Cylindrical Proximity Sensor
E2E/E2E2
A New Series of Easy-to-use
and Tough E2E/E2E2 Models
Long-size E2E2 Proximity Sen-
sor Conforms to CENELEC
• Ideal for a variety of applications.
• With a metal connector that can be tightened
securely and a cable protector.
• With an easy-to-see indicator, deeper mounting
holes, and tightening flats for wrenches.
• New 3-dia. size (sensing distance: 0.6 mm) added to
the lineup.
<READ AND UNDERSTAND THIS CATALOG>
Please read and understand this catalog before purchasing
the products. Please consult your OMRON representative if
you have any questions or comments.
Ordering Information
E2E
DC 2-wire/Pre-wired Models
Self-diagnostic
output function
Yes
Shielded
Size
M12
M18
M30
Unshielded
M12
M18
M30
No
Shielded
M8
M12
M18
M30
Unshielded
M8
M12
M18
M30
Sensing distance
NO
3 mm
7 mm
10 mm
8 mm
14 mm
20 mm
2 mm
3 mm
7 mm
10 mm
4 mm
8 mm
14 mm
20 mm
E2E-X3D1S (See note 1.)
E2E-X7D1S (See note 1.)
E2E-X10D1S (See note 1.)
E2E-X8MD1S (See note 1.)
E2E-X14MD1S (See note 1.)
E2E-X20MD1S (See note 1.)
E2E-X2D1-N (See notes 2 and 3.)
E2E-X3D1-N (See notes 1, 2 and 3.)
E2E-X7D1-N (See notes 1, 2 and 3.)
E2E-X4MD1 (See notes 2 and 3.)
E2E-X8MD1 (See notes 1, 2 and 3.)
E2E-X14MD1 (See notes 1, 2 and 3.)
E2E-X20MD1 (See notes 1, 2 and 3.
---
---
---
---
---
---
E2E-X2D2-N (See note 3.)
E2E-X3D2-N (See note 3.)
E2E-X7D2-N (See note 3.)
E2E-X4MD2
E2E-X8MD2
E2E-X14MD2
E2E-X20MD2
Model
NC
E2E-X10D1-N (See notes 1, 2 and 3.) E2E-X10D2-N
Note 1.
In addition to the above models, E2E-X@@15 models (e.g., E2E-X3D15-N), which are different in frequency from the above models, are
available.
2.
E2E models with a robotics cable are available as well. The model number of a model with a robotics cable has the suffix “-R”
(e.g., E2E-X3D1-R).
3.
Cables with a length of 5 m are also available. Specify the cable length at the end of the model number (e.g., E2E-X3D1-N 5M).
E2E/E2E2
Cylindrical Proximity Sensor
1
DC 2-wire/Connector Models
Connector
M12
Self-diagnostic
output function
Yes
Shielded
Size
M12
M18
M30
Unshielded
M12
M18
M30
No
Shielded
M8
M12
M18
M30
Unshielded
M8
M12
M18
M30
M8
Shielded
M8
Sensing
distance
3 mm
7 mm
10 mm
8 mm
14 mm
20 mm
2 mm
3 mm
7 mm
10 mm
4 mm
8 mm
14 mm
20 mm
2 mm
Model
NO
E2E-X3D1S-M1
E2E-X7D1S-M1
E2E-X10D1S-M1
E2E-X8MD1S-M1
E2E-X14MD1S-M1
E2E-X20MD1S-M1
E2E-X2D1-M1G
E2E-X3D1-M1G (See note.)
E2E-X7D1-M1G (See note.)
E2E-X10D1-M1G (See note.)
E2E-X4MD1-M1G
E2E-X8MD1-M1G (See note.)
E2E-X14MD1-M1G (See note.)
E2E-X20MD1-M1G (See note.)
E2E-X2D1-M3G
---
---
---
---
---
---
E2E-X2D2-M1G
E2E-X3D2-M1G
E2E-X7D2-M1G
E2E-X10D2-M1G
E2E-X4MD2-M1G
E2E-X8MD2-M1G
E2E-X14MD2-M1G
E2E-X20MD2-M1G
E2E-X2D2-M3G
NC
Unshielded
4 mm
E2E-X4MD1-M3G
E2E-X4MD2-M3G
Note:
In addition to the above models, E2E-X@D15-M1G models (e.g., E2E-X3D15-M1G), which are different in frequency from the above models,
are available.
