BAW-56S-E6327: DescriptionDiodes - General Purpose, Power, Switching Silicon Switch Diode; Categorysemiconductor Discrete semiconductor; File Size149KB，12 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/

Download Datasheet Parametric Compare View All

BAW-56S-E6327 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BAW-56S-E6327	-	-	View	Buy Now

BAW-56S-E6327 Overview

Diodes - General Purpose, Power, Switching Silicon Switch Diode

BAW-56S-E6327 Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	Infineon
Product Category	Diodes - General Purpose, Power, Switching
RoHS	Details
Product	Switching Diodes
Mounting Style	SMD/SMT
Package / Case	SOT-363-6
Peak Reverse Voltage	85 V
Max Surge Current	4.5 A
If - Forward Current	0.2 A
Configuration	Double Dual Common Anode
Recovery Time	4 ns
Vf - Forward Voltage	1.25 V
Ir - Reverse Current	0.15 uA
Minimum Operating Temperature	- 65 C
Maximum Operating Temperature	+ 150 C
Packaging	Cut Tape
Packaging	Reel
Height	0.9 mm
Length	2 mm
Type	Switching Diode
Width	1.25 mm
Factory Pack Quantity	3000
Unit Weight	0.000265 oz

Preview

Download Datasheet

View All

BAW56...

Silicon Switching Diode

•

For high-speed switching applications

•

Common anode configuration

•

BAW56S / U: For orientation in reel see

package information below

•

Pb-free (RoHS compliant) package

•

Qualified according AEC Q101

BAW56

BAW56W

BAW56S

BAW56U

, "

, !

Type

BAW56

BAW56S

BAW56U

BAW56W

Pb-containing

Package

SOT23

SOT363

SC74

SOT323

Configuration

common anode

double common anode

common anode

Marking

A1s

package may be available upon special request

2007-09-19
