MXB-1502-17H
Features
•
•
•
•
•
Frequency Range: LO & RF 10 – 1500 MHz, IF DC – 1000 MHz
L.O. Drive: +17 dBm
Industry Standard SMT package
Available in Tape-and -Reel
Low Cost
The MXB-1502-17 is a high drive level, surface mount mixer
designed for applications that require small, low cost and highly
reliable surface mount components. This mixer is a
double balanced design for wideband high dynamic range
use in communications up and down-converter applications.
SURFACE MOUNT MIXER
Description
Specifications
Parameter
Frequency Range (MHz)
Conversion Loss (dB)
LO – RF Isolation (dB)
LO – IF Isolation (dB)
IIP
3
(dBm)
25
20
Min
10
6.0
30
30
+20
Typ
Max
1500
8.0
Absolute Maximum Ratings
Parameter
RF Power
Operating Temperature
Storage Temperature
Re-flow Temperature
Maximum
+ 13 dBm
-50 to +80
°C
-65 to +100
°C
+ 240
°C
Notes: Test Conditions-LO +17 dBm, RF -10 dBm, IF 30 MHz.
Typical values represent Mid-band performance @ 25°C.
Schematic
Package – S07
Pin Functions
Function
LO INPUT
RF INPUT
IF OUTPUT
GROUND
Pin
1
4
5
2,3,6
Typical Test Data – Conversion Loss
Typical Test Data – LO-RF and LO-IF Isolation
Conversion Loss
-1.5
-3.5
dB
-5.5
-7.5
-9.5
10
159
308
457
606
755
904
1053 1202 1351 1500
S21
Isolation
-5
-10
-15
-20
dB
-25
-30
-35
-40
-45
10
159
308
457
606
755
904 1053 1202 1351 1500
LO-IF
LO-RF
Frequency (MHz)
Frequency (MHz)
Specifications and information on this data sheet are subject to change without notice..
