VS-VSKT56-04

Description
SCR Modules 400 Volt 60 Amp 890 Amp IFSM
Categorysemiconductor    Discrete semiconductor
File Size505KB,11 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric View All

VS-VSKT56-04 Online Shopping

Suppliers Part Number Price MOQ In stock
VS-VSKT56-04 - - View Buy Now

VS-VSKT56-04 Overview

SCR Modules 400 Volt 60 Amp 890 Amp IFSM

VS-VSKT56-04 Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerVishay
Product CategorySCR Modules
RoHSDetails
On-State RMS Current - It RMS135 A
Non Repetitive On-State Current1200 A
Rated Repetitive Off-State Voltage VDRM400 V
Off-State Leakage Current @ VDRM IDRM15 mA
On-State Voltage1.7 V
Holding Current Ih Max200 mA
Gate Trigger Voltage - Vgt2.5 V
Gate Trigger Current - Igt150 mA
Minimum Operating Temperature- 40 C
Maximum Operating Temperature+ 125 C
Mounting StyleChassis
Package / CaseADD-A-PAK
PackagingBulk
Breakover Current IBO Max1256 A
Current Rating60 A
Circuit TypeThyristors / Thyristors
Factory Pack Quantity10
Unit Weight3.880136 oz
VS-VSK.41.., VS-VSK.56.. Series
www.vishay.com
Vishay Semiconductors
ADD-A-PAK Generation VII Power Modules
Thyristor/Diode and Thyristor/Thyristor, 45 A/60 A
FEATURES
• High voltage
• Industrial standard package
• Low thermal resistance
• UL approved file E78996
• Designed and qualified for industrial level
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
BENEFITS
ADD-A-PAK
• Excellent thermal performances obtained by the usage of
exposed direct bonded copper substrate
• Up to 1600 V
45 A/60 A
PRODUCT SUMMARY
I
T(AV)
or I
F(AV)
Type
Modules - Thyristor, Standard
• High surge capability
• Easy mounting on heatsink
MECHANICAL DESCRIPTION
The ADD-A-PAK generation VII, new generation of
ADD-A-PAK module, combines the excellent thermal
performances obtained by the usage of exposed direct
bonded copper substrate, with advanced compact simple
package solution and simplified internal structure with
minimized number of interfaces.
ELECTRICAL DESCRIPTION
These modules are intended for general purpose high
voltage applications such as high voltage regulated power
supplies, lighting circuits, temperature and motor speed
control circuits, UPS, and battery charger.
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL
I
T(AV)
or I
F(AV)
I
O(RMS)
I
TSM,
I
FSM
I
2
t
I
2
t
V
RRM
T
Stg
T
J
Range
CHARACTERISTICS
85 °C
As AC switch
50 Hz
60 Hz
50 Hz
60 Hz
VS-VSK.41
45
100
850
890
3.61
3.30
36.1
400 to 1600
-40 to 125
-40 to 125
VS-VSK.56
60
135
1200
1256
7.20
6.57
72
400 to 1600
kA
2
s
kA
2
s
V
°C
°C
A
UNITS
Revision: 21-Mar-14
Document Number: 94630
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