DC 2-wire/Pre-wired Connector Models
Size
Shielded
M12
M18
M30
Unshielded
M12
M18
M30
Sensing distance
3 mm
7 mm
10 mm
8 mm
14 mm
20 mm
NO
Operation mode
Yes
No
Yes
No
Yes
No
Yes
Polarity
Model
E2E-X3D1-M1GJ
E2E-X3D1-M1J-T
E2E-X7D1-M1GJ
E2E-X7D1-M1J-T
E2E-X10D1-M1GJ
E2E-X10D1-M1J-T
E2E-X8MD1-M1GJ
E2E-X14MD1-M1GJ
E2E-X20MD1-M1GJ
Note 1.
A model with no polarity has a residual voltage of 5 V, which must be taken into consideration together with the interface condition (the
PLC’s ON voltage, for example) when connecting the Proximity Sensor to a load.
2.
The standard cable length is 300 mm. Models are also available with 500 mm and 1 m cables.
Connector Pin Assignments of DC 2-wire Model
The connector pin assignments of each new E2E DC 2-wire conforms to IEC947-5-2 Table III.
The following E2E models with conventional connector pin assignments are available as well.
Size
Shielded
M8
M12
M18
M30
Operation mode
NO
NC
NO
NC
NO
NC
NO
NC
Model
E2E-X2D1-M1
E2E-X2D2-M1
E2E-X3D1-M1
E2E-X3D2-M1
E2E-X7D1-M1
E2E-X7D2-M1
E2E-X10D1-M1
E2E-X10D2-M1
M30
M18
M12
Size
Unshielded
M8
Operation mode
NO
NC
NO
NC
NO
NC
NO
NC
Model
E2E-X4MD1-M1
E2E-X4MD2-M1
E2E-X8MD1-M1
E2E-X8MD2-M1
E2E-X14MD1-M1
E2E-X14MD2-M1
E2E-X20MD1-M1
E2E-X20MD2-M1
2
E2E/E2E2
Cylindrical Proximity Sensor
DC 3-wire/Pre-wired Models
Size
Sensing
Output
distance configuration
NPN NO
NPN NC
PNP NO
PNP NC
4 dia. 0.8 mm
NPN NO
NPN NC
PNP NO
PNP NC
M5
1 mm
NPN NO
NPN NC
PNP NO
PNP NC
5.4
dia.
1 mm
NPN NO
NPN NC
PNP NO
PNP NC
M8
1.5 mm
NPN NO
NPN NC
PNP NO
PNP NC
M12
2 mm
NPN NO
NPN NC
PNP NO
PNP NC
M18
5 mm
NPN NO
NPN NC
PNP NO
PNP NC
M30
10 mm
NPN NO
NPN NC
PNP NO
PNP NC
Model
E2E-CR6C1
E2E-CR6C2
E2E-CR6B1
E2E-CR6B2
E2E-CR8C1
(See notes 1 and 2.)
E2E-CR8C2
E2E-CR8B1
E2E-CR8B2
E2E-X1C1
(See notes 1 and 2.)
E2E-X1C2
E2E-X1B1
E2E-X1B2
E2E-C1C1
(See notes 1 and 2.)
E2E-C1C2
E2E-C1B1
E2E-C1B2
E2E-X1R5E1
(See notes 1 and 2.)
E2E-X1R5E2
E2E-X1R5F1
E2E-X1R5F2
E2E-X2E1 (See notes 1,
2, 3, and 4.)
E2E-X2E2
(See notes 3 and 4.)
E2E-X2F1
E2E-X2F2
E2E-X5E1 (See notes 1,
2, 3, and 4.)
E2E-X5E2
(See notes 3 and 4.)
E2E-X5F1
E2E-X5F2
E2E-X10E1 (See notes
1, 2, 3, and 4.)
E2E-X10E2
(See notes 3 and 4.)
E2E-X10F1
E2E-X10F2
Size
Un-
M8
shielded
Sensing
Output
distance configuration
2 mm
NPN NO
NPN NC
PNP NO
PNP NC
Model
E2E-X2ME1
(See note 2.)
E2E-X2ME2
E2E-X2MF1
E2E-X2MF2
E2E-X5ME1 (See notes
1, 2, 3, and 4.)
E2E-X5ME2 (See notes
3 and 4.)
