8230 Overview

RF/MICROWAVE NARROW BAND LOW POWER AMPLIFIER

8230 Parametric

Parameter NameAttribute value
Maximum operating temperature85 Cel
Minimum operating temperature-40 Cel
Maximum input power10 dBm
Processing package description2 X 2 MM, 0.50 MM HEIGHT, LEAD FREE, LEADLESS, MINIMOLD PACKAGE-8
Lead-freeYes
EU RoHS regulationsYes
China RoHS regulationsYes
stateTRANSFERRED
structureCOMPONENT
terminal coatingMATTE TIN/TIN BISMUTH
Microwave RF TypeNARROW BAND LOW POWER
DATA SHEET
BIPOLAR ANALOG INTEGRATED CIRCUIT
PC8230TU
SiGe:C LOW NOISE AMPLIFIER FOR GPS
DESCRIPTION
The
PC8230TU is a silicon germanium carbon (SiGe:C) monolithic integrated circuit designed as low noise
PC8230TU which is included output matching circuit contributes to
amplifier for GPS. This device exhibits low noise figure and high power gain characteristics, so this IC can improve the
sensitivity of GPS receiver. In addition, the
reduce external components and system size.
The package is 8-pin lead-less minimold suitable for surface mount.
This IC is manufactured using our UHS4 (Ultra High Speed Process) SiGe:C bipolar process.
FEATURES
• Low noise
• High gain
• Low current consumption
• Built-in power-saving function
• High-density surface mounting : 8-pin lead-less minimold package (2.0
• Included output matching circuit
• Included very robust bandgap regulator (Small V
CC
and T
A
dependence)
• Included protection circuits for ESD
2.0
0.5 mm)
: NF = 0.85 dB TYP. @ f
in
= 1 575 MHz
: G
P
= 18.5 dB TYP. @ f
in
= 1 575 MHz
: I
CC
= 6.0 mA TYP. @ V
CC
= 3.0 V
APPLICATION
• Low noise amplifier for GPS
ORDERING INFORMATION
Part Number
PC8230TU-E2
Order Number
PC8230TU-E2-A
Package
8-pin lead-less minimold
(Pb-Free)
Marking
8230
Supplying Form
8 mm wide embossed taping
Pin 5, 6, 7, 8 indicates pull-out direction of tape
Qty 5 kpcs/reel
Remark
To order evaluation samples, contact your nearby sales office.
Part number for sample order: PC8230TU
Caution Observe precautions when handling because these devices are sensitive to electrostatic discharge.
The information in this document is subject to change without notice. Before using this document, please confirm
that this is the latest version.
Document No. PU10612EJ01V0DS (1st edition)
Date Published April 2006 NS CP(N)
