Bussmann
®
Industrial HRC Fuse
12 x 47mm, BS88, IEC 269-1
Offset Bolted Tags
STD
Time-Current Characteristic Curve
(Full Size Curves Available)
1,000
CURRENT
RATING
10
16
20
25
32
2
100
TIME IN SECONDS
4
6
CATALOG SYMBOL: STD
INDUSTRIAL HRC FUSE
OFFSET BOLTED TAGS
PACKAGE QUANTITY: 20
33kA INTERRUPTING RATING
Dimensional Data:
B
C
E
D
E
G
F
10
1
A
H
.1
CURRENT IN AMPERES
Electrical Characteristics
Catalog
Number
STD2
STD4
STD6
STD10
STD16
STD20
STD25
STD32
Ampere
Rating
2
4
6
10
16
20
25
32
I
2
T (Amp
2
Seconds)
Pre-
Total At
Arcing
240V
0.8
5.4
15
28
160
293
800
1600
1
8
22
42
2500
450
1300
2500
Watts
Loss
0.5
1
1.6
1.2
1.5
1.7
1.8
2.4
Nom
Rated
Voltage
Dimensions (Inches/mm)
A
B
C
D
E
F
G
H
240AC
47.0
35.0
24.0
11.0
4.7
12.1
1.0
13.1
The only controlled copy of this BIF document is the electronic read-only version located on the Bussmann Network Drive. All other copies of this BIF document are by definition uncontrolled. This bulletin is intended to
clearly present comprehensive product data and provide technical information that will help the end user with design applications. Bussmann reserves the right, without notice, to change design or construction of any
products and to discontinue or limit distribution of any products. Bussmann also reserves the right to change or update, without notice, any technical information contained in this bulletin. Once a product has been select-
ed, it should be tested by the user in all possible applications.
12-28-98
SB98107
Rev. A
Form No. STD
Page 1 of 1
