Low-Peak™ LP-CC Class CC 600 Vac/300 Vdc, 1⁄2-30 A time-delay fuses
Technical Data 1023
Effective October 2017
Time-current curves - average melt:
3
3-1/2
4
4-1/2
6
8
10
12
15
20
25
30
6/10
8/10
1
1-1/4
1/2
200
100
AMP RATING
10
TIME IN SECONDS
1
0.1
0.4
1
10
100
CURRENT IN AMPS
1000
0.01
Eaton.com/bussmannseries
3
Technical Data 1023
Effective October 2017
Low-Peak™ LP-CC Class CC 600 Vac/300 Vdc, 1⁄2-30 A time-delay fuses
Current-limitation curves:
INSTANTANEOUS PEAK-LET-THROUGH CURRENT IN AMPS
B
30
25
20
15
2-8/10
1-1/4
Amp Rating
Current-limiting effects:
Let-through current
Prospective (apparent RMS symmetrical vs. fuse rating)
S.C.C. 1-1/4 A 2-8/10 A
15 A
20 A
25 A
1000
3000
5000
10,000
20,000
30,000
40,000
50,000
60,000
80,000
100,000
200,000
100
140
165
210
260
290
315
340
350
390
420
525
135
210
255
340
435
525
610
650
735
785
830
1100
240
350
420
540
680
800
870
915
1050
1130
1210
1600
305
440
570
700
870
1030
1150
1215
1300
1500
1600
2000
380
575
690
870
1090
1300
1390
1520
1650
1780
2000
2520
30 A
435
580
710
1000
1305
1520
1700
1820
1980
2180
2400
3050
A
NOTE: To calculate I
p
(I
peak
) multiply I
RMS
value by 2.3.
RMS SYMMETRICAL CURRENT IN AMPS
A-B = ASYMMETRICAL AVAILABLE PEAK (2.3 X SYM RMS AMPS)
