1310nm Emitting,1550nm Receiving(PIN-TIA,5pin-out,3.3V)
Bi-directional Diplexer Optical Module
C-13/15-FXXM-PX-XXXX/XXX-XX
Features
• Single fiber bi-directional operation
• Laser diode with multi-quantum- well structure
• Low threshold current
• InGaAs/InP PIN Photodiode with trans-impedance amplifier
• High sensitivity with AGC*
• Differential ended output
• Single +3.3V Power Supply
• Integrated WDM coupler
• Un-cooled operation from -40ºC to +85ºC
• Hermetically sealed active component
• SM/MM fiber pigtailed packaging with optional
FC/ST/SC/MU/LC/- connector
• Design for fiber optic networks application
• RoHS Compliant available
Absolute Maximum Rating (Tc=25ºC)
Parameter
Fiber Output Power
LD Reverse Voltage
PIN-TIA Voltage
Operating Temperature
Storage Temperature
L/M/H
Symbol
P
f
V
RLD
V
CC
T
opr
T
stg
Value
1(L)/1.5(M)/2.5(H)
2
4.5
-40 to +85
-40 to +85
Unit
mW
V
V
ºC
ºC
(All optical data refer to a coupled 9/125µm SM fiber & 50/125µm MM fiber)
Optical and Electrical Characteristics( Tc=25ºC)
Parameter
Laser Diode
Optical Output Power
Peak Wavelength
Spectrum Width (RMS)
Threshold Current
Forward Voltage
Rise/Fall Time
Symbol
L
M
H
λ
∆λ
I
th
V
F
t
r/
t
f
I
m
I
DARK
C
t
∆P
f
/P
f
CRT
Min
0.2
0.5
1
1290
-
-
-
-
100
-
-
-1.5
Typical
0.35
0.75
1.6
1310
-
10
1.2
-
-
-
6
-
< -40
Max
0.5
1
-
1330
5
15
1.5
0.5
-
0.1
15
1.5
Unit
Test Condition
mW
nm
nm
mA
V
ns
µA
µA
p
F
CW, I
th
+ 20mA , kink free
CW, P
f
=P
f
(Min)
CW, P
f
=P
f
(Min)
CW
CW, P
f
=P
f
(Min)
I
bias=Ith
,10% to 90%
CW, Pf=Pf(Min),VRPD=2V
V
RPD
=5V
V
RPD
=5V, f=1MHz
APC, -40 to +85ºC
Monitor Diode
Monitor Current
Dark Current
Capacitance
Module
Tracking Error
Optical Crosstalk
dB
dB
Note:
1.Pin assignment can be customized.
2.Specifications subject to change without notice.
LUMINENTOIC.COM
20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486
9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213
1
LUMNDS1556-APR1106
rev. A.0
1310nm Emitting,1550nm Receiving(PIN-TIA,5pin-out,3.3V)
Bi-directional Diplexer Optical Module
C-13/15-FXXM-PX-XXXX/XXX-XX
Detector
λ=1480-1600nm
DC Electrical Characteristics( Tc=25ºC)
Parameter
Power Supply
Differential Output Voltage
Symbol
Vcc
F02
V
d
F04
F06
F02
Min
3.0
-
-
185
-
-
-
Typical
3.3
-
260
250
-
21
26
Max
3.6
1000
450
415
35
30
50
Unit
V
mV
Test Condition
Supply Current (no load)
I
cc
F04
F06
mA
AC/Optical and Electrical Characteristics( Tc=25ºC)
Parameter
Detection Range
Symbol
F02
Min
1480
52
6
1.92
120
404
700
-3
-7
-3
-
-
-
-
48
48
Typical
1550
-
7
2.5
140
470
920
0
-6
-
-38
-33
-26
50
50
50
Max
1600
70
-
3.4
-
-
1100
-
-
-
-35
-30
-23
-
52
62
Unit
nm
Test Condition
-
Measure differentially, AC coupled, RL=50
Ω
Gain @ 10 Mbps Differential
G
F04
F06
F02
V/mW
Measure differentially, AC coupled, RL=50
Ω
Measure differentially with 30uAp-p singnal
Bandwidth
BW
F04
F06
F02
MHz
BER<10
-10
@155Mbps PRBS 2
23
-1,Er=10dB
dBm
BER<10
-10
@622Mbps PRBS 2
23
-1,Er=10dB
BER<10
-12
@1.25Gbps PRBS 2
7
-1,Er=10dB
BER<10
-10
@155Mbps PRBS 2
23
-1,Er=10dB
dBm
BER<10
-10
@622Mbps PRBS 2
23
-1,Er=10dB
BER<10
-12
@1.25Gbps PRBS 2
7
-1,Er=10dB
Saturation Power
Psat
F04
F06
F02
Sensitivity
Sens.
