LEADED CERAMIC RESONATOR
HWZT-MD
FEATURES:
• Low resonant impedance
• Small size, Light
weight.
• Low cost timing solution
RoHS/RoHS II Compliant
APPLICATIONS:
• Clock oscillation for microcontrollers
•
Telephones
• Household electric appliances
Pb in ceramic, exemption (7c-I)
| | | | | | | | | | | | | |
Siz e Varies
|
STANDARD SPECIFICATIONS:
Parameters
Frequency
Range
Resonant
Impedance
(Ro)
24
24
12
4
-0.5
-0.3
30
30
15
5
Minimum
2.00
12.51
Typical
Maximum
6.00
60.00
80
30
30
36
36
18
6
+0.5
+0.3
50
6
15
+85
+85
0.3
Units
MHz
Ω
2.00 MHz ~ 2.99
MHz
3.00
MHz ~
6.00
MHz
12.51 MHz
~ 60.00 MHz
2.00
MHz
~ 6.00
MHz
12.51
MHz ~ 20.00 MHz
20.01 MHz
~ 25.99 MHz
26.00 MHz
~ 60.00 MHz
-25ºC
to +85ºC
DC , 1
min
Notes
Standard Load Capacitance for
test
circuit (C1=C2)
Frequency
Tolerance
Frequency Stability
Withstanding Voltage
D.C. Voltage
Rating Voltage
A.C. Voltage
Insulation
Resistance
Operation
Temperature
Storage
Temperature
Aging Rate (Fosc)
pF
%
%
Vdc
Vdc
Vp-p.
MΩ
ºC
ºC
%
100
-25
-55
-0.3
10Vdc, 1min
From initial
value
TEST CONDITION AND TEST CIRCUIT:
OPTIONS & PART IDENTIFICATION:
HWZT -
X: Ceramic Resonator
Frequency
Frequency in
MHz
MD -
Blank:
Bulk
A: AMMO
package*
*AMMO
package
lead length
13.5mm
Packaging
Parts shall be measured under a condition (Temp.:
20±15°C, Humidity:
65±20%
R.H.) unless the standard
condition
(Temp: 25±2°C, Humidity: 65±5% R.H.)
is
regulated to measure
ABRACON IS
ISO9001:2008
CERTIFIED
Revised: 05.07.13
30332 Esperanza, Rancho
Santa
Margarita,
California
92688
tel
949-546-8000
|
fax
949-546-8001
| www.abracon.com
Visit www.abracon.com for Terms & Conditions of Sale
LEADED CERAMIC RESONATOR
HWZT-MD
OUTLINE DRAWING:
Freq. Range: 2.00 ~ 6.00MHz (Low Profile)
Bulk:
AMMO:
RoHS/RoHS II Compliant
Pb in ceramic, exemption (7c-I)
| | | | | | | | | | | | | |
Siz e Varies
|
Freq. Range: 12.51 ~ 60.00MHz
Bulk:
10.0max
5.0max
AMMO:
**
0.5±0.1
5.0±0.30
5.0±1.0
H
0.25±0.1
H :
*:EIAJ
23.99MHz,
CODE
12.51 ~
MONTHLY
10.0mm max
24.00 ~ 31.99MHz, 7.5mm max
32.00 ~ 60.00MHz, 6.5mm max
Dimension: mm
Packaging:
Bulk:
500pcs/plastic bag
AMMO:
2000pcs/box
Note:
upon opening the original packaging, it is recommended that the product be used within 1 year. If the prod-
uct will not be used within 1 year, it is recommended that the product be re-sealed in airtight packaging according
to MSL 1 requirements to maintain solderability.
CAUTION
(1) Do not apply excess mechanical stress to the component body or terminations. Do not attempt to re-form or bend the components as
this will cause damage to the component.
(2) This component is not hermetically sealed. Do not clean or wash the component.
(3) Reflow Soldering: Do not use strong acidity flux, such as flux with chlorine content of greater than 0.2wt% during Reflow Soldering.
(4) Do not expose the component to open flame.
(5) This specification applies to the functionality of the component as a single unit.
(6) Storage Conditions: If the product is to be stored for a period greater than 1 year after the Delivery Date, it is recommended that
customers confirm the solderability and characteristics for the product prior to use.
(7) This product is not recommended for use in the following applications: Automotive, Medical, Military, Safety, or any other high-
reliability life dependant applications. ContactAbracon Corporation prior to using this product when in doubt.
,
ATTENTION:
Abracon Corporation’s products are COTS – Commercial-Off-The-Shelf products; suitable for Commercial, Industrial and, where designated, Automotive Applica-
tions. Abracon’s products are not specifically designed for Military, Aviation, Aerospace, Life-dependant Medical applications or any application requiring high reliability where
component failure could result in loss of life and/or property. For applications requiring high reliability and/or presenting an extreme operating environment, written consent and
authorization from Abracon Corporation is required. Please contact Abracon Corporation for more information.
ABRACON IS
ISO9001:2008
CERTIFIED
Revised: 05.07.13
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001
| www.abracon.com
Visit www.abracon.com for Terms & Conditions of Sale
