BAR64V-05W
www.vishay.com
Vishay Semiconductors
RF PIN Diodes - Dual, Common Cathode in SOT-323
FEATURES
• High voltage current controlled RF resistor
• Small diode capacitance
3
• Low series inductance
• Low forward resistance
• Improved performance due to two separate dice
• Base P/N-E3 - RoHS-compliant, commercial grade
1
2
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
APPLICATIONS
• For frequencies up to 3 GHz
DESIGN SUPPORT TOOLS
click logo to get started
Models
Available
• RF-signal tuning
• Signal attenuator and switches
• Mobile, wireless, and TV-applications
DESCRIPTION
Characterized by low reverse capacitance the PIN diodes
BAR64V-05W was designed for RF signal switching and
tuning. As a function of the forward bias current the forward
resistance (RF) can be adjusted over a wide range. A long
carrier life time offers low signal distortion for signals over
10 MHz up to 3 GHz. Typical applications for these PIN
diodes are switches and attenuators in wireless, mobile, and
TV-systems.
MECHANICAL DATA
Case:
SOT-323
Weight:
approx. 5.7 mg
Packaging codes/options:
18/10K per 13" reel (8 mm tape), 10K/box
08/3K per 7" reel (8 mm tape), 15K/box
PARTS TABLE
PART
BAR64V-05W
ORDERING CODE
BAR64V-05W-E3-08 or BAR64V-05W-E3-18
TYPE MARKING
DW5
CIRCUIT CONFIGURATION
Common cathode
REMARKS
Tape and reel
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PART
Reverse voltage
Forward continuous current
TEST CONDITION
SYMBOL
V
R
I
F
VALUE
100
100
UNIT
V
mA
THERMAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Junction temperature
Storage temperature range
Operating temperature range
TEST CONDITION
SYMBOL
T
j
T
stg
T
op
VALUE
150
-55 to +150
-55 to +125
UNIT
°C
°C
°C
Rev. 1.6, 27-Apr-17
Document Number: 81836
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAR64V-05W
www.vishay.com
Vishay Semiconductors
TEST CONDITION
I
F
= 50 mA
I
F
= 10 μA
V
R
= 50 V
f = 1 MHz, V
R
= 0 V
f = 1 MHz, V
R
= 1 V
f = 1 MHz, V
R
= 20 V
PART
SYMBOL
V
F
V
R
I
R
C
D
C
D
C
D
r
f
r
f
r
f
t
rr
L
S
0.5
0.37
0.23
10
2
0.8
1.8
1
0.5
0.35
20
3.8
1.35
100
0.05
MIN.
TYP.
MAX.
1.1
UNIT
V
V
μA
pF
pF
pF
μs
nH
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Forward voltage
Reverse voltage
Reverse current
Diode capacitance
f = 100 MHz, I
F
= 1 mA
Differential forward resistance
Charge carrier lifetime
Series inductance
f = 100 MHz, I
F
= 10 mA
f = 100 MHz, I
F
= 100 mA
I
F
= 10 mA, I
R
= 6 mA, i
R
= 3 mA
TYPICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
100.00
100.0
r
f
- Forward Resistance (Ω)
f = 100 MHz
10.0
I
F
- Forward Current (mA)
100
10.00
1.00
1.0
0.10
0.1
0.1
18342
1
10
0.01
0.5
18326
0.6
0.7
0.8
0.9
1.0
I
F
- Forward Current (mA)
V
F
- Forward
Voltage
(V)
Fig. 1 -
Forward Resistance vs. Forward Current
Fig. 3 -
Forward Current vs. Forward Voltage
0.50
0.45
f = 1 MHz
12
10
I
F
= 10 mA
I
R
= 6 mA
i
R
=
3 mA
C
D
- Diode Capacitance (pF)
I
F
- Forward Current (mA)
0
4
8
12
16
20
24
28
18338
0.40
0.35
0.30
0.25
0.20
0.15
0.10
0.05
0.00
8
6
4
2
0
-2
-4
-6
-8
- 500
500
1500
2500
3500
18334
V
R
- Reverse
Voltage
(V)
t
rr
- Reverse Recovery Time (ns)
Fig. 2 -
Diode Capacitance vs. Reverse Voltage
Fig. 4 -
Typical Charge Recovery Curve
Rev. 1.6, 27-Apr-17
Document Number: 81836
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAR64V-05W
www.vishay.com
Vishay Semiconductors
0
- 0.5
-1
- 1.5
I
F
= 0.5 mA
-2
- 2.5
-3
0
21027
|S
21
|² - Insertion Loss (dB)
I
F
= 3mA
I
F
= 1 mA
I
F
= 10 mA
I
F
= 100 mA
0.5
1
1.5
2
2.5
3
3.5
f - Frequency (GHz)
Fig. 5 -
Insertion Loss of One Diode Inserted in Series
with 50
Strip Line
0
|S
21
|² = |S
12
|² - Isolation (dB)
-5
- 10
- 15
V
R
= 0, diode zero-biased
- 20
- 25
0
21028
0.5
1
1.5
2
2.5
3
3.5
f - Frequency ( GHz )
Fig. 6 -
Isolation of One Diode Inserted in Series
with 50
Strip Line
I
P2
- Second Order Intercept Point (dBm)
150
100
f = 1.8 GHz
f = 0.9 GHz
50
0
0.1
1
10
21029
I
F
- Forward Current (mA)
Fig. 7 -
Second Order Intercept Point for One Diode Inserted
in 50
Strip Line
Rev. 1.6, 27-Apr-17
Document Number: 81836
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAR64V-05W
www.vishay.com
PACKAGE DIMENSIONS
in millimeters (inches):
SOT-323
1.0 (0.039)
0.8 (0.031)
1.1 (0.043)
0.8 (0.031)
Vishay Semiconductors
2.2 (0.087)
2.0 (0.079)
0.15 (0.006)
0.08 (0.003)
0.1 (0.004)
0.0 (0.000)
8°
0.46 (0.018)
0.26 (0.010)
0.525 (0.021) ref.
0.4 (0.016)
0.2 (0.008)
2.45 (0.096)
2.15 (0.085)
1.35 (0.053)
1.15 (0.045)
foot print recommendation:
0.6 (0.024)
0.65 (0.026) typ
1.4 (0.055)
1.2 (0.047)
0.8 (0.031)
Document no.: 6.541-5040.02-4
Rev. 1 - Date: 06. April 2010
21113
0.65 (0.026)
1.3 (0.051)
Rev. 1.6, 27-Apr-17
Document Number: 81836
4
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
1.8 (0.071)
0°
