ZADCS1082/1042/1022
10-Bit, 250ksps, ADC Family
Typical Applications
Embedded control & real time appl.
Industrial control & process control
ZADCS1082 Block Diagram
applications
Motion control applications
Three phase motor control
Power generation (Solar,
Windmills, etc.)
Data Acquisition
Portable Data Logging
Battery-Powered Systems
Automotive
CH0
CH1
CH2
CH3
CH4
CH5
CH6
CH7
COM
IN -
SAR
8-Channel
Analog
Input
Multiplexer
Comparator
IN +
nCS
SCLK
DIN
DOUT
SSTRB
nSHDN
DAC
with inherent
T&H
+
-
+1.25V
Reference
REFADJ
VREF
x 2.00
Serial
Interface
and
Control
State
Machine
Internal
3.2 MHz
Oscillator
VDD
DGND
AGND
Available in ZADCS1082V / ZADCS1042V / ZADCS1022V
Ordering Information
Temperature
range
[°C]
Sample Rate
[ksps]
Channels
[number]
Pins
[number]
Package
[Type]
ZADCS1082VIS20T
ZADCS1082IS20T
ZADCS1042VIS16T
ZADCS1042IS16T
ZADCS1022VIS14T
ZADCS1022IS14T
10
10
10
10
10
10
8
8
4
4
2
2
250
250
250
250
250
250
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
--
--
--
± 0,4 LSB
± 0,4 LSB
± 0,4 LSB
± 0,4 LSB
± 0,4 LSB
± 0,4 LSB
± 0,4 LSB
± 0,4 LSB
± 0,4 LSB
± 0,4 LSB
± 0,4 LSB
± 0,4 LSB
20
20
16
16
14
14
SSOP
SSOP
SSOP
SSOP
SSOP
SSOP
Tube
Tube
Tube
Tube
Tube
Tube
