINE
SOCKETS
SERIES 104 • SOLDERLESS PRESS
-
FIT • OPEN FRAME
.018-.025
.010 .018
B
•
Designed for solderless press- t into plated
through-holes
•
Pin lengths are suitable for .062” and .093”-
.110
.175
.150
.102
.125” thick panels
•
Required plated through hole is .036”-.041”.
Use a 1.1mm drill prior to plating
L=.175
OR
L=.250
.026
.072
.044 DIA.
•
Series 104 uses MM #0477 or MM #0478 pins
with a BeCu #30 contact, rated at 3 amps.
See page 162 for details
See page 130 for Insulator Details
•
Insulators are high temperature thermoplastic
•
For Electrical, Mechanical and Environmental
Data, see page 264 for details
Total number
of pins
A
B
.100
C
Quantity
per tube
ORDERING INFORMATION
(for .062” thick panel)
104-XX-210-41-770000
104-XX-304-41-770000
104-XX-306-41-770000
104-XX-308-41-770000
104-XX-310-41-770000
104-XX-314-41-770000
104-XX-316-41-770000
104-XX-318-41-770000
104-XX-320-41-770000
104-XX-322-41-770000
104-XX-324-41-770000
104-XX-328-41-770000
104-XX-420-41-770000
104-XX-422-41-770000
104-XX-424-41-770000
104-XX-428-41-770000
104-XX-432-41-770000
104-XX-624-41-770000
104-XX-628-41-770000
104-XX-632-41-770000
104-XX-636-41-770000
104-XX-640-41-770000
104-XX-642-41-770000
104-XX-648-41-770000
104-XX-650-41-770000
104-XX-652-41-770000
104-XX-950-41-770000
104-XX-952-41-770000
104-XX-964-41-770000
11
10
µ”
Au
10
µ”
Au
A
0.5
0.2
0.3
0.4
0.5
0.7
0.8
0.9
1.0
1.1
1.2
1.4
1.0
1.1
1.2
1.4
1.6
1.2
1.4
1.6
1.8
2.0
2.1
2.4
2.5
2.6
2.5
2.6
3.2
B
0.2
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.4
0.4
0.4
0.4
0.4
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.9
0.9
0.9
C
0.3
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.5
0.5
0.5
0.5
0.5
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
1.0
1.0
1.0
L = .175
(for .125” thick panel)
104-XX-210-41-780000
104-XX-304-41-780000
104-XX-306-41-780000
104-XX-308-41-780000
104-XX-310-41-780000
104-XX-314-41-780000
104-XX-316-41-780000
104-XX-318-41-780000
104-XX-320-41-780000
104-XX-322-41-780000
104-XX-324-41-780000
104-XX-328-41-780000
104-XX-420-41-780000
104-XX-422-41-780000
104-XX-424-41-780000
104-XX-428-41-780000
104-XX-432-41-780000
104-XX-624-41-780000
104-XX-628-41-780000
104-XX-632-41-780000
104-XX-636-41-780000
104-XX-640-41-780000
104-XX-642-41-780000
104-XX-648-41-780000
104-XX-650-41-780000
104-XX-652-41-780000
104-XX-950-41-780000
104-XX-952-41-780000
104-XX-964-41-780000
L = .250
10
4
6
8
10
14
16
18
20
22
24
28
20
22
24
28
32
40
102
67
50
40
28
25
22
20
18
16
14
20
18
16
14
12
16
14
12
11
10
9
8
8
7
8
7
6
PAGE 96 | IC SOCKETS / TO SOCKETS
24
28
32
36
40
42
48
50
52
50
52
64
2011/65/EU
RoHS - 2
XX=Plating Code
See Below
SPECIFY PLATING CODE XX =
Sleeve (Pin)
Contact (Clip)
13
10
µ”
Au
30
µ”
Au
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
