P6KE6V8(C)A - P6KE400(C)A
600W TRANSIENT VOLTAGE SUPPRESSOR
Features
•
•
•
•
•
•
•
600W Peak Pulse Power Dissipation
Voltage Range 6.8V - 400V
Constructed with Glass Passivated Die
Uni- and Bidirectional Versions Available
Excellent Clamping Capability
Fast Response Time
Lead Free Finish, RoHS Compliant (Note 1)
Mechanical Data
•
•
•
•
•
•
•
•
Case: DO-15
Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Leads: Plated Leads, Solderable per MIL-STD-202, Method 208
Marking: Unidirectional - Type Number and Cathode Band
Marking: Bidirectional - Type Number Only
Ordering Information: See Page 4
Weight: 0.4 grams (approximate)
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Symbol
P
pk
I
FSM
V
F
Value
600
100
3.5
5.0
Unit
W
A
V
Characteristic
Peak Power Dissipation, t
p
= 1.0 ms
(Non repetitive current pulse, derated above T
A
= 25°C)
Peak Forward Surge Current, 8.3ms Single Half Sine Wave, Superimposed on Rated
Load Duty Cycle = 4 pulses per minute maximum
Forward Voltage @ I
F
= 35A
V
BR
≤
200V
300µs Square Wave Pulse, Unidirectional Only
V
BR
> 200V
Thermal Characteristics
Characteristic
Steady State Power Dissipation at T
L
= 75°C
Lead Lengths 9.5 mm (Mounted on Copper Land Area of 40mm)
Typical Thermal Resistance, Junction to Case
Typical Thermal Resistance, Junction to Lead
Typical Thermal Resistance, Junction to Ambient
Operating and Storage Temperature Range
Notes:
Symbol
P
D
R
θJC
R
θJL
R
θJA
T
J
, T
STG
Value
5.0
20
15
75
-55 to +175
Unit
W
°C/W
°C/W
°C/W
°C
1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied, see EU Directive 2002/95/EC Annex Notes.
P6KE6V8(C)A - P6KE400(C)A
Document number: DS21502 Rev. 18 - 2
1 of 5
www.diodes.com
March 2010
© Diodes Incorporated
P6KE6V8(C)A - P6KE400(C)A
Electrical Characteristics
Type
Number
(Note 2)
(UNI)
P6KE6V8A
P6KE7V5A
P6KE8V2A
P6KE9V1A
P6KE10A
P6KE11A
P6KE12A
P6KE13A
P6KE15A
P6KE16A
P6KE18A
P6KE20A
P6KE22A
P6KE24A
P6KE27A
P6KE30A
P6KE33A
P6KE36A
P6KE39A
P6KE43A
P6KE47A
P6KE51A
P6KE56A
P6KE62A
P6KE68A
P6KE75A
P6KE82A
P6KE91A
P6KE100A
P6KE110A
P6KE120A
P6KE130A
P6KE150A
P6KE160A
P6KE170A
P6KE180A
P6KE200A
P6KE220A
P6KE250A
P6KE300A
P6KE350A
P6KE400A
Notes:
@T
A
= 25°C unless otherwise specified
Max
Reverse
Leakage
(Note 3)
@ V
R
I
R
(μA)
1000
500
200
50
10
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
Max
Clamping
Voltage
@ I
pp
V
C
(V)
10.5
11.3
12.1
13.4
14.5
15.6
16.7
18.2
21.2
22.5
25.2
27.7
30.6
33.2
37.5
41.4
45.7
49.9
53.9
59.3
64.8
70.1
77.0
85.0
92.0
103.0
113.0
125.0
137.0
152.0
165.0
179.0
207.0
219.0
234.0
246.0
274.0
328.0
344.0
414.0
482.0
548.0
Type
Number
(Note 2)
(BI)
P6KE6V8CA
P6KE7V5CA
P6KE8V2CA
P6KE9V1CA
P6KE10CA
P6KE11CA
P6KE12CA
P6KE13CA
P6KE15CA
P6KE16CA
P6KE18CA
P6KE20CA
P6KE22CA
P6KE24CA
P6KE27CA
P6KE30CA
P6KE33CA
P6KE36CA
P6KE39CA
P6KE43CA
P6KE47CA
P6KE51CA
P6KE56CA
P6KE62CA
P6KE68CA
P6KE75CA
P6KE82CA
P6KE91CA
P6KE100CA
P6KE110CA
P6KE120CA
P6KE130CA
P6KE150CA
P6KE160CA
P6KE170CA
P6KE180CA
P6KE200CA
P6KE220CA
P6KE250CA
P6KE300CA
P6KE350CA
P6KE400CA
Reverse
Standoff
Voltage
V
RWM
(V)
5.80
6.40
7.02
7.78
8.55
9.40
10.20
11.10
