PC0882DG-21H
Features
•
•
•
•
Low Cost and
RoHS
Compliant
Industry Standard 1 Inch Drop-in package
Designed for Wireless Telecom Systems
50 Ohms Characteristic Impedance
The PC0882DG-21H is a small low cost drop-in circulator designed
for applications in high performance linear power amplifiers for
wireless base stations. These circulators feature a robust construction
for high reliability with excellent IMD performance.
These circulators are built Lead-Free and RoHS compliant.
CCW rotation and special tab offsets available on request.
S-Parameters are also available on request.
DROP-IN CIRCULATOR
Description
Specifications
Parameter
Frequency Range (MHz)
Insertion Loss (dB)
Isolation (dB)
Return Loss (dB)
IMD (dBc) 2T x 37.5 Watts
20
20
-70
Minimum
869
< .15
>25
>25
-75
Typical
Maximum
894
.30
Absolute Maximum Ratings
Parameter
Power
Operating Temperature
Storage Temperature
Maximum
100 Watts CW
-40 to +85
°C
-40 to +85
°C
Note: Typical values represent Mid-band performance @ 25°C.
Schematic
Package
Pin Functions
Function
INPUT
Pin
1
2
3
1
2
OUTPUT
TERMINATED
3
Typical Test Data – Insertion Loss
Insertion Loss
0.00
-0.05
-0.10
dB
-0.15
-0.20
S21
Typical Test Data – Return Loss and Isolation
Re turn Loss and Isolation
-18
-23
S11
S22
S12
dB
-28
-33
-0.25
-0.30
849
857
865
873
881
889
897
905
913
Frequency (MHz)
-38
849
857
865
873
881
889
897
905
913
Frequency (MHz)
Specifications and information on this data sheet are subject to change without notice.
1860 Hartog Drive, San Jose, California 95131 USA
Leffelholzstr. 20, D-90441, Nurnberg, Germany
2/1-2F, No.99 Lane 2535 Gudai Rd, Shanghai, China PC 201100
Tel: 001-408-436-7720
Tel: +49(0)911/9411 233
Tel: (86)21-5416-8648
Fax: 001-408-436-7689
Fax: +49(0)911/9411 198
Fax: (86)21-5416-8753