F04
F06
F02
Output Resistance
Rout
F04
F06
ohm
LUMINENTOIC.COM
20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486
9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213
2
LUMNDS1556-APR1106
rev. A.0
1310nm Emitting,1550nm Receiving(PIN-TIA,5pin-out,3.3V)
Bi-directional Diplexer Optical Module
C-13/15-FXXM-PX-XXXX/XXX-XX
Pin Assignment
LD Pin Assignment
A Type
D Type
Pin 1 : Laser Cathode
Pin 2 : Laser Anode and Case Gnd
Pin 3 : Monitor Diode Anode
Pin 4 : Monitor Diode Cathode
Pin 1 : Laser Anode and Monitor Diode Cathode
Pin 2 : Case Gnd
Pin 3 : Laser Cathode
Pin 4 : Monitor Diode Anode
PIN-TIA Pin Assignment
Imon
Vcc(+3.3V)
Pin Assignment
1~Dout
Dout
PD
Dout
F02
2~Vcc
3~GND(CASE)
4~Imon
GND
Functional Schematic
5~Dout
Imon
Vcc(+3.3V)
Pin Assignment
1~Dout
Dout
PD
Dout
F04
2~Vcc
3~GND(CASE)
4~Imon
GND
Functional Schematic
5~Dout
Imon
Vcc(+3.3V)
Pin Assignment
1~Dout
Dout
PD
Dout
F06
2~Vcc
3~GND(CASE)
4~Imon
GND
Functional Schematic
LUMINENTOIC.COM
5~Dout
20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486
9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213
3
LUMNDS1556-APR1106
rev. A.0
1310nm Emitting,1550nm Receiving(PIN-TIA,5pin-out,3.3V)
Bi-directional Diplexer Optical Module
C-13/15-FXXM-PX-XXXX/XXX-XX
Outline Dimensions
Units in mm.
C-13/15-FXXM-PX-SXXX/XXX-XX
Connector Type
PIN-TIA
FC:FC/PC
LD
DIMENSION: A:7.0~7.6 mm (Low & Middle power)
A:9.3~9.9 mm (High power)
SC:SC/PC
ST:ST/PC
MU:MU/PC
C-13/15-FXXM-PX-MXXX/XXX-XX
LC:LC/PC
PIN-TIA
LD
"
"
DIMENSION: A:7.2~9.2 mm
20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486
9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213
LUMINENTOIC.COM
4
LUMNDS1556-APR1106
rev. A.0
1310nm Emitting,1550nm Receiving(PIN-TIA,5pin-out,3.3V)
Bi-directional Diplexer Optical Module
C-13/15-FXXM-PX-XXXX/XXX-XX
Ordering Information
C-13/15-FXXM-PX-XXXX/XXX-XX
1310nm Transmitter
1550nm Receiver
M = with 5 pinout
Pin Assignment
"-"=A Type
D =D Type
Fiber Output Power
L/M/H
Connector
FC/ST/SC/MU/LC/-
" - " = PC Fiber
APC = APC Fiber
(for single mode)
-/G5/GR
02: 155 Mb/s PIN-TIA+3.3V
04: 622 Mb/s PIN-TIA+3.3V
06:1250 Mb/s PIN-TIA+3.3V
S=SM 9/125µm
M=MM 50/125µm
Fiber Application
RoHS Compliant
Blank = RoHS non-compliant product
G5 = RoHS 5/6-compliant product (lead exemption)
GR = Full RoHS compliant product (no exemption)
Warnings
Handling Precautions:
This device is susceptible to damage as a result of electrostatic discharge (ESD). A static free environment is
highly recommended. Follow guidelines according to proper ESD procedures.
Laser Safety:
Radiation emitted by laser devices can be dangerous to human eyes. Avoid eye exposure to direct or indirect radiation.
Legal Notice
IMPORTANT NOTICE!
All information contained in this document is subject to change without notice, at LuminentOIC＇s sole and absolute discretion.
LuminentOIC warrants performance of its products to current specifications only in accordance with the company＇s standard one-year
warranty; however, specifications designated as “preliminary＂ are given to describe components only, and LuminentOIC expressly dis-
claims any and all warranties for said products, including express, implied, and statutory warranties, warranties of merchantability,
fitness for a particular purpose, and non-infringement of proprietary rights. Please refer to the company＇s Terms and Conditions of
Sale for further warranty information.
LuminentOIC assumes no liability for applications assistance, customer product design, software performance, or infringement of pat-
ents, services, or intellectual property described herein. No license, either express or implied, is granted under any patent right,
copyright, or intellectual property right, and LuminentOIC makes no representations or warranties that the product(s) described here-
in are free from patent, copyright, or intellectual property rights. Products described in this document are NOT intended for use in
implantation or other life support applications where malfunction may result in injury or death to persons. LuminentOIC customers
using or selling products for use in such applications do so at their own risk and agree to fully defend and indemnify LuminentOIC
for any damages resulting from such use or sale.
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROVIDED ON AN “AS IS＂ BASIS. Customer agrees that LuminentOIC is not liable for any
actual, consequential, exemplary, or other damages arising directly or indirectly from any use of the information contained in this
document. Customer must contact LuminentOIC to obtain the latest version of this publication to verify, before placing any order,
that the information contained herein is current.
© LuminentOIC, Inc. 2006
All rights reserved
LUMINENTOIC.COM
20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486
9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213
5
LUMNDS1556-APR1106
rev. A.0
