BAS16-G
www.vishay.com
Vishay Semiconductors
Small Signal Fast Switching Diode
FEATURES
• Silicon epitaxial planar diode
3
• Ultra fast switching speed
• Surface mount package ideally suited for
automatic insertion
• High conductance
1
2
• AEC-Q101 qualified available
• Base P/N-G3 - green, commercial grade
• Material categorization: For definitions of
compliance please see
www.vishay.com/doc?99912
MECHANICAL DATA
Case:
SOT-23
Weight:
approx. 8.1 mg
Packaging codes/options:
18/10K per 13" reel (8 mm tape), 10K/box
08/3K per 7" reel (8 mm tape), 15K/box
PARTS TABLE
PART
BAS16-G
ORDERING CODE
BAS16-G3-08 or BAS16-G3-18
INTERNAL CONSTRUCTION
Single diode
TYPE MARKING
AK
REMARKS
Tape and reel
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Non repetitive peak reverse voltage
Repetitive peak reverse voltage
= working peak reverse voltage
= DC blocking voltage
Peak forward surge current
t
p
= 1 s
t
p
= 1 μs
Half wave rectification with resistive load and
f
50 MHz, on ceramic substrate
8 mm x 10 mm x 0.7 mm
On ceramic substrate
8 mm x 10 mm x 0.7 mm
On ceramic substrate
8 mm x 10 mm x 0.7 mm
TEST CONDITION
SYMBOL
V
RM
V
RRM
= V
RWM
= V
R
I
FSM
I
FSM
I
F(AV)
I
F
P
tot
VALUE
100
75
1
2
150
300
350
UNIT
V
V
A
A
mA
mA
mW
Average forward current
Forward current
Power dissipation
THERMAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Junction ambient
Junction and storage temperature range
Operating temperature range
TEST CONDITION
On ceramic substrate
8 mm x 10 mm x 0.7 mm
SYMBOL
R
thJA
T
j
= T
stg
T
op
VALUE
357
-55 to +150
-55 to +150
UNIT
K/W
°C
°C
Rev. 1.1, 22-Nov-13
Document Number: 85416
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAS16-G
www.vishay.com
Vishay Semiconductors
TEST CONDITION
I
F
= 1 mA
I
F
= 10 mA
I
F
= 50 mA
I
F
= 150 mA
V
R
= 75 V
SYMBOL
V
F
V
F
V
F
V
F
I
R
I
R
I
R
C
D
t
rr
MIN.
TYP.
MAX.
0.715
855
1
1.25
1
50
30
4
6
UNIT
V
mV
V
V
μA
μA
μA
pF
ns
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Forward voltage
Reverse current
Diode capacitance
Reverse recovery time
V
R
= 75 V, T
j
= 150 °C
V
R
= 25 V, T
j
= 150 °C
V
R
= 0, f = 1 MHz
I
F
= 10 mA to i
R
= 1 mA,
V
R
= 6 V, R
L
= 100
TYPICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
1000
10000
I
R
– Reverse Current (nA)
V
R
= 20
V
1000
I
F
- Forward Current (mA)
100
T
j
= 100 °C
10
25 °C
1
100
0.1
10
0.01
0
14356
1
0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0
0
14357
25
V
F
- Forward
Voltage
(V)
50 75 100 125 150 175 200
T
j
– Junction Temperature (°C)
Fig. 1 -
Forward Current vs. Forward Voltage
Fig. 2 -
Reverse Current vs. Junction Temperature
Rev. 1.1, 22-Nov-13
Document Number: 85416
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAS16-G
www.vishay.com
PACKAGE DIMENSIONS
in millimeters (inches):
SOT-23
Vishay Semiconductors
1.15 (0.045)
0.1 (0.004) max.
0.175 (0.007)
0.098 (0.004)
0.2 (0.008)
0.5 (0.020)
0.45 (0.018)
0.35 (0.014)
0.45 (0.018)
0.35 (0.014)
0.3 (0.012)
2.6 (0.102)
2.35 (0.093)
0.45 (0.018)
1.43 (0.056)
1.20 (0.047)
0.35 (0.014)
Foot print recommendation:
0.7 (0.028)
2 (0.079)
1 (0.039)
0.9 (0.035)
1 (0.039)
0.9 (0.035)
Document no.: 6.541-5014.01-4
Rev. 8 - Date: 23.Sept.2009
17418
0.95 (0.037)
0.95 (0.037)
Rev. 1.1, 22-Nov-13
Document Number: 85416
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
0.9 (0.035)
0° t
o8
°
0.9 (0.035)
3.1 (0.122)
2.8 (0.110)
0.550 ref. (0.022 ref.)
