RCWE0612R953FKEA

Description
Current Sense Resistors - SMD 1watt .953ohms 1% 100ppm
CategoryPassive components
File Size101KB,4 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric View All

RCWE0612R953FKEA Online Shopping

Suppliers Part Number Price MOQ In stock
RCWE0612R953FKEA - - View Buy Now

RCWE0612R953FKEA Overview

Current Sense Resistors - SMD 1watt .953ohms 1% 100ppm

RCWE0612R953FKEA Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerVishay
Product CategoryCurrent Sense Resistors - SMD
RoHSDetails
TechnologyThick Film
Termination2 Terminal
PackagingReel
Height0.6 mm
Length1.6 mm
Package / Case0612 (1632 metric) Reversed
Termination StyleSMD/SMT
Width3.2 mm
NumOfPackaging1
Factory Pack Quantity5000
RCWE
www.vishay.com
Vishay Dale
Thick Film Surface Mount Chip Resistors,
Wraparound, Extremely Low Value (0.01
to 0.976
)
FEATURES
• Extremely low resistance values
(0.01
to 0.976
)
• Sulfur resistant (per ASTM B809-95 humid vapor
test)
• Enhanced power rating due to long side terminal
construction (0612, 1020 types)
• Suitable for current sensing and shunts
• Metal glaze on high quality ceramic
• Protective overglaze
• Lead (Pb)-free solder contacts on Ni barrier layer
• AEC-Q200 qualified
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
DESIGN SUPPORT TOOLS
Models
Available
click logo to get started
STANDARD ELECTRICAL SPECIFICATIONS
GLOBAL
MODEL
RCWE0402
CASE SIZE
POWER RATING
P
70 °C
W
0.125
TEMPERATURE
COEFFICIENT
± ppm/°C
400
200
100
700
400
200
100
400
300
200
100
300
200
100
600
300
200
100
500
300
200
100
200
100
600
300
200
100
600
300
200
100
RESISTANCE
RANGE
0.033 to 0.05
0.051 to 0.196
0.2 to 0.976
0.010 to 0.018
0.02 to 0.0324
0.033 to 0.105
0.11 to 0.976
0.010 to 0.018
0.02 to 0.0324
0.033 to 0.05
0.051 to 0.976
0.010 to 0.016
0.018 to 0.2
0.205 to 0.976
0.010 to 0.018
0.02 to 0.0324
0.033 to 0.05
0.051 to 0.976
0.010 to 0.018
0.02 to 0.0324
0.033 to 0.05
0.051 to 0.976
0.010 to 0.016
0.0162 to 0.976
0.010 to 0.018
0.02 to 0.0324
0.033 to 0.05
0.051 to 0.976
0.010 to 0.018
0.02 to 0.0324
0.033 to 0.05
0.051 to 0.976
TOLERANCE
±%
5.0
1.0, 5.0
0.5
(1)
, 1.0, 5.0
5.0
1.0, 5.0
1.0, 5.0
0.5
(1)
, 1.0, 5.0
5.0
1.0, 5.0
1.0, 5.0
0.5
(1)
, 1.0, 5.0
2.0, 5.0
2.0, 5.0
1.0, 5.0
5.0
1.0, 5.0
1.0, 5.0
0.5
(1)
, 1.0, 5.0
5.0
1.0, 5.0
1.0, 5.0
0.5
(1)
, 1.0, 5.0
2.0, 5.0
1.0, 5.0
5.0
1.0, 5.0
1.0, 5.0
0.5
(1)
, 1.0, 5.0
5.0
1.0, 5.0
1.0, 5.0
0.5
(1)
, 1.0, 5.0
E-SERIES
(2)
24
24; 96
24
24; 96
24
24; 96
0402
RCWE0603
0603
0.2
RCWE0805
0805
0.25
RCWE0612
0612
1.0
24
24; 96
24
24; 96
24
24; 96
24
24; 96
24
24; 96
24
24; 96
RCWE1206
1206
0.5
RCWE1210
1210
1.0
RCWE1020
1020
2.0
RCWE2010
2010
1.0
RCWE2512
2512
2.0
Notes
• Power rating depends on the max. temperature at the solder point, the component placement density and the substrate material
• Part marking: Reference “Surface Mount Resistor Marking” (www.vishay.com/doc?20020)
(1)
Tight tolerance of 0.5 % is available for resistance values above 0.300
(0402 size) and above 0.200
(0603 to 2512 sizes)
(2)
Use E24 decades only for 5.0 % tolerance. E24 or E96 decades are available for 0.5 % and 1.0 % tolerance. Refer to standard decade table
(www.vishay.com/doc?31001)
Revision: 21-Aug-2018
Document Number: 20019
1
For technical questions, contact:
ww2bresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
