LH1523BB, LH1523BAC, LH1523BACTR
www.vishay.com
Vishay Semiconductors
Dual 1 Form B Solid State Relay
FEATURES
DIP
S1
S1'
• Dual channel (LH1511)
• Isolation test voltage 3750 V
RMS
• Typical R
ON
10
S2
S2'
• Load voltage 200 V
• Load current 200 mA
• High surge capability
• Clean bounce free switching
• Low power consumption
• SMD lead available on tape and reel
• Compliant to RoHS Directive 2002/95/EC and in
accordance to WEEE 2002/96/EC
SMD
S1
8
S1' S2
7
6
S2'
5
i179034_2
1
2
3
4
APPLICATIONS
• General telecom switching
DESCRIPTION
The LH1523 dual 1 form B relays are SPST normally closed
switches that can replace electromechanical relays in many
applications. The relays are constructed as a multi chip
hybrid device. Actuation control is via an infrared LED. The
output switch is a combination of a photodiode array with
MOSFET switches and control circuity.
- On/off hook control
- Ring delay
- Dial pulse
- Ground start
- Ground fault protection
• Instrumentation
• Industrial controls
AGENCY APPROVALS
UL1577: file no. E52744 system code H, double protection
CSA:
certification no. 093751
DIN EN: 60747-5-2 (VDE 0884)/60747-5-5 (pending),
available with option 1
FIMKO: 25419
ORDERING INFORMATION
L
H
1
5
2
3
B
ELECTR.
VARIATION
#
#
T
R
DIP
SMD
PART NUMBER
PACKAGE
CONFIG.
TAPE AND
REEL
7.62 mm
> 0.1 mm
PACKAGE
SMD-8, tubes
SMD-8, tape and reel
DIP-8, tubes
UL, CSA, FIMKO
LH1523BAC
LH1523BACTR
LH1523BB
Rev. 1.6, 07-Jul-11
1
For technical questions, contact:
optocoupleranswers@vishay.com
Document Number: 83822
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
LH1523BB, LH1523BAC, LH1523BACTR
www.vishay.com
Vishay Semiconductors
TEST CONDITION
SYMBOL
I
F
I
R
10 μA
I
L
50 μA
V
R
V
L
I
L
I
L
t = 100 ms
I
P
T
amb
T
stg
t = 10 s max.
t = 1 s, I
ISO
= 10 μA max.
(1)
,
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
INPUT
LED continuous forward current
LED reverse voltage
OUTPUT
DC or peak AC load voltage
Continuous DC load current,
one pole operating
Continuous DC load current,
two poles operating
Peak load current (single shot)
SSR
Ambient temperature range
Storage temperature range
Pin soldering temperature
(2)
Input to output isolation voltage
Pole-to-pole isolation voltage (S1 to S2)
(dry air, dust free, at sea level)
Output power dissipation (continuous)
- 40 to + 85
- 40 to + 125
260
3750
1600
P
diss
600
°C
°C
°C
V
RMS
V
mW
200
200
140
400
V
mA
mA
mA
50
5
mA
V
VALUE
UNIT
T
sld
V
ISO
Notes
• Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. Functional operation of the device is not
implied at these or any other conditions in excess of those given in the operational sections of this document. Exposure to absolute
maximum ratings for extended periods of the time can adversely affect reliability.
(1)
Breakdown occurs between the output pins external to the package.
(2)
Refer to reflow profile for soldering conditions for surface mounted devices (SMD). Refer to wave profile for soldering conditions for through
hole devices (DIP).
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
INPUT
LED forward current, switch turn-on
LED forward current, switch turn-off
LED forward voltage
OUTPUT
On-resistance
Off-resistance
Off-state leakage current
Output capacitance
TRANSFER
Capacitance (input to output)
V
ISO
= 1 V
C
IO
3
pF
I
F
= 0 mA, I
L
= 50 mA
I
F
= 5 mA, V
L
= ± 100 V
I
F
= 5 mA, V
L
= ± 200 V
I
F
= 5 mA, V
L
= 50 V
R
ON
R
Off
I
O
C
O
0.1
10
1.4
0.07
50
1
15
G
μA
pF
I
L
= ± 200 mA, t = 10 ms
V
L
= ± 150 V
I
F
= 10 mA
I
Fon
I
Foff
V
F
1.15
0.2
0.9
1
1.22
2
1.45
mA
mA
V
TEST CONDITION
SYMBOL
MIN.
TYP.
MAX.
UNIT
Note
• Minimum and maximum values are testing requirements. Typical values are characteristics of the device and are the result of engineering
evaluations. Typical values are for information only and are not part of the testing requirements.
SWITCHING CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Turn-on time
Turn-off time
TEST CONDITION
I
F
= 10 mA, I
L
= 50 mA
I
F
= 10 mA, I
L
= 50 mA
SYMBOL
t
on
t
off
MIN.
TYP.
1
2
MAX.
3
3
UNIT
ms
ms
Rev. 1.6, 07-Jul-11
2
For technical questions, contact:
optocoupleranswers@vishay.com
Document Number: 83822
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
LH1523BB, LH1523BAC, LH1523BACTR
www.vishay.com
TYPICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
Vishay Semiconductors
150
5.0 mA
120
Load Current (mA)
90
50
30
0
- 40
ilh1523bb_00
- 20
0
20
40
60
80
Ambient Temperature (°C)
Fig. 1 - Recommended Operating Conditions
PACKAGE DIMENSIONS
in inches (millimeters)
DIP
9.65
6 to 0.8 dia.
2.54
2.54
SMD
9.65
2.54
2.54
6.35
9.14
6.35
7.62
6.35
9.53
8.31
0.46
8.08
7.62
0.46
7.62
8.08
1.9
1.5
3.3
7.24 typ.
4.45
ISO method A
i178017
7.62
3.3
9.14 typ.
ISO method A
0.25 typ.
i178018
0.64 typ.
PACKAGE MARKING
(example)
LH1523
V YWW H 68
Note
• Tape and reel suffix (TR) is not part of the package marking.
Rev. 1.6, 07-Jul-11
3
For technical questions, contact:
optocoupleranswers@vishay.com
Document Number: 83822
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Footprint and Schematic Information
www.vishay.com
Vishay Semiconductors
Footprint and Schematic Information
for LH1523BAC, LH1523BACTR, LH1523BB
The footprint and schematic symbols for the following parts can be accessed using the associated links. They are available in
Eagle, Altium, KiCad, OrCAD / Allegro, Pulsonix, and PADS.
Note that the 3D models for these parts can be found on the Vishay product page.
PART NUMBER
LH1523BAC
LH1523BACTR
LH1523BB
FOOTPRINT / SCHEMATIC
www.snapeda.com/parts/LH1523BAC/Vishay/view-part
www.snapeda.com/parts/LH1523BACTR/Vishay/view-part
www.snapeda.com/parts/LH1523BB/Vishay/view-part
For technical issues and product support, please contact
optocoupleranswers@vishay.com.
DIP
SMD
i179034_2
Rev. 1.0, 09-May-17
