Liquid Tight Cordgrips
HEYbrid Stainless Steel Liquid Tight Cordgrips
Straight-Thru, Metric Hubs
Don’t get SKU’ed: More Cable Range, Fewer SKU’s –
Genetically engineered to destroy your inventory monster!
The Ultimate in Liquid Tight Strain Relief Protection
CABLE DIA. RANGE
Minimum Maximum
in. mm.
.065
.115
.065
.105
.095
.170
.180
.260
in.
mm.
5,3
M6060
6,4
M6061
5,8
M6062
8,0
M6063
RSSCG M12
SSCG M12
RSSCG M16
SSCG M16
RSSCG M20
SSCG M20
c
US
™
ALL NEW
PRODUCTS!
•
HEYCo-molded gripping finger/gland
technology
accommodates the
widest
cable range
over the
fewest sku’s.
•
Rolled grease-free threads
prevent
galling
and allow for multiple
assemblies and disassemblies.
No messy, unsightly thread
lubrication required.
•
Approved for
NEMA 4, 4X, 6 and 6P
applications.
•
Self-retaining sealing rings eliminate
the need for an O-Ring groove, thus
reducing cost.
•
Typical applications: Control cabinets,
marine, car washes, hot tubs,
instrumentation, carpet cleaning
machines, food processing equipment,
underground for direct burial
or submersed up to 130 ft. (70 PSIG).
•
Ideal for corrosive environments.
•
Constructed from corrosion resistant
303 stainless steel.
•
Resistant to salt water, acids and
most chemicals.
•
Locknuts not included. To order
locknuts separately, see page 3-46.
•
Patent pending.
•
DFARS Compliant
PART
NO.
DESCRIPTION
or
PART DIMENSIONS
A
B
C
D
E
Clearance Max. O.A. Thread
Wrenching Nut
Hole Dia.
Length
Length Thickness Flat Size
in. mm. in. mm. in. mm. in. mm. in. mm.
.473 12,0 1.23 31,2 .34
.630 16,0 1.31 33,3 .34
8,6 .20
8,6 .20
5,1
5,1
.75 19,1
.88 22,4
HEYco-molded Finger/Gland
1,7 .210
2,9 .250
1,7 .230
2,7 .315
2,4 .290 7,4
M6066
4,3 .450 11,4
M6067
4,6 .400 10,2
M6068
6,6 .545 13,8
M6069
.787 20,0 1.58 42,9 .42 13,5 .20
.787 20,0 1.70 43,2 .42 10,7 .20
.985 25,0 1.91 48,5 .53 13,5 .20
1.260 32,0 2.19 55,6 .59 15,0 .20
5,1 1.06 26,9
5,1 1.25 31,8
5,1 1.31 33,3
5,1 1.75 44,5
RSSCG LL M20
SSCG LL M20
c
RSSCG M25
SSCG M25
RSSCG M32
SSCG M32
c
US
.250 6,4 .490 12,4
M6070
.435 11,0 .705 17,9
M6071
.490 12,4 .785 19,9
M6072
.590 15,0 1.000 25,4
M6073
US
c
US
The HEYCo-molded
Finger, Gland & Seat
NYLON
FINGERS
B
C
D
A
E
SUGGESTED CLEARANCE HOLE
FOR NONTHREADED MOUNTING
HEYCo-molded
ELASTOMERIC
GLAND AND SEAT
RETAINED
SEALING WASHER
Material
Certifications
Flammability Rating
Temperature Range
IP Rating
c
US
303 Stainless Steel Body and sealing nut with nylon 6/6 and TPE
co-molded finger/gland assembly
SBR Sealing Washer
Listed under Underwriters’ Laboratories File E51579
Recognized under Underwriters’ Laboratories File E51579
94V-2
-40°F (-40°C) to 221°F (105°C)
IP68 (70 PSI, 5 BAR)
Quick
Specs
3-26
