PC0882DG-21 Overview

DROP-IN CIRCULATOR

Preview

Download Datasheet

View All

PC0882DG-21

Features

•

Low Cost

Industry Standard 1 Inch Drop-in package

Designed for Wireless Telecom Systems

50 Ohms Characteristic Impedance

The PC0882DG-21 is a small low cost drop-in circulator designed

for applications in high performance linear power amplifiers for

wireless base stations. These circulators feature a robust

construction for high reliability with excellent IMD performance.

CCW rotation and special tab offsets available on request.

S-Parameters are also available on request.

DROP-IN CIRCULATOR

Description

Specifications

Parameter

Frequency Range (MHz)

Insertion Loss (dB)

Isolation (dB)

Return Loss (dB)

IMD (dBc) 2T x 37.5 Watts

-70

Minimum

869

< .15

>25

-75

Typical

Maximum

894

.30

Absolute Maximum Ratings

Parameter

Power

Operating Temperature

Storage Temperature

Maximum

100 Watts CW

-40 to +85

°C

-40 to +85

°C

Note: Typical values represent Mid-band performance @ 25°C.

Schematic

Package

Pin Functions

Function

INPUT

OUTPUT

TERMINATED

Typical Test Data – Insertion Loss

Insertion Loss

0.00

-0.05

-0.10

-0.15

-0.20

S21

Typical Test Data – Return Loss and Isolation

Re turn Loss and Isolation

-18

-23

S11

S22

S12

-28

-33

-0.25

-0.30

849

857

865

873

881

889

897

905

913

Frequency (MHz)

-38

849

857

865

873

881

889

897

905

913

Frequency (MHz)

Specifications and information on this data sheet are subject to change without notice..
