PIN
RECEPTACLES
FOR .015” - .025” DIAMETER PINS
0501
0501-0-15-XX-30-XX-04-0
Press-fit in .057 mounting hole
8427
8427-0-15-XX-30-XX-04-0
Press-fit in .057 mounting hole
1434
1434-0-15-XX-30-XX-10-0
Press-fit in .055 mounting hole
9970
9970-0-15-XX-30-XX-04-0
Square press-fit in .032 ± .002
plated through-hole
5970
5970-X-15-XX-32-XX-04-0
Square press-fit for .032 or .039 ± .002
plated through-hole
0477/0478
Basic Part
Number
U
Square
Mounting
Hole
047X-0-18-XX-30-XX-04-0
Solderless press-fit in .038 +.003 / -.002 plated
through-hole (use 1.1mm drill prior to plating)
5970-1
5970-2
.028
.034
.032
.039
Basic
Part
Number
V
A
Board
Thick-
ness
Length
V
Length
A
0477-0
0478-0
.062
.125
.075
.140
.175
.250
4612
4612-0-31-XX-30-XX-04-0
Compliant press-fit in .040 ± .003 plated
through-hole. For .060".100” thick board
4613
4613-0-31-XX-30-XX-04-0
Compliant press-fit in .040 ± .003 plated
through-hole. For .090”.130” thick board
0680
0680-0-15-XX-32-XX-10-0
Solder mount in .051 min. mounting hole
Also available on 16mm wide carrier tape:
1,700 parts per 13” reel
Order as: 0680-0-57-XX-32-XX-10-0
0149
0149-0-15-XX-30-XX-04-0
Press-fit in .059 mounting hole
PAGE 162 | PIN RECEPTACLES
SPECIFICATIONS:
Shell Material:
Brass Alloy 360, 1/2 Hard
Contact Material:
Beryllium Copper Alloy 172, HT
Dimensions: Inches
Tolerances On:
Lengths:
± .005
RoHS - 2
2011/65/EU
ORDER CODE: XXXX - X - XX - XX -
XX
- XX - XX - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
200
”
TIN/LEAD OVER NICKEL
80
200
”
TIN OVER NICKEL (RoHS)
15
10
”
GOLD OVER NICKEL (RoHS)
SPECIFY CONTACT FINISH:
02
100
”
TIN/LEAD OVER NICKEL
84
100
”
TIN OVER NICKEL (RoHS)
27
30
”
GOLD OVER NICKEL (RoHS)
Diameters: ± .002
Angles:
±2°
SELECT CONTACT:
#30 or #32
CONTACT (DATA ON PAGE 253)
(For alternate contact choices, see groups B and C on page 248)
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
