SERIES 880
Quick Disconnect
880-001P Cable Plug with Pigtail Wires
and Integral Banding Porch
Series 880 Quick-Disconnect (QDC) cable plugs are pre-wired and sealed with
epoxy. Features an integral shield termination platform and Three contact sizes
are available with current ratings of 5A, 3A and 1A. Aluminum or stainless steel
housings and thermoplastic insulators. High-strength wire with crosslinked
ETFE insulation crimped at factory to high performance contacts. Ultraminiature
SuperFly® connectors are ideal for soldier systems and other applications where
reduced size and weight are critical.
Shell Size and Insert Arrangements
Insert
Arrangement
B7N
C10N
C2M2N
D3M
D2W2N
E3W
E4M
E19N
E4M4N
F4W
F7M
F22N
F4M8N
F4W4N
G7W
G10M
G31N
G6M10N
G6M12N
H10W
H37N
H6W14N
J44N
J7W19N
K19M
K13M19N
L22M
No. of Contacts
#23
Micro
Nano
5A.
3A.
1A.
—
—
—
—
2
3
—
—
—
4
—
—
—
4
7
—
—
—
—
10
—
6
—
7
—
—
—
—
—
2
3
—
—
4
—
4
—
7
—
4
—
—
10
—
6
6
—
—
—
—
—
19
13
22
7
10
2
—
2
—
—
19
4
—
—
22
8
4
—
—
31
10
12
—
37
14
44
19
—
19
—
How To Order
Sample Part Number
Series
Insert Style
Shell Size/
Insert Arr.
1
Material/
Finish
2
880-001P
A
= Unshrouded Contacts
B
= Shrouded Contacts
Shrouded contacts are recessed
within the insulator
See Shell Size and Insert
Arrangement Table
M
= Aluminum/electroless nickel RoHS compliant
ZR
= Aluminum/zinc-nickel, non-reflective with
RoHS compliant black chromate
MT
= Aluminum/nickel-PTFE RoHS compliant
ZMT
= Stainless steel/nickel-PTFE RoHS compliant
See Wire Code Table
J
= “Space Grade” wire M22759/33 or equivalent (ETFE)
1
= White
5
= Full Color; 1-10 solid color, 11 and up are striped
7
= 10 Color Repeating; Wire #1 black, Wire #11 black, etc
Overall length (‘L’) in inches measured from front of connector
880-001P
A
-B7N
-M
004
J
1
-24
B
Wire AWG
Wire Type
Wire Color
Wire Length
Standard SuperFly® connectors have a single master key. Versions with three keys
are also available if alternate key positions are required. Add suffix code 686 to the
part number per the following example: 880-001PA-B7N-M004J1-24-686A
Plug Alternate Key Positions
Suffix Code
686A
686B
686C
686D
686E
686F
A°
150°
75°
95°
140°
75°
95°
B°
210°
210°
230°
275°
275°
210°
Master
Key
MOD-686 POLARIZING OPTIONS
First letter of insert arrangement represents
connector shell size, as in this example:
K13M19N
B° A°
1. See Section A for insert
arrangement layouts
2. See Section A for additional finish
options
NOTES
4
© 2015 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • Series 88 SuperFly® Catalog
Dimensions in Inches (millimeters) are subject to change without notice.
SERIES 880
Quick Disconnect
880-001P Cable Plug with Pigtail Wires
and Integral Banding Porch
Shrouded contacts are recessed within the insert. Unshrouded contacts extend from the insert face. Shrouded inserts contain
1 amp and 3 amp Twistpin contacts along with 5 amp socket contacts. Unshrouded inserts contain 1 amp and 3 amp sockets
and 5 amp pin.
Wire Code Table
Layouts with 5A. Contacts
Insert
#23 Micro Nano
Code
Arrangement
5A.
3A.
1A.
#22
—
—
100
E3W, F4W,
#24
—
—
200
G7W, H10W
#26
—
—
300
Layouts with 5A. and 1A. Contacts
Insert
#23 Micro Nano
Code
Arrangement
5A.
3A.
1A.
#22
—
#28
104
#24
—
#28
204
D2W2N, F4W4N,
H6W14N,
J7W19N
#26
#22
#24
—
—
—
#28
#30
#30
304
105
205
3 Amp
Micro Twistpin
ABOUT SHROUDED AND UNSHROUDED SUPERFLY® CONFIGURATIONS
Shrouded
Type B Insert
1 Amp
Nano Twistpin
5 Amp
#23 Socket
3 Amp
Micro Socket
Unshrouded
Type A Insert
B
1 Amp
Nano Socket
5 Amp
#23 Pin
#26
—
#30
305
#22
—
#32
106
#24
—
#32
206
#26
—
#32
306
Layouts with 3A. Contacts
Insert
#23 Micro Nano
Code
Arrangement
5A.
3A.
1A.
D3M, E4M F7M,
G10M, K19M,
L22M
—
—
—
#24
#26
#28
—
—
—
020
030
040
‘L’ +1.00/-.00 (+25.4/-.00
.811 (20.61)
.361 (9.17)
ØB
ØA
—
#30
—
050
Layouts with 3A. and 1A. Contacts
Insert
#23 Micro Nano
Code
Arrangement
5A.
3A.
1A.
—
C2M2N,
E4M4N, F4M8N
G6M10N,
G6M12N,
K13M19N
—
—
—
—
—
—
—
#24
#26
#28
#24
#26
#28
#24
#26
#28
#28
#28
#30
#30
#30
#32
#32
024
034
044
025
035
045
026
036
Pigtail Wires
Band-Master
®
Nano Band
Shield Termination Platform
Dimensions
Shell Size
B
C
D
E
F
G
H
J
K
L
A Max OD
In.
.317
.342
.355
.381
.400
.422
.459
.487
.509
.548
mm.
8.05
8.69
9.02
9.68
10.16
10.72
11.66
12.37
12.93
13.92
In.
.197
.222
.235
.261
.280
.302
.339
.369
.391
.430
B Rear OD
mm.
5.00
5.64
5.97
6.63
7.11
7.67
8.61
9.37
9.93
10.92
—
#28
#32
046
Layouts with 1A. Contacts
Insert
#23 Micro Nano
Code
Arrangement
5A.
3A.
1A.
B7N, C10N,
—
—
#28
004
E19N, F22N,
—
—
#30
005
G31N, H37N,
—
—
#32
006
J44N
© 2015 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • Series 88 SuperFly® Catalog
Dimensions in Inches (millimeters) are subject to change without notice.
5
