PIN
RECEPTACLES
FOR .015” - .020” DIAMETER PINS (#11 CONTACT)
AND .015” - .022” DIAMETER PINS (#05 & #21 CONTACTS)
(SEE SPECIFIC CONTACT RANGE ON PAGE 251)
0489
.040 DIA.
.042 DIA.
.043 DIA.
.033 DIA.
0489-X-15-XX-11-XX-04-0
Press-fit in .041 mounting hole
0463
Basic Part
Number
Length
A
0463-0-15-XX-21-XX-04-0
0466
.055 DIA.
Press-fit in .043 mounting hole.
Shell is Phosphor Bronze Alloy 544 (B2)
.055 DIA.
.046 DIA.
.040 DIA.
0466-0-15-XX-21-XX-04-0
Press-fit in .043 mounting hole.
Shell is Phosphor Bronze Alloy 544 (B2)
.030
.028 .087
.135
.170
.032
.073 .075
.093
.120 .134
0489-0
0489-1
0489-2
.102
.199
.299
.020
.015
.075
.046 DIA.
.093 .105
.041 DIA.
.020 DIA.
.018 DIA.
A
.051
.018 DIA.
.200
7491
7491-0-15-XX-09-XX-04-0
0462
.055 DIA.
.046 DIA.
Press-fit in .042 mounting hole
*
Contact substitution not recommended
.020
.060 DIA.
.045 DIA.
.040 DIA.
.020 .051 .075
.093
0462-0-15-XX-X1-XX-04-0
Press-fit in .043 mounting hole
.030
.028 .088
.150
.041 DIA.
.170
0560
.055 DIA.
0560-0-15-XX-11-XX-10-0
Hex press-fit in .043 plated through-hole
.016
.025
.038 DIA.
.063
.110
.140
5552
.068 DIA.
5552-0-15-XX-05-XX-10-0
Solder mount in .040 min. mounting hole
.018
.083
.033 DIA.
.024 DIA.
HOLE
.120
.038 DIA.
.160
.200
.012 DIA.
.082
.020 DIA.
.046
4890
.039 DIA.
4890-X-15-XX-11-XX-04-0
Octagonal press-fit in .041 mounting hole
4994
Basic Part
Number
Length
A
.055 DIA.
4994-0-15-15-11-27-10-0
4485
.064 DIA.
Compliant press-fit in .041 - .044 dia.
mounting hole
.030
.075 .084
.100
.155
4485-0-51-XX-21-XX-10-0
Solder mount in .059 min. mounting hole
For wire sizes up to 22 AWG
.050
.083
.186
.056 DIA.
.364
.042 DIA.
.033 DIA.
.020
.080 .075 .093
.120
.158
4890-0
4890-1
4890-2
.045 DIA.
.102
.199
.299
.017 DIA.
.035
.018 DIA.
A
.020 DIA.
HOLE
.038 DIA.
HOLE
.125
.100 .104
PAGE 160 | PIN RECEPTACLES
SPECIFICATIONS:
Shell Material:
Brass Alloy 360, 1/2 Hard
Contact Material:
Beryllium Copper Alloy 172, HT
Dimensions: Inches
Tolerances On:
Lengths:
± .005
2011/65/EU
ORDER CODE: XXXX - X - XX - XX -
XX
- XX - XX - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
200
μ”
TIN/LEAD OVER NICKEL
80
200
μ”
TIN OVER NICKEL (RoHS)
15
10
μ”
GOLD OVER NICKEL (RoHS)
SPECIFY CONTACT FINISH:
02
100
μ”
TIN/LEAD OVER NICKEL
84
100
μ”
TIN OVER NICKEL (RoHS)
27
30
μ”
GOLD OVER NICKEL (RoHS)
Diameters: ± .002
Angles:
±2°
RoHS - 2
SELECT CONTACT:
#05, #11 or #21
CONTACT (DATA ON PAGE 251)
(For alternate contact choices, see group A on page 248)
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
