Anti-Pulse Power Resistors
Anti-Pulse Power Resistors
Type:
ERGD
(0.5 W, 1 W, 2 W, 3 W)
Features
●
Miniaturized
●
Non-flammable
●
Anti-Pulse
Characteristic
●
Automatic Insertion
●
RoHS compliant
Explanation of Part Numbers
1
2
3
4
5
6
7
8
9
10
11
12
E
R
G
2
D
J
2
2
4
Product Code
Anti-Pulse
Power Resistors
Power Rating
12
0.5 W
1
1W
2
2W
3
3W
Resistance
Tolerance
G
±2 %
J
±5 %
Resistance Value
The first two digits are
significant figures of
resistance and the third
one denotes number of
zeros following.
(Ex.) 224 : 220 kΩ
Code
□···□
□···V
□···P
U···V
□···E
W···E
Forming &
Taping matrix
12D 1D 2D 3D
Straight lead wire type
○ ○ ○ ○
Axial paping type (Straight lead)
○ ○ ○ ○
Cut & Forming type
○ ○ ○ ○
Axial paping type (Stand off)
○ ○
Radial Taping type (E type)
○ ○ ○
Radial Taping type (WE type)
○ ○ ○ ○
Forming / Packaging
The above example shows an anti-pulse resistor, 2 W power rating, resistance value of 220 k ohms, tolerance ±5 %, and package of standard bulk
packing.
Construction
High reliable special film
Lead wire
Dimensions in mm (not to scale)
k
L
k
fd
fD
Ceramic core
(High thermal conductivity)
Dimensions (mm)
Spiralling
turns
Part No.
Marking
L
ERG12D
ERG1D
6.35
–0.35
9.00
–1.00
+0.65
0D
2.3
–0.3
2.8
4.0
5.5
+0.5
k
30.0
30.0
30.0
38.0
±3.0
0d
0.65
0.65
0.80
0.80
±0.05
Mass
(Weight)
[g/pc.]
0.26
0.33
0.66
1.47
+1.50
±0.5
±3.0
±0.05
Flame and solvent retardant
ERG2D
End cap
12.00
–1.00
15.00
+1.50
±1.0
±3.0
±0.05
ERG3D
±1.50
±1.0
±3.0
±0.05
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
02 Sep. 2014
Anti-Pulse Power Resistors
Ratings
Power
Rating
at 70 °C
(W)
0.5
1
2
3
Limiting
Element
(1)
Voltage
(V)
400
500
500
500
Maximum
Dielectric
Maximum
Intermittent Withstanding
Overload
Overload
Voltage
(2)
Voltage
(3)
Voltage
(V)
(VAC)
(V)
800
1000
1000
1000
800
1000
1000
1000
500
500
700
700
Res.
Tol.
(%)
J
G
J
G
J
G
J
G
(±5)
(±2)
(±5)
(±2)
(±5)
(±2)
(±5)
(±2)
Resistance
(4)
Range (Ω)
min.
51 k
110 k
110 k
110 k
max.
240 k
330 k
510 k
750 k
E24
E24
E24
E24
Standard
Resistance
Value
Part No.
ERG12D
ERG1D
ERG2D
ERG3D
(1) Rated Continuous Working Voltage (RCWV) shall be determined from RCWV=√Power Rating×Resistance Value or Limiting Element Voltage listed
above whichever less.
(2) Overload (Short-time Overload) Test Voltage (SOTV) shall be determined from SOTV=2.5×Power Rating or max. Overload Voltage listed above
whichever less.
(3) Intermittent Overload Test Voltage (IOTV) shall be determined from IOTV=4.0×Power Rating or max. Intermittent Overload Voltage listed above
whichever less.
(4) Resistance tolerance and resistance range is of use besides range listed, please inquire.
Rated Load (%)
Power Derating Curve
For resistors operated in ambient temperatures above
70 °C, power rating shall be derated in accordance
with the figure on the right.
120
–55 °C
100
80
60
ERG12D
40
20
130 °C
0
–60 –40 –20 0
Ambient Temperature (°C)
235 °C
ERG1D ~ 3D
70 °C
20 40 60 80 100 120 140 160 180 200 220 240
■
As for Packaging Methods and / or cut formed leads,
Please see Metal (Oxide) Film Resistors Packaging Methods
Safety Precautions
The following are precautions for individual products. Please also refer to the common precautions for Fixed Resistors
in this catalog.
1. Transient voltage
If there is a possibility that the transient phenomenon (significantly high voltage applied in a short time) may
occur or that a high voltage pulse may be applied, make sure to evaluate and check the characteristics of
Anti-Pulse Power Resistors (hereafter called the resistors) mounted on your product rather than only depending on
the calculated power limit or steady-state conditions to complete the design or decide to use the resistors.
2. The resistors are covered with a special coating. Do not apply shock or vibration to them, or pinch them with
long-nose pliers. Otherwise, the resistors may be damaged.
3. Do not apply excessive tension to the lead-connected sections. When bending the lead wire, do not apply
excessive stress to the resistors and provide the wire with a natural curvature.
4. Do not brush the resistors during or after the cleaning process, which may be conducted after soldering.
Otherwise, the coating film may be damaged.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
02 Sep. 2014
