Molded transformer terminal block - VTRK 4-SI/C OG - 3004508
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Molded transformer terminal block, Connection method: Screw connection, Length: 23.4 mm, Width: 12.4 mm,
Height: 29.7 mm, Color: orange
Key Commercial Data
Packing unit
Minimum order quantity
GTIN
Weight per Piece (excluding packing)
Custom tariff number
Country of origin
10.23 g
85369010
Poland
1 pc
50 pc
Technical data
General
Number of connections
Color
Insulating material
Flammability rating according to UL 94
Rated surge voltage
Rated insulation voltage
Degree of pollution
Overvoltage category
Nominal current I
N
Nominal voltage U
N
Number of positions
4
orange
PA
V0
0.8 kV
32 V
3
III
10 A (is determined by the fuse used)
voltage data only possible in conjunction with transformer
2
Dimensions
04/24/2016 Page 1 / 7
https://www.phoenixcontact.com/us/products/3004508
Molded transformer terminal block - VTRK 4-SI/C OG - 3004508
Technical data
Dimensions
Width
Length
Height
12.4 mm
23.4 mm
29.7 mm
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule without plastic sleeve max.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded min.
2 conductors with same cross section, stranded max.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
0.2 mm²
6 mm²
0.2 mm²
4 mm²
24
10
0.25 mm²
4 mm²
0.25 mm²
2.5 mm²
0.2 mm²
1.5 mm²
0.2 mm²
1.5 mm²
0.25 mm²
1.5 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic
0.5 mm²
sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with plastic
2.5 mm²
sleeve, max.
Connection method
Stripping length
Internal cylindrical gage
Screw thread
Tightening torque, min
Tightening torque max
Screw connection
8 mm
A4
M3
0.6 Nm
0.8 Nm
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
CSA
V0
04/24/2016 Page 2 / 7
https://www.phoenixcontact.com/us/products/3004508
Molded transformer terminal block - VTRK 4-SI/C OG - 3004508
Classifications
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 7.0
eCl@ss 8.0
27141110
27141110
27141110
27141110
27141110
27141110
27141110
ETIM
ETIM 2.0
ETIM 3.0
ETIM 4.0
ETIM 5.0
EC001283
EC001283
EC000398
EC000398
UNSPSC
UNSPSC 6.01
UNSPSC 7.0901
UNSPSC 11
UNSPSC 12.01
UNSPSC 13.2
30211811
39121410
39121410
39121410
39121410
Approvals
Approvals
Approvals
CSA / UL Recognized / cUL Recognized / EAC / cULus Recognized
Ex Approvals
Approvals submitted
Approval details
04/24/2016 Page 3 / 7
https://www.phoenixcontact.com/us/products/3004508
Molded transformer terminal block - VTRK 4-SI/C OG - 3004508
Approvals
CSA
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
B
24-10
7.5 A
125 V
D
24-10
7.5 A
125 V
UL Recognized
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
B
30-10
10 A
32 V
C
30-10
10 A
32 V
cUL Recognized
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
B
30-10
10 A
32 V
C
30-10
10 A
32 V
EAC
cULus Recognized
Accessories
Accessories
Fuse
04/24/2016 Page 4 / 7
https://www.phoenixcontact.com/us/products/3004508
Molded transformer terminal block - VTRK 4-SI/C OG - 3004508
Accessories
Fuse - SI FORM C 2 A - 0913689
Flat-type plug-in fuse, type C, color code: gray, nominal current: 2 A
Fuse - SI FORM C 3 A DIN 72581 - 0913773
Flat-type plug-in fuse, type C, color code: violet, nominal current: 3 A
Fuse - SI FORM C 4 A DIN 72581 - 0913731
Flat-type plug-in fuse, type C, color code: pink, nominal current: 4 A
Fuse - SI FORM C 5 A DIN 72581 - 0913692
Flat-type plug-in fuse, type C, color code: light brown, nominal current: 5 A
Fuse - SI FORM C 7,5 A DIN 72581 - 0913702
Flat-type plug-in fuse, type C, color code: brown, nominal current: 7.5 A
04/24/2016 Page 5 / 7
