HDM 160GS16
Dimensional Drawing
160 X 160 Dots Graphic, Low Power w/Touch Screen
Connector Information:
Mating = Molex 52207-1890
Dimension tolerance: +/-0.3mm
Features
Backlight................................................................................EL
Options.........................................FSTN, Postive mode display
Extended temperature, Bottom viewing
Touch Screen
Built-in Controller..............................................................None
Physical Data
Module Size...................................70.5W x 90.5H x 10.8T mm
Viewing Area Size........................................61.5W x 61.5H mm
Dot Pitch......................................................0.35W x 0.35H mm
Dot Size...................................................0.335W x 0.335H mm
Weight...............................................................................47.9g
Power Supply
Electrical Characteristics (VDD=3.3±0.25V 25°C)
PARAMETER
OPERATING VOLTAGE
POWER FOR LCD
INPUT HIGH VOLTAGE
INPUT LOW VOLTAGE
EL POWER SUP. CUR-
RENT
POWER SUP. CURRENT
POWER SUP. CURRENT
DRIVE METHOD
SYM
V
DD
V
EE
-
V
SS
V
IH
V
IL
CONDITION
-
-
-
-
MIN
3.0
20.2
.8V
DD
GND
TYP
3.3
20.5
-
-
17.5
-
-
1/160 Duty
0.03
1.0
MAX
3.6
20.8
V
DD
.2V
DD
26.3
0.05
1.5
UNIT
V
V
V
V
mA
mA
mA
I
BATTERY
V
DD
=3.3V
EL=ON
I
DD
I
LCD
V
DD
=3.3V
V
DD
=3.3V
Pin Connections
PIN NO.
1
2
3
4
5
6
7
8
9
10
11
SYMBOL
V
SS
FLM
CL1
CL2
M
V
DD
EL ON
V
EE
DB3
DB2
DB1
DB0
LEFT
UP
RIGHT
DOWN
V
SS
BATTERY
0V
3.3V
Ground
Power Supply for EL Backlight
Touch Panel Connections
0V
H
H,H→L
H,H→L
H/L
Ground
First line marker
Display data latch clock
Latch Pulse
AC driving control signal
FUNCTION
Power supply for logic +3.3v
EL Backlight Control (H=ON, L=OFF)
Power supply for LCD
H/L
H/L
H/L
H/L
Data bus
Absolute Maximum Ratings
PARAMETER
SUPPLY VOLTAGE
INPUT VOLTAGE
OPERATING TEMPERATURE
STORAGE TEMPERATURE
SYMBOL
V
DD
-V
SS
V
EE
-V
SS
T
OP
T
STG
0
0
-20
MIN
-0.3
MAX
7.0
30.0
50
70
UNIT
V
V
°C
°C
12
13
14
15
16
17
18
