SPECIFICATIONS
PARAMETERS
RATED INPUT POWER
MAX INPUT POWER
IMPEDANCE
OUTPUT SPL @ 1W/0.5M
(AT 1.0 kHz)
DISTORTION (MAX.)
RESONANT FREQUENCY
FREQUENCY RANGE
HOUSING MATERIAL
CONE MATERIAL
MAGNET MATERIAL
OPERATING TEMPERATURE
WEIGHT
VALUES
1
1.5
4 ± 15%
83 ± 3
5%
600 ± 20%
600 ~ 4500
METAL
MYLAR
Nd-Fe-B
-25 ~ +100
5.2
n
36
`
0.2
UNITS
W
W
OHM
dBA
-
Hz
Hz
-
-
-
°C
grams
THIS DOCUMENT CONTAINS DATA PROPRIETARY TO
PROJECTS UNLIMITED, INC. ANY USE OR
REPRODUCTION, IN ANY FORM, WITHOUT PRIOR
WRITTEN PERMISSION OF PROJECTS UNLIMITED,
INC. IS PROHIBITED.
©2003, Projects Unlimited Inc.
LTR
-
A
REVISION HISTORY
DESCRIPTION
RELEASED FROM ENGINEERING
REVISED TO INVENTOR 3-D DRAWING TEMPLATE
DATE
4/18/2007
11/26/2008
APPROVED
B.R.
4
`
0.2
1.5
`
0.2
n
31.8
n
16.7
NOTES:
1. ALL DIMENSIONS ARE IN MILLIMETERS.
2. SPECIFICATIONS SUBJECT TO CHANGE OR WITHDRAWL
WITHOUT NOTICE.
3. THIS PART IS RoHS 2002/95/EC COMPLIANT.
UNLESS OTHERWISE
SPECIFIED:
DIMENSIONS ARE IN
MILLIMETERS,
TOLERANCES
ARE ±0.5 AND
ANGLES ARE ±3°.
Designed by
Date
Checked by
Date
Approved by
Date
Drawn Date
SIZE
J.D.
4/18/2007
D.F.
5/1/2007
R.W.
5/1/2007 11/26/2008
A3
AS03604MR-R
Speaker
Edition
Sheet
AS03604MR-R.idw
-
1/1
