HSMx-A10x-xxxxx
PLCC-2, Surface Mount LED Indicator
Data Sheet
Description
This family of SMT LEDs is packaged in the industry standard
PLCC-2 package. These SMT LEDs have high reliability
performance and are designed to work under a wide range of
environmental conditions. This high reliability feature makes
them ideally suited to be used under harsh interior automotive
as well as interior signs application conditions.
To facilitate easy pick & place assembly, the LEDs are packed in
EIA-compliant tape and reel. Every reel will be shipped in single
intensity and color bin, except red color, to provide close
uniformity.
These LEDs are compatible with IR solder reflow process. Due
to the high reliability feature of these products, they can also
be mounted using through-the-wave soldering process.
The super wide viewing angle at 120° makes these LEDs ideally
suited for panel, push button, or general backlighting in
automotive interior, office equipment, industrial equipment,
and home appliances. The flat top emitting surface makes it
easy for these LEDs to mate with light pipes. With the built-in
reflector pushing up the intensity of the light output, these
LEDs are also suitable to be used as LED pixels in interior
electronic signs.
Features
Industry standard PLCC-2 package
High reliability LED package
High brightness using AlInGaP and InGaN dice
technologies
Available in full selection of colors
Super wide viewing angle at 120
Available in 8 mm carrier tape on 7 inch reel (2000 pieces)
Compatible with both IR and TTW soldering process
Applications
Interior automotive
—
Instrument panel backlighting
—
Central console backlighting
—
Switch/push button backlighting
Electronic signs and signals
—
Interior full color sign
—
Variable message sign
Office automation, home appliances, industrial equipment
—
Front panel backlighting
—
Push button backlighting
—
Display backlighting
CAUTION
HSMN, M, and E-A10x-xxxxx LEDs are Class 2 ESD sensitive. Please observe appropriate precautions during handling
and processing. Refer to Broadcom Application Note AN-1142 for additional details.
