NC7SB3157, FSA3157 — Low-Voltage SPDT Analog Switch or 2:1 Multiplexer / De-multiplexer Bus Switch
March 2009
NC7SB3157, FSA3157
Low-Voltage SPDT Analog Switch or 2:1Multiplexer /
De-multiplexer Bus Switch
Features
■
Useful in Both Analog and Digital Applications
■
Space-Saving, SC70 6-Lead Surface Mount Package
■
Ultra-Small, MicroPak™ Leadless Package
■
Low On Resistance: <10Ω on Typical at 3.3V V
CC
■
Broad V
CC
Operating Range: 1.65V to 5.5V
■
Rail-to-Rail Signal Handling
■
Power-Down, High-Impedance Control Input
■
Over-Voltage Tolerance of Control Input to 7.0V
■
Break-Before-Make Enable Circuitry
■
250MHz, 3dB Bandwidth
Description
The NC7SB3157 / FSA3157 is a high-performance, sin-
gle-pole / double-throw (SPDT) analog switch or 2:1 mul-
tiplexer / de-multiplexer bus switch.
The device is fabricated with advanced sub-micron
CMOS technology to achieve high-speed enable and
disable times and low on resistance. The break-before-
make select circuitry prevents disruption of signals on
the B Port due to both switches temporarily being
enabled during select pin switching. The device is speci-
fied to operate over the 1.65 to 5.5V V
CC
operating
range. The control input tolerates voltages up to 5.5V,
independent of the V
CC
operating range.
Ordering Information
Part Number
NC7SB3157P6X
NC7SB3157L6X
FSA3157P6X
FSA3157L6X
Top
Mark
B7A
BB
B7A
BB
Eco Status
RoHS
RoHS
RoHS
RoHS
Package Description
6-Lead, SC70, EIAJ SC88, 1.25mm Wide Package
6-Lead, MicroPak 1.0mm Wide Package
6-Lead, SC70, EIAJ SC88, 1.25mm Wide Package
6-Lead, MicroPak 1.0mm Wide Package
Packing
Method
3000 Units on
Tape and Reel
5000 Units on
Tape and Reel
3000 Units on
Tape and Reel
5000 Units on
Tape and Reel
