70 MHz Bandpass Filter
Data Sheet
Typical Performance
10
0
-10
-20
-30
-40
-50
-60
-70
-80
-90
Horizontal:
73 76
55 58 61 64 67 70
3 MHz/Div
79 82 85
Vertical: 10 dB/Div
1
125
0
100
-1
75
-2
50
-3
25
-4
0
-5
-25
-6
-50
-7
-75
-8
-100
-9
-125
65 66 67
Horizontal: 1 MHz/Div
73 74 75
68 69 70 71 72
Vertical: 1 dB/Div
Vertical: 25 nsec/Div
8 MHz Bandwidth
Part Number 851557
Parameter
Center Frequency
Insertion Loss at F
o
1 dB Bandwidth
3 dB Bandwidth
40 dB Bandwidth
Passband Variation
Phase Linearity
Group Delay Variation
Absolute Delay
Ultimate Rejection
Substrate Material
Ambient Temperature
Specifications
Unit
Minimum
MHz
dB
MHz
MHz
MHz
dB
deg
nsec
µsec
dB
-
°C
69.89
-
7.5
8
-
-
-
-
-
50
-
-
Typical
70
22
7.63
8.23
10.52
0.22
2.1
40
1.9
60
YZ LiNbO
3
25
Maximum
70.11
24
-
-
10.6
0.8
4
60
-
-
-
-
Package Outline
Matching Configuration
No Matching Required
Nominal Source/Load Impedance = 50
Ω
Package Style I
11/17/99
Sawtek Inc.
Telephone: (407) 886-8860
Fax: (407) 886-7061
