CN-RT
anti sulfuration chip networks
(concave termination)
EU
features
•
Excellent anti-sulfuration characteristic
due to using high sulfuration-proof inner
top electrode material
•
More advancement in the mounting density than
individual chip resistors
•
Mounting cost reduction by decreasing the number
of parts mounting times
•
Higher self-alignment effect in reflow-soldering process
•
Suitable for an image recognition mounter due to
square corner design
•
Products with lead-free terminations meet EU RoHS
requirements. EU RoHS regulation is not intended for
Pb-glass contained in electrode, resistor element and glass.
resistors
b
W
a
L
P
C
d
Ceramic Protective Outer Resistive
Inner
Electrode
Substrate Coating Electrode
Film
dimensions and construction
Dimensions
inches
(mm)
L±0.2 W±0.2
c
d±0.1 t±0.1 a (
top
) a (
bottom
) b±0.1
.02±.004 .016±.006
CN1J4RT
0.126 0.06 .01±.008 0.016
(0.5±0.1) (0.4±0.15)
(1.6) (0.3±0.2) (0.4)
(0603x4)
(3.2)
Type
CN2A4RT
(0805x4)
0.2
CN2B4RT
(5.08)
(1206x4)
0.08 .016±.008
(2.0) (0.4±0.2)
0.022
0.126 .02±.01
(0.55)
(3.2) (0.5±0.3)
0.024
0.006
(0.6)
.03±.004 .03±.006
(0.15)
(0.8±0.1) (0.75±0.15)
Weight
(g)
10.2
20.6
33.5
P
0.031
(0.8)
0.05
(1.27)
ordering information
CN
Type
CN
CNZ
1J
Size
1J
2A
2B
4
Number
of Resistors
4
RT
Termination
Material
RT : Sn
TD
Packaging
TD: 7" paper
TE: 7"plastic
embossed
103
Nominal
Resistance
2 significant
figures +
1 multiplier
J
Tolerance
J : ±5%
For further information on packaging,
please refer to Appendix A.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
11/28/16
130
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
CN-RT
anti sulfuration chip networks
(concave termination)
circuit schematic
CN1J4RT
CN2A4RT
CN2B4RT
R
1
R
2
R
3
R
4
jumper ratings
Type
CNZ1J4RT
CNZ2A4RT
50mΩ max.
Resistance
Current Rating Max. Surge Current
0.5A
1.0A
2A
3A
4A
R
1
= R
2
= R
3
= R
4
CNZ2B4RT
applications and ratings
Part
Designation
CN1J4RT
CN2A4RT
CN2B4RT
Power
T.C.R.
Rating
(x10
-6
/K)
(per Element)
0.063
0.1
0.125
Resistance Absolute
Range (Ω) Maximum
J:±5% E24 Working
Voltage
50V
100V
10~1M
200V
Maximum
Overload
Voltage
100V
200V
400V
Rated
Operating
Working
Temperature
Temperature
Range
-55°C to
+125°C
Taping & Quantity Reel
(pcs)
TD
5,000
—
—
TE
—
4,000
4,000
±200
+70°C
* Note that network resistors generate higher heat rather than single flat chip resistors even under rated power output
environmental applications
Derating Curve
100
% Rated Power
80
60
Circuit Board Application
Vcc
IC
IC
40
20
0
-60 -40 -20
-55
0
20
40
60
80 100 120 140
70
125
Ambient Temperature
(°C)
For resistors operated at an ambient temperature of 70°C or above, a
power rating shall be derated in accordance with the above derating curve.
Performance Characteristics
Parameter
Resistance
T.C.R.
Overload (Short time)
Resistance to Solder Heat
Rapid Change of Temperature
Moisture Resistance
Endurance at 70°C
High Temperature Exposure
Sulfuration Test
Requirement
∆
R
Limit
Within specified
tolerance
Within specified
T.C.R.
±2.0%
±1.0%
±1.0%
±5.0%
±5.0%
±1.0%
±5.0%
±(%+0.1Ω)
Typical
—
—
±0.50%
±0.25%
±0.50%
±1.0%
±0.50%
±0.20%
—
25°C
+25°C/-55°C and +25°C/+125°C
Rated voltage x 2.5 for 5 seconds
260°C ± 5°C, 10 seconds ± 1 second
-55°C (30 minutes) / +125°C (30 minutes), 5 cycles
40°C ± 2°C, 90-95% RH, 1000 hours, 1.5 hr ON / 0.5 hr OFF cycle
70°C ± 2°C, 1000 hours, 1.5 hr ON, 0.5 hr OFF cycle
+125°C, 1000 hours
Soaked in industrial oil with 3.5% sulfur concentration 105°C ± 3°C, 500 hours
Test Method
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
12/01/17
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
131
resistors
