B-01
TS SEALED
SERIES
Features
The TS sealed connector series has a mechanism of terminal
position assurance.
This series consists of 025, 040, 090, 187, and 312 types classified
according to terminal size, covering an extensive array of
applications from signal to power circuits.
●Retainers
are pre-mounted on the connector housing, and are
structured to enable setting by the same simple operation
regardless of the number of ways, improving operability.
●These
connectors can be directly secured to a bracket on the car
body.
TS SEALED SERIES
Wire seals
(UNIT: mm)
●The
wire seals are common to M and F.
※A
wireseal depends on a chosen cable.
Cable size (mm
2
)
Cable overall diameter (mm)
Material
Color
025(0.64
mm
)／STANDARD
B-03
（CHFUS／0.22）
0.95∼1.05
Silicon
Green
φ
2.75
Cable size (mm
2
)
Cable overall diameter (mm)
Material
Color
（CHFUS／0.35∼0.5）
1.1∼1.4
Silicon
Dark Green
φ
2.75
7.4
7.4
SS Type
(7165-1043)
φ
2.75
Cable size (mm
2
)
S Type
(7165-0851)
φ
2.75
Cable size (mm
2
)
（AVSS／0.3）
（AVSSH／0.3）
（AVSSX／0.3）
1.4∼1.5
Silicon
Reddish Brown
（AESSX／0.3）
1.4∼1.5
Silicon
Dark Brown
Cable overall diameter (mm)
Material
Color
Cable overall diameter (mm)
Material
Color
7.4
M Type (For AV)
7.4
M Type (For AE)
(7165-0796)
φ
2.75
(7165-0891)
φ
2.9
025
Cable size (mm
2
)
（AVSS／0.5）
（AVSSH／0.5）
（AVSSX
／0.5）
1.6∼1.7
Silicon
Dark Gray
Cable size (mm
2
)
Cable overall diameter (mm)
Material
Color
（CHFUS/0.35∼0.5）
1.1∼1.4
Silicon
Violet
Cable overall diameter (mm)
Material
Color
7.4
L Type
7.4
United Wire Seal Size S.
(7165-0815)
φ
2.9
(7165-1312)
φ2.9
Cable size (mm
2
)
（AVSS／0.3）
（AVSSH／0.3）
（AVSSX
／0.3）
1.4∼1.5
Silicon
Dark Yellow
Cable size (mm
2
)
（AVSS／0.5）
（AVSSH／0.5）
（AVSSX
／0.5）
（AESSX／0.5）
1.6∼1.7
Silicon
Red Violet
Cable overall diameter (mm)
Material
Color
Cable overall diameter (mm)
Material
Color
7.4
United Wire Seal Size M.
7.4
United Wire Seal Size L.
(7165-1198)
(7165-1199)
Dummy plugs
(UNIT: mm)
●Dummy
plugs are common to M and F.
●Dummy
plugs are used to blind unused terminal holes.
Material
Color
N.B.R
Light Gray
025
φ
2.8
6.4
(7165-0797)
