Zener Diodes
MAZYxxx Series
(MA1Zxxx Series)
Silicon planar type
Unit : mm
For stabilization of power supply
2.5
±0.3
2.15
±0.3
2
■
Features
•
Large power dissipation P
D
: 1 W
•
Zener voltage V
Z
: 4.7 V to 51 V
•
Zener voltage allowable deviation: 10%
•
Auto mounting possible
1
8˚
8˚
0.25
+0.1
–0.05
■
Absolute Maximum Ratings
T
a
=
25°C
Parameter
Repetitive peak forward current
Power dissipation
*1
Symbol
I
FRM
P
D
P
ZSM
T
j
T
stg
Rating
500
1.0
100
150
−40
to
+150
Unit
mA
1.4
±0.2
0 to 0.05
W
W
°C
°C
Non-repetitive reverse surge
power dissipation
*2
Junction temperature
Storage temperature
1: Anode
2: Cathode
NMiniP2-J1 Package
Note) *1: P
D
=
1.0 W achieved with a printed circuit board (alumina)
t
=
50
µs
for the product of V
Z
≤
6.8 V
*2: t
=
100
µs,
T
j
=
150°C
Marking Symbol
Refer to the list of the electrical
characteristics within part numbers
(Example) MAZY047: 4.7
■
Common Electrical Characteristics
T
a
=
25°C
±
3°C
*1
Parameter
Forward voltage
Zener voltage
*2
Zener operating resistance
Reverse current
Temperature coefficient of zener voltage
*3
Symbol
V
F
V
Z
R
Z
I
R
S
Z
Conditions
I
F
=
200 mA
I
Z
I
Z
V
R
I
Z
Specified value
Specified value
Specified value
Specified value
Min
Typ
Max
1.2
Refer to the list of the
electrical characteristics
within part numbers
mV/°C
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7031 measuring methods for diodes.
2. Absolute frequency of input and output is 5 MHz.
3. *1: The temperature must be controlled 25°C for V
Z
mesurement.
V
Z
value measured at other temperature must be adjusted to V
Z
(25°C)
*2: V
Z
guaranteed 20 ms after current flow.
*3: T
j
=
25°C to 150°C
Note) The part number in the parenthesis shows conventional part number.
Publication date: March 2004
SKE00014CED
1.2
±0.4
5.0
+0.4
–0.1
4.4
±0.3
1.2
±0.4
Unit
V
V
Ω
µA
1