E2E-X5MF1
E2E-X5MF2
E2E-X10ME1 (See notes
1, 2, 3, and 4.)
E2E-X10ME2
(See notes 3 and 4.)
E2E-X10MF1
E2E-X10MF2
E2E-X18ME1 (See notes
1, 2, 3, and 4.)
E2E-X18ME2
(See notes 3 and 4.)
E2E-X18MF1
E2E-X18MF2
Shielded 3 dia. 0.6 mm
M12
5 mm
NPN NO
NPN NC
PNP NO
PNP NC
M18
10 mm
NPN NO
NPN NC
PNP NO
PNP NC
M30
18 mm
NPN NO
NPN NC
PNP NO
PNP NC
Note 1.
Cables with a length of 5 m are also available. Specify the
cable length at the end of the model number (e.g., E2E-X2E1
5M).
2.
Models with a robotics cable are also available. These
models are E2E-X@E1-R (e.g., E2E-X5E1-R).
3.
Models with a different frequency are also available. These
models are E2E-X@E@5 (e.g., E2E-X5E15).
4.
These models have e-CON connectors (0.3 m cable length),
which is indicated by the suffix “-ECON” (e.g., E2E-X2E1-
ECON).
AC 2-wire/Pre-wired Models
Size
Shielded M8
M12
Sensing
distance
1.5 mm
2 mm
Operation
mode
NO
NC
NO
NC
M18
5 mm
NO
NC
M30
10 mm
NO
NC
Un-
M8
shielded
M12
2 mm
5 mm
NO
NC
NO
NC
M18
10 mm
NO
NC
M30
18 mm
NO
NC
Model
E2E-X1R5Y1
E2E-X1R5Y2
E2E-X2Y1
(See notes 1 and 2.)
E2E-X2Y2
E2E-X5Y1
(See notes 1 and 2.)
E2E-X5Y2
E2E-X10Y1
(See notes 1 and 2.)
E2E-X10Y2
E2E-X2MY1
E2E-X2MY2
E2E-X5MY1
(See notes 1 and 2.)
E2E-X5MY2
E2E-X10MY1
(See note 1.)
E2E-X10MY2
E2E-X18MY1
(See note 1.)
E2E-X18MY2
Note 1.
Models with a different frequency are also available. These
models are E2E-X@Y@5 (e.g., E2E-X5Y15).
2.
Cables with a length of 5 m are also available. Specify the
cable length at the end of the model number (e.g., E2E-X2Y1
5M).
E2E/E2E2
Cylindrical Proximity Sensor
3
DC 3-wire/Connector Models
Connector
M12
Size
Shielded M8
Sensing
Output
distance configuration
1.5 mm
NPN NO
NPN NC
PNP NO
PNP NC
M12
2 mm
NPN NO
NPN NC
PNP NO
PNP NC
M18
5 mm
NPN NO
NPN NC
PNP NO
PNP NC
M30
10 mm
NPN NO
NPN NC
PNP NO
PNP NC
Un-
shielded
M8
2 mm
NPN NO
NPN NC
PNP NO
PNP NC
M12
5 mm
NPN NO
NPN NC
PNP NO
PNP NC
M18
10 mm
NPN NO
NPN NC
PNP NO
PNP NC
M30
18 mm
NPN NO
NPN NC
PNP NO
PNP NC
M8-3 pin
Shielded 4 dia. 0.8 mm
NPN NO
NPN NC
PNP NO
PNP NC
M5
1 mm
NPN NO
NPN NC
PNP NO
PNP NC
M8
Shielded M8
1.5 mm
NPN NO
NPN NC
PNP NO
PNP NC
Un-
shielded
M8
2 mm
NPN NO
NPN NC
PNP NO
PNP NC
Model
E2E-X1R5E1-M1
E2E-X1R5E2-M1
E2E-X1R5F1-M1
E2E-X1R5F2-M1
E2E-X2E1-M1
E2E-X2E2-M1
E2E-X2F1-M1
E2E-X2F2-M1
E2E-X5E1-M1
E2E-X5E2-M1
E2E-X5F1-M1
E2E-X5F2-M1
E2E-X10E1-M1
E2E-X10E2-M1
E2E-X10F1-M1
