2SC5777

Description
Power Bipolar Transistor, 10A I(C), 800V V(BR)CEO, 1-Element, NPN, Silicon, Plastic/Epoxy, 3 Pin, TO-3PMLH, 3 PIN
CategoryDiscrete semiconductor    The transistor
File Size33KB,4 Pages
ManufacturerSANYO
Websitehttp://www.semic.sanyo.co.jp/english/index-e.html
Download Datasheet Parametric View All

2SC5777 Overview

Power Bipolar Transistor, 10A I(C), 800V V(BR)CEO, 1-Element, NPN, Silicon, Plastic/Epoxy, 3 Pin, TO-3PMLH, 3 PIN

2SC5777 Parametric

Parameter NameAttribute value
Objectid1914130485
Parts packaging codeTO-3PMLH
package instructionFLANGE MOUNT, R-PSFM-T3
Contacts3
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresHIGH RELIABILITY
Maximum collector current (IC)10 A
Collector-emitter maximum voltage800 V
ConfigurationSINGLE WITH BUILT-IN DIODE AND RESISTOR
Minimum DC current gain (hFE)4
JESD-30 codeR-PSFM-T3
Number of components1
Number of terminals3
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Polarity/channel typeNPN
Maximum power dissipation(Abs)80 W
Certification statusNot Qualified
surface mountNO
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
transistor applicationsAMPLIFIER
Transistor component materialsSILICON

