568-2232-2222 datasheet, PDF - EEWORLD Datasheet

568-2232-2222: Description4X2 CB1 ARRAY BLOCK; CategoryLED optoelectronic/LED photoelectric; File Size100KB，1 Pages; ManufacturerDIALIGHT; Websitehttps://www.dialight.com

Download Datasheet Parametric Compare View All

568-2232-2222 Overview

4X2 CB1 ARRAY BLOCK

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Reach Compliance Code	compli
color	GREEN
Configuration	SEPARATE, 8 ELEMENTS
Maximum forward current	0.03 A
JESD-609 code	e0
Lens type	NONDIFFUSED
Nominal luminous intensity	50.0 mcd
Installation features	RADIAL MOUNT
Number of functions	8
Number of terminals	16
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
Optoelectronic device types	SINGLE COLOR LED ARRAY
total height	16.51 mm
method of packing	BULK
peak wavelength	565 nm
shape	ROUND
size	3 mm
surface mount	NO
T code	T-1
Terminal surface	Tin/Lead (Sn/Pb)
Terminal pitch	2.54 mm
perspective	45 deg
Base Number Matches	1

	568-2232-2222	568-2233-3332	568-223X-XXX2	568-2231-1112
Description	4X2 CB1 ARRAY BLOCK	4X2 CB1 ARRAY BLOCK	4X2 CB1 ARRAY BLOCK	4X2 CB1 ARRAY BLOCK
Is it lead-free?	Contains lead	Contains lead	-	Contains lead
Is it Rohs certified?	incompatible	incompatible	-	incompatible
Reach Compliance Code	compli	compliant	-	compliant
color	GREEN	YELLOW	-	RED
Configuration	SEPARATE, 8 ELEMENTS	SEPARATE, 8 ELEMENTS	-	SEPARATE, 8 ELEMENTS
Maximum forward current	0.03 A	0.02 A	-	0.03 A
JESD-609 code	e0	e0	-	e0
Lens type	NONDIFFUSED	NONDIFFUSED	-	NONDIFFUSED
Nominal luminous intensity	50.0 mcd	20.0 mcd	-	29.0 mcd
Installation features	RADIAL MOUNT	RADIAL MOUNT	-	RADIAL MOUNT
Number of functions	8	8	-	8
Number of terminals	16	16	-	16
Maximum operating temperature	100 °C	100 °C	-	100 °C
Minimum operating temperature	-55 °C	-55 °C	-	-55 °C
Optoelectronic device types	SINGLE COLOR LED ARRAY	SINGLE COLOR LED ARRAY	-	SINGLE COLOR LED ARRAY
total height	16.51 mm	16.51 mm	-	16.51 mm
method of packing	BULK	BULK	-	BULK
peak wavelength	565 nm	585 nm	-	635 nm
shape	ROUND	ROUND	-	ROUND
size	3 mm	3 mm	-	3 mm
surface mount	NO	NO	-	NO
T code	T-1	T-1	-	T-1
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	-	Tin/Lead (Sn/Pb)
Terminal pitch	2.54 mm	2.54 mm	-	2.54 mm
perspective	45 deg	45 deg	-	45 deg
Base Number Matches	1	1	-	1