E2E-X10F2-M1
E2E-X2ME1-M1
E2E-X2ME2-M1
E2E-X2MF1-M1
E2E-X2MF2-M1
E2E-X5ME1-M1
E2E-X5ME2-M1
E2E-X5MF1-M1
E2E-X5MF2-M1
E2E-X10ME1-M1
E2E-X10ME2-M1
E2E-X10MF1-M1
E2E-X10MF2-M1
E2E-X18ME1-M1
E2E-X18ME2-M1
E2E-X18MF1-M1
E2E-X18MF2-M1
E2E-CR8C1-M5
E2E-CR8C2-M5
E2E-CR8B1-M5
E2E-CR8B2-M5
E2E-X1C1-M5
E2E-X1C2-M5
E2E-X1B1-M5
E2E-X1B2-M5
E2E-X1R5E1-M3
E2E-X1R5E2-M3
E2E-X1R5F1-M3
E2E-X1R5F2-M3
E2E-X2ME1-M3
E2E-X2ME2-M3
E2E-X2MF1-M3
E2E-X2MF2-M3
AC 2-wire/Connector Models
Size
Shielded M12
M18
M30
Un-
M12
shielded
M18
M30
Sensing
distance
2 mm
5 mm
10 mm
5 mm
10 mm
18 mm
Operation
mode
NO
NC
NO
NC
NO
NC
NO
NC
NO
NC
NO
NC
Model
E2E-X2Y1-M1
E2E-X2Y2-M1
E2E-X5Y1-M1
E2E-X5Y2-M1
E2E-X10Y1-M1
E2E-X10Y2-M1
E2E-X5MY1-M1
E2E-X5MY2-M1
E2E-X10MY1-M1
E2E-X10MY2-M1
E2E-X18MY1-M1
E2E-X18MY2-M1
AC/DC 2-wire/Pre-wired Models
Size
Shielded M12
M18
M30
Sensing
distance
3 mm
7 mm
10 mm
Operation
mode
NO
Model
E2E-X3T1
E2E-X7T1
(See note 2.)
E2E-X10T1
Note 1.
These models do not conform to CE standards.
2.
Cables with a length of 5 m are also available as standard
models. Specify the cable length at the end of the model
number (e.g., E2E-X7T1 5M).
4
E2E/E2E2
Cylindrical Proximity Sensor
E2E2
DC 2-wire/Pre-wired Models
Size
Shielded
M12
M18
M30
Unshielded
M12
M18
M30
3 mm
7 mm
10 mm
8 mm
14 mm
20 mm
Sensing distance
NC
NO (See note.)
NC
NO (See note.)
NC
NO (See note.)
NC
NO (See note.)
NC
NO (See note.)
NC
Operation mode
NO (See note.)
E2E2-X3D1
E2E2-X3D2
E2E2-X7D1
E2E2-X7D2
E2E2-X10D1
E2E2-X10D2
E2E2-X8MD1
E2E2-X8MD2
E2E2-X14MD1
E2E2-X14MD2
E2E2-X20MD1
E2E2-X20MD2
Model
Note:
In addition to the above models, E2E-X@D15 models (e.g., E2E-X3D15), which are different in frequency from the above models, are
available.
DC 3-wire/Pre-wired Models
Size
Shielded
M12
2 mm
Sensing distance
Output configuration
NPN NO
NPN NC
PNP NO
PNP NC
M18
5 mm
NPN NO
NPN NC
PNP NO
PNP NC
M30
10 mm
NPN NO
NPN NC
PNP NO
PNP NC
Unshielded
M12
5 mm
NPN NO
NPN NC
PNP NO
PNP NC
M18
10 mm
NPN NO
NPN NC
PNP NO
PNP NC
M30
18 mm
NPN NO
NPN NC
PNP NO
PNP NC
E2E2-X2C1
E2E2-X2C2
E2E2-X2B1
E2E2-X2B2
E2E2-X5C1
E2E2-X5C2
E2E2-X5B1
E2E2-X5B2
E2E2-X10C1
E2E2-X10C2
E2E2-X10B1
E2E2-X10B2
E2E2-X5MC1
E2E2-X5MC2
E2E2-X5MB1
E2E2-X5MB2
E2E2-X10MC1
E2E2-X10MC2
E2E2-X10MB1
E2E2-X10MB2
E2E2-X18MC1
E2E2-X18MC2
E2E2-X18MB1
E2E2-X18MB2
Model
E2E/E2E2
Cylindrical Proximity Sensor
5
京公网安备 11010802033920号
EEWORLD