2SC5777 Preview

Ordering number : ENN6991A
2SC5777
NPN Triple Diffused Planar Silicon Transistor
2SC5777
Ultrahigh-Definition CRT Display
Horizontal Deflection Output Applications
Features
Package Dimensions
unit : mm
2174A
[2SC5777]
16.0
5.0
3.4
5.6
3.1
8.0
22.0
High speed.
High breakdown voltage (VCBO=1600V).
High reliability (Adoption of HVP process).
Adoption of MBIT process.
On-chip damper diode.
21.0
4.0
2.8
2.0
20.4
0.7
1
2
5.45
3
3.5
0.9
1 : Base
2 : Collector
3 : Emitter
SANYO : TO-3PMLH
Specifications
Absolute Maximum Ratings
at Ta=25°C
Parameter
Collector-to-Base Voltage
Collector-to-Emitter Voltage
Emitter-to-Base Voltage
Collector Current
Collector Current (Pulse)
Collector Dissipation
Junction Temperature
Storage Temperature
Symbol
VCBO
VCEO
VEBO
IC
ICP
PC
Tj
Tstg
Tc=25°C
5.45
Conditions
0.8
2.1
Ratings
1600
800
5
10
25
3.0
80
150
--55 to +150
Unit
V
V
V
A
A
W
W
°C
°C
Electrical Characteristics
at Ta=25°C
Parameter
Collector Cutoff Current
Emitter Cutoff Current
Symbol
ICBO
ICES
IEBO
Conditions
VCB=800V, IE=0
VCE=1600V, RBE=0
VEB=4V, IC=0
40
Ratings
min
typ
max
10
1.0
200
Unit
µA
mA
mA
Continued on next page.
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft's
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
52003 TS IM TA-100442 / 62001 TS IM TA-3323 No.6991-1/4
2SC5777
Continued from preceding page.
Parameter
DC Current Gain
Collector-to-Emitter Saturation Voltage
Base-to-Emitter Saturation Voltage
Storage Time
Fall Time
Diode Forward Voltage
Symbol
hFE1
hFE2
VCE(sat)
VBE(sat)
tstg
tf
VF
VCE=5V, IC=1A
VCE=5V, IC=7A
IC=6.3A, IB=1.6A
IC=6.3A, IB=1.6A
IC=5A, IB1=0.8A, IB2=--2.5A
IC=5A, IB1=0.8A, IB2=--2.5A
IEC=8A
Conditions
Ratings
min
8
4
7
3.0
1.5
3.0
0.2
2.2
V
V
µs
µs
V
typ
max
Unit
Switching Time Test Circuit
IB1
OUTPUT
IB2
RB
+
470µF
VCC=200V
PW=20µs
D.C.≤1%
INPUT
VR
50Ω
RL=40Ω
+
100µF
VBE= --5V
10
9
IC -- VCE
2.0A
1.8A
1.6A
1.4A
1.2A
1.0A
0.8A
10
9
8
7
6
5
IC -- VBE
VCE=5V
Collector Current, IC -- A
7
6
5
4
3
2
1
0
0
1
2
3
4
5
6
7
0.6A
0.4A
0.2A
0.1A
Collector Current, IC -- A
8
20
°
Ta=
1
0.2
0.4
0.6
4
3
2
1
C
25
°
C
0.8
IB=0
8
9
10
0
0
1.0
1.2
IT03534
Collector-to-Emitter Voltage, VCE -- V
100
7
5
IT03533
10
7
5
hFE -- IC
Base-to-Emitter Voltage, VBE -- V
VCE(sat) -- IC
Collector-to-Emitter
Saturation Voltage, VCE(sat) -- V
DC Current Gain, hFE
3
2
2
1.0
7
5
3
2
0.1
7
5
3
2
10
7
5
3
2
C
20
°
a=1
T
C
25
°
°
C
--40
25
°
C
Ta
=
--4
0
°
C
120°C
1.0
0.1
2
3
5
7
1.0
2
3
5
Collector Current, IC -- A
10
IT03535
7
0.01
0.1
2
3
5
7
1.0
2
3
5
Collector Current, IC -- A
7
10
IT03536
No.6991-2/4
--40
°
C
25
°
C
3
Ta=1
2
0
°
C
VCE=5V
IC / IB=5
--40
°
C
2SC5777
10
7
SW Time -- IC
Switching Time, SW Time --
µs
VCC=200V
IC / IB1=6
IB2 / IB1=3
R load
10
7
5
3
2
SW Time -- IB2
VCC=200V
IC=5A
IB1=0.8A
R load
Switching Time, SW Time --
µs
5
3
2
tstg
tst
g
1.0
7
5
3
2
1.0
7
5
3
2
tf
tf
0.1
3
5
7
1.0
2
3
5
0.1
Collector Current, IC -- A
100
7
5
3
2
10
IT03537
100
7
5
3
7
3
5
7
1.0
2
3
5
7
Base Current, IB2 -- A
IT03538
Forward Bias A S O
ICP=25A
Reverse Bias A S O
L=500µH
IB2= --3A
Tc=25°C
Single pulse
10
Collector Current, IC -- A
Collector Current, IC -- A
10
7
5
3
2
1.0
7
5
3
2
0.1
7
5
3
2
IC=10A
P
C =8
2
10
7
5
3
2
1.0
7
5
3
2
s
0
µ
30
0W
10
ms
s
0
µ
1m
s
D
C
op
at
er
io
n
0.01
1.0
Tc=25°C
Single pulse
2
3
5 7 10
2
3
5 7 100
2
3
Collector-to-Emitter Voltage, VCE -- V
3.5
5 7 1000
IT03539
0.1
100
2
3
5
7
1000
2
IT03540
PC -- Ta
Collector-to-Emitter Voltage, VCE -- V
90
80
PC -- Tc
3.0
Collector Dissipation, PC -- W
Collector Dissipation, PC -- W
70
60
50
40
30
20
10
0
2.5
2.0
No
he
at
sin
k
1.5
1.0
0.5
0
0
20
40
60
80
100
120
140
160
0
20
40
60
80
100
120
140
160
Ambient Temperature, Ta --
°C
IT03541
Case Temperature, Tc --
°C
IT03542
No.6991-3/4
2SC5777
Specifications of any and all SANYO products described or contained herein stipulate the performance,
characteristics, and functions of the described products in the independent state, and are not guarantees
of the performance, characteristics, and functions of the described products as mounted in the customer's
products or equipment. To verify symptoms and states that cannot be evaluated in an independent device,
the customer should always evaluate and test devices mounted in the customer's products or equipment.
SANYO Electric Co., Ltd. strives to supply high-quality high-reliability products. However, any and all
semiconductor products fail with some probability. It is possible that these probabilistic failures could
give rise to accidents or events that could endanger human lives, that could give rise to smoke or fire,
or that could cause damage to other property. When designing equipment, adopt safety measures so
that these kinds of accidents or events cannot occur. Such measures include but are not limited to protective
circuits and error prevention circuits for safe design, redundant design, and structural design.
In the event that any or all SANYO products(including technical data,services) described or
contained herein are controlled under any of applicable local export control laws and regulations,
such products must not be expor ted without obtaining the expor t license from the authorities
concerned in accordance with the above law.
No part of this publication may be reproduced or transmitted in any form or by any means, electronic or
mechanical, including photocopying and recording, or any information storage or retrieval system,
or otherwise, without the prior written permission of SANYO Electric Co., Ltd.
Any and all information described or contained herein are subject to change without notice due to
product/technology improvement, etc. When designing equipment, refer to the "Delivery Specification"
for the SANYO product that you intend to use.
Information (including circuit diagrams and circuit parameters) herein is for example only ; it is not
guaranteed for volume production. SANYO believes information herein is accurate and reliable, but
no guarantees are made or implied regarding its use or any infringements of intellectual property rights
or other rights of third parties.
This catalog provides information as of May, 2003. Specifications and information herein are subject
to change without notice.
PS No.6991-4/4
