Type 5HF / 5HFP
5HFD0106
W5HFD0405-A2
5 x 20mm Ceramic Tube
RoHS Compliant
Quick-acting Fuse Series (High-Breaking Capacity)
Catalog
Number
RoHS
Suffix
Ampere
Rating
Typical
Volt-drop Melting I
2
T Melting I
2
T Maximum
Cold
@100%
In
< 10 mSec @10
In
Power
Resistance
Dissipation
(ohm) (Volt) max. (A
2
Sec)
(A
2
Sec)
(W)
5HF (P) 100
5HF (P) 125
5HF (P) 160
5HF (P) 200
5HF (P) 250
5HF (P) 315
5HF (P) 400
5HF (P) 500
5HF (P) 630
5HF (P) 800
5HF (P) 1
5HF (P) 1.25
5HF (P) 1.6
5HF (P) 2
5HF (P) 2.5
5HF (P) 3.15
5HF (P) 4
100mA - 10A / 250V AC @ 1,500A
-R
-R
-R
-R
-R
-R
-R
-R
-R
-R
-R
-R
-R
-R
-R
-R
-R
-R
-R
-R
-R
-R
100mA
125mA
160mA
200mA
250mA
315mA
400mA
500mA
630mA
800mA
1A
1.25A
1.6A
2A
2.5A
3.15A
4A
5A
6.3A
8A
10A
12A
3.85
2.78
2.01
1.45
1.05
0.757
0.547
0.395
0.286
0.206
0.150
0.110
0.080
0.058
0.043
0.031
0.023
0.016
0.012
0.009
0.006
0.005
0.56
0.54
0.52
0.50
0.48
0.46
0.44
0.43
0.41
0.20
0.18
0.17
0.16
0.15
0.14
0.14
0.13
0.12
0.11
0.11
0.10
0.094
0.003
0.005
0.009
0.016
0.028
0.051
0.091
0.16
0.29
0.36
0.65
1.17
2.10
3.77
6.78
12
22
39
70
126
227
408
0.002
0.004
0.008
0.014
0.026
0.046
0.084
0.15
0.27
0.35
0.63
1.15
2.07
3.75
6.78
12
22
40
73
131
238
430
0.30
0.36
0.43
0.52
0.63
0.76
0.92
1.11
1.35
0.58
0.69
0.81
0.96
1.1
1.3
1.6
1.9
2.2
2.7
3.1
3.7
4.4
Electrical Characteristics
( IEC-127-2 STANDARD SHEET 1)
Rated Current
1.5
In
2.1
In
MIN
MAX
2.75
In
MIN
MAX
4
In
MIN
MAX
10
In
MAX
100mA to 3.15A
4A to 6.3A
8A to 12A
1
1
1
hr.
30
30
30
min.
10
10
40
ms
2
3
20
sec
3
3
10
ms
300
300
1
ms
20
20
30
ms
pc
c
Approvals
sd
m
r
S
Safety Agency Approvals
Amp range / Volt @ I.R.ability
1A - 6.3A / 250V AC @ 1,500A
8A - 12A / 250V AC @ 1,500A
s
d
m
r
Certificate No. 408891
Certificate No. 401359
Licence No. 40000506
1A - 6.3A / 250V AC @ 1,500A
Certificate No. EM233
Recognized File No. E20624
5HF (P) 5
5HF (P) 6.3
5HF (P) 8
5HF (P) 10
5HF (P) 12
S
Acceptance File No. LR39772
o. 103 310
p
FEilTe1N37-J3E1T003-71-00503-1004,
J 0
1A - 5A / 250V AC @ 1,500A
100mA - 10A / 250V AC @ 1,500A
c
Licence No. 2002010207021529
Consult manufacturer for other ratings
RoHS Compliant Product
For RoHS Compliant Version, add suffix “R” after catalog number
Operating Temperature
-55ºC to +125ºC
Physical Specification
Materials
Ceramic body / Nickel Plated Brass Caps
Lead wire:
Tin plated copper alloy,
Diameter 0.032”, 6.3A and less
Diameter 0.040", 8A and above
Marking
On fuse:
“bel”, “F”, “Current Rating”, “H”, “250V”,
“Approporiate Safety Logos”, “✔” (RoHS Version)
On label:
“bel”, “5HF” or “5HFP”, “Current Rating”,
“Voltage Rating”, “Interrupting Rating”, “Approporiate
Safety Logos” and
+ suffix “R” for RoHS Version
Packaging
1. In bulk:
5HF
- 1,000 pcs per box;
5HFP
- 500 pcs per box
2. On Axial Tape & Reel:
1,500 pcs per reel
3. Tape & Reel specification:
per EIA-296-E & IEC 286-1@ 10mm Pitch and 63.5mm inside Tape Spacing
Mechanical Dimensions
0.787"
±
0.02"
(20
±
0.5mm)
0.20"
±
0.004"
(5.1
±
0.1mm)
5HF
5HFP
1.5"
±
0.08"
(38.1
±
2mm)
0.827"
±
0.02"
(21.0
±
0.5mm)
0.217"
±
0.004"
(5.5
±
0.1mm)
SEE LEAD SIZE LISTED IN “ MATERIAL”
ORDERING INFORMATION SEE LAST 2 PAGES
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 • Tel: 201-432-0463 • Fax: 201-432-9542 • E-Mail: belfuse@belfuse.com
Website: www.belfuse.com
45
Specifications subject to change without notice
Type 5HF / 5HFP
5 x 20mm Ceramic Tube
RoHS Compliant
W5HFC0405-A2
Quick-acting Fuse Series (High-Breaking Capacity)
5HFC0405
5HF / 5HFP - TIME CURRENT CHARACTERISTIC CURVE
-
100mA
-
125mA
-
160mA
-
200mA
-
250mA
-
315mA
-
400mA
-
500mA
-
630mA
-
800mA
-
1A
-
1.25A
-
1.6A
-
2A
-
2.5A
-
3.15A
-
4A
-
5A
-
6.3 A
-
8A
-
10 A
-
12A
10000
1000
100
TIME IN SECONDS
10
1
0.1
0.01
0.01
0.1
1
10
100
1000
CURRENT IN AMPERES
NOTE - see important information under “User Guide”on P.08
Corporate Office
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302
Tel: 201-432-0463
Fax: 201-432-9542
E-Mail: belfuse@belfuse.com
Website: www.belfuse.com
Far East Office
Bel Fuse Ltd.
8F/8 Luk Hop Street
San Po Kong
Kowloon, Hong Kong
Tel: 852-2328-5515
Fax: 852-2352-3706
European Office
Bel Fuse Europe Ltd.
Preston Technology Management Centre
Marsh Lane, Preston PR1 8UD
Lancashire, U.K
Tel: 44-1772-556601
Fax: 44-1772-888366
Specifications subject to change without notice
46
