SMA
COUPLERS, DUAL DIRECTIONAL
0.2-18 GHz
GENERAL INFORMATION
KDI/Triangle’s forward and reverse-dual directional couplers feature strip-
line construction with high directivity and excellent accuracy. High perfor-
mance specifications are offered in a space-saving “two-in-one package”
which is competitively priced.
SERIES CLD,
CL-K07S
GENERAL SPECIFICATIONS
Frequency Range:
Impedance:
Finish Conn.:
Body:
Coupling Values:
Total Tolerance:
(includes frequency sensitivity)
Frequency Sensitivity:
Power:
Temperature Range:
Construction:
0.2 to 18.0 GHz, Octave Bands
50 Ohms Nominal
Passivated S/S per MIL-C-39012
Paint
6, 10, 20, 30 dB (specify when
ordering)
±1.00 dB for 6 dB
±1.25 dB for 10-30 dB
±0.6 dB for 6 dB
±0.75 dB for 10-30 dB
50 WCW, 3 KW peak
–55° C to +85° C
Stripline.
TYPE "SMA" FEMALE
(4) PLS.
.62[15,8]
MAX.
H
±.03
[0,76]
.38[9,65]
TYP.
L
±.03[0,76]
.38±.003
[9,65±0,08]
OUTLINE CLD SERIES
ELECTRICAL PERFORMANCE Dual (Forward and Reverse) Directional Couplers CLD Series
Frequency
Range
GHz
0.2-0.4
0.25-0.50
0.5-1.0
1-2
1.5-3.0
2-4
2.6-5.2
4-8
Nominal
Coupling
dB
Deviation from
Nominal
Coupling vs.
Frequency
dB
Minimum
Directivity
dB
25
25
25
23
20
20
20
20
17
14
Maximum
Prim/Sec
VSWR
1.15
1.15
1.15
1.15
1.20
1.20
1.25
1.25
1.30
1.50
Maximum
Insertion
Loss Above
Coupling Loss
dB
0.4
0.4
0.4
0.4
0.4
0.4
0.5
0.5
0.8
0.9
Model*
No.
CLD-24
CLD-25
CLD-510
CLD-1020
CLD-1530
CLD-2040
CLD-2652
CLD-4080
“L”
inches[mm]
7.0[177,8]
7.0[177,8]
7.0[177,8]
7.6[193,0]
2.8[71,1]
2.4[61,0]
2.0[50,8]
2.0[50,8]
2.0[50,8]
2.0[50,8]
“H”
*
inches[mm]
2.0[50,8]
2.0[50,8]
0.5[12,7]
0.5[12,7]
0.5[12,7]
0.5[12,7]
0.5[12,7]
0.5[12,7]
0.5[12,7]
0.5[12,7]
See
General
Specifications
CLD-7012
7-12.4
CLD-1218
12.4-18
*Specify coupling value when ordering
ELECTRICAL SPECIFICATIONS
MODEL CL-K07S
Frequency:
Coupling:
Coupling Flatness:
Directivity:
Ins. Loss:
VSWR, PRI:
SEC:
Average Power:
Operating Temperature:
Store Temperature:
Intermod Product:
810-960 MHz
30 ±.75 dB
±0.25 dB
30 dB minimum 810-900 MHz .28 dB
minimum 901-960
0.2 dB maximum
1.08:1 maximum
1.20:1 maximum
500W maximum
0° to +70°C
–40° to +85°C
–110 dBm maximum in Rec. Band
Given 2 XMIT Band Signals @ 25W
average power
.79
[20,0]
.631
[16,0]
MAX
2 PLS.
4.568
[116,0]
MAX
1.10
[28,0]
MAX
.79
[20,0]
MAX
1.10[28,0] MAX 2 PLS
MTG. SURFACE
TO FREE OF PAINT
2.56
[65,0]
MAX
TYPE 'N' FEMALE
CONN. 2 PLS
4X M4.0 X 0.7
8.5 MM FULL THREAD
WILL ACCEPT A SCREW
TO A DEPTH OF 14 MM
1.97
[50,0]
ANT
TYPE 'SMA' FEMALE
CONN.
2 PLS
-30dB
KEY:
Inches[Millimeters] .XX ±.03 .XXX ±.010 [.X ±0.8 .XX ±0.25]
10/98
An MCE Company
CORPORATION
TRIANGLE
BTS
-30dB
.709
[18,0]
OUTLINE CL-KO7S