12.80
13.60
15.30
17.10
18.80
20.50
23.10
25.60
28.20
30.80
33.30
36.80
40.20
43.60
47.80
53.00
58.10
64.10
70.10
77.80
85.50
94.00
102.00
111.00
128.00
136.00
145.00
154.00
171.00
185.00
214.00
256.00
300.00
342.00
Breakdown Voltage
V
BR @ IT
Min (V)
6.45
7.13
7.79
8.65
9.50
10.50
11.40
12.40
14.30
15.20
17.10
19.00
20.90
22.80
25.70
28.50
31.40
34.20
37.10
40.90
44.70
48.50
53.20
58.90
64.60
71.30
77.90
86.50
95.00
105.00
114.00
124.00
143.00
152.00
162.00
171.00
190.00
209.00
237.00
285.00
332.00
380.00
Max (V)
7.14
7.88
8.61
9.55
10.50
11.60
12.60
13.70
15.80
16.80
18.90
21.00
23.10
25.20
28.40
31.50
34.70
37.80
41.00
45.20
49.40
53.60
58.80
65.10
71.40
78.80
86.10
95.50
105.00
116.00
126.00
137.00
158.00
168.00
179.00
189.00
210.00
231.00
263.00
315.00
368.00
420.00
Test
Current
I
T
(mA)
10
10
10
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Max Peak
Pulse Current
I
PP
(A)
57.0
53.0
50.0
45.0
41.0
38.0
36.0
33.0
28.0
27.0
24.0
22.0
20.0
18.0
16.0
14.40
13.20
12.00
11.20
10.10
9.30
8.60
7.80
7.10
6.50
5.80
5.30
4.80
4.40
4.00
3.60
3.30
2.90
2.70
2.60
2.40
2.20
1.83
1.75
1.45
1.25
1.10
2. Suffix ‘C’ denotes bidirectional device.
3. For bidirectional devices having V
R
of 10 volts and under, the I
R
limit is doubled.
P6KE6V8(C)A - P6KE400(C)A
Document number: DS21502 Rev. 18 - 2
2 of 5
www.diodes.com
March 2010
© Diodes Incorporated
P6KE6V8(C)A - P6KE400(C)A
10,000
T
j
= 25°C
f = 1.0 MHz
V
sig
= 50mV p-p
Measured at
Zero Bias
I
P
, PEAK PULSE CURRENT (%
pp
)
C
T
, CAPACITANCE (pF)
1,000
Measured at
Stand-off Voltage
100
10
1
t, TIME (ms)
Fig. 1 Pulse Waveform
10
100
1,000
V
RWM
, REVERSE STANDOFF VOLTAGE (V)
Fig. 2 Typical Total Capacitance
100
100
Impulse
P
P
, PEAK PULSE POWER (kW)
PEAK PULSE DERATING
(% PEAK POWER OR CURRENT)
75
10
50
1.0
25
10 X 1000 Waveform
as defined by REA
T
C
= 25°C
0.1
0.1
1.0
10
100
1,000
10,000
0
0
25
50
75 100 125 150 175
T
A
, AMBIENT TEMPERATURE (°C)
Fig. 4 Pulse Derating Curve
200
P
d
, STEADY STATE POWER DISSIPATION (W)
Single phase
half-wave 60Hz
resistive or
inductive load
3.75
I
FSM
, PEAK FORWARD SURGE CURRENT (A)
5.0
1,000
100
2.5
10
1.25
0
0
25
50
75
100
125
150
175
200
T
L
, LEAD TEMPERATURE (°C)
Fig. 5, Steady State Power Derating
0
1
10
100
200
NUMBER OF CYCLES AT 60Hz
Fig. 6 Peak Forward Surge Current
vs. Number of Cycles at 60Hz
P6KE6V8(C)A - P6KE400(C)A
Document number: DS21502 Rev. 18 - 2
3 of 5
www.diodes.com
March 2010
© Diodes Incorporated
P6KE6V8(C)A - P6KE400(C)A
Ordering Information
Part Number
(Type Number)-B*
(Type Number)-T*
(Note 4)
Case
DO-15
DO-15
Packaging
500/Bulk
4K/Tape & Reel, 13-inch
* Add "-B" or "-T" to the appropriate type number in Table 1 for Bulk or Tape & Reel, respectively. Example: 6.40V VRWM = P6KE7V5A-B for Bulk, P6KE7V5A-T for
Tape & Reel.
Notes:
4. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02008.pdf.
Package Outline Dimensions
Dim
A
B
C
D
DO-15
Min
Max
25.40
⎯
5.50
7.62
0.686
0.889
2.60
3.60
All Dimensions in mm
P6KE6V8(C)A - P6KE400(C)A
Document number: DS21502 Rev. 18 - 2
4 of 5
www.diodes.com
March 2010
© Diodes Incorporated
