ACCESSORIES
DIN RAIL & MOUNTING
DIN35 x 7.5
DIN35 x 15
DIN RAIL
HIGHLIGHTS
FEATURES
•
Altech DIN Rails comply with
DIN EN60715, EN50022,
EN50035, EN50045
standards
•
Easy mounting of terminal
blocks, power supplies and
other control components
and devices into panel
•
Space saving
•
Reduces labor
•
35mm, 32mm and 15mm
versions
•
1m and 2m standard length
•
Custom length available
•
Perforated, unperforated
35 mm x
7.5 mm deep
35 mm x
15 mm deep
Zinc Plated Steel
Type
Cat. No.
Perforated
Unperforated
2511120
2511120/1M
2511110
2511110/1M
Stainless Steel
Type
Cat. No.
Perforated
Unperforated
Aluminum
Type
Perforated
Unperforated
2511125
2511125/1M
2511115
2511115/1M
Cat. No.
2511121
2511121/1M
2511111
2511111/1M
Length
2m
1m
2m
1m
Length
2m
1m
2m
1m
Length
2m
1m
2m
1m
Std. Pk.
20
40
20
40
Std. Pk.
20
40
20
40
Std. Pk.
20
40
20
40
Zinc Plated Steel
Type
Cat. No.
Perforated
CA701-15/S-2M
CA701-15/S
Unperforated CA701-15-2M
CA701-15
Length
2m
1m
2m
1m
Std. Pk.
20
40
20
40
MATERIAL
•
Zinc-plated steel
•
35x7.5mm
•
35x15mm
•
32mm
•
15mm
•
Aluminum
•
35x7.5mm
•
Stainless Steel
(Type AISI 304)
•
35x7.5mm
Dimensions
Preforated Steel and Stainless
18
Preforated Steel
18
Preforated Aluminum
25.4
12.7
Unpreforated Steel
4.6
Unpreforated
106
Altech Corp.
®
• 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490
ACCESSORIES
DIN RAIL & MOUNTING
MOUNTING ACCESSORIES
HIGHLIGHTS
SUPPORT BRACKETS
•
Elevate DIN Rail away
SUPPORT BRACKETS
CA603
Ø7mm (.28in)
M6
48mm
(1.89in)
18mm
(.71in)
Ø6mm
(.24 in.)
Slot 6x15mm
(.24x.59 in.)
TSTW
M6
from panel
•
Easier mounting of
components
•
Suitable for all mounting rails
•
Increase wiring access
•
45° version for improved
visibility
•
Straight brackets available
in 3 heights:
•
1”
•
2”
•
3”
H
60mm (2.36in)
74mm (2.91in)
52m
m(
18mm(.71in.)
2.0
5 in
.)
74m
m(
2.9
8 in
.)
Cat. No.
CA603
Std. Pk.
25
Cat. No.
CA703
CA803
CA903
Height
1 in.
2 in.
3 in.
Std. Pk.
25
25
25
MOUNTING
•
Brackets mount with 2
screws to any panel or flat
surface
•
Tapped center hole for DIN
Rail mounting
MATERIAL
•
Zinc-plated yellow
chromated Steel
UNIVERSAL DIN CLIPS
D35CLIP
CMTB35
CA902
Ø 4.3 x 4
25.4
18
14.5
Ø 5.5 x 2
58
UNIVERSAL DIN CLIPS
•
Clips on to any 35mm/32mm
DIN Rail
•
Flexible mounting solution
•
Mount any component on
32mm/35mm DIN Rail
•
Various mounting hole
solutions
•
Material: zinc-plated steel,
Polyamide 66
Cat. No.
Mounting Hole Std. Pk.
D35CLIP-M4
M4
100
D35CLIP-M5
M5
100
Cat. No.
CMTB35
Mounting Hole Std. Pk. Cat. No.
2x4.4 mm
50
CA902
2x5.5 mm
Std. Pk.
100
SPACER
CASP
CDL4U SPACER
SPACER
•
Increases creepage and
clearance distance between
terminal blocks
•
Segregate different groups
of terminal blocks
block for visual identification
Make entire terminal block
assembly shock-proof
WARNING LABELS
•
Mounted on top of terminal
•
Cat. No.
CASP
Dimensions
29 x 43 x 8 mm
Std. Pk.
50
Cat. No.
CDL4USP
Dimensions
54 x 55.5 x 6 mm
Std. Pk.
50
WARNING LABELS
Cat. No.
WLX2.5
WLX4
WLX6
WLX10
SWL4
SWL10
Terminal Blocks
CX2.5 Series, CXDL2.5, CXK2.5, CXM2.5
CX4 Series, CXF Series, CXK4
CX6 Series, CXDB Series
CX10 Series
CTS4U-N, CDB4, CMDB4
CTS6U, CDB6U, CMDB6
Std. Pk.
Pack Strips
1
20
1
20
1
20
1
20
1
20
1
20
Tags
100
100
100
100
100
100
108
Altech Corp.
®
• 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490
ACCESSORIES
MARKING
GROUP MARKERS
HIGHLIGHTS
FEATURES
•
Group identification
•
Holders fit standard
MT8
•
•
•
DIN RAIL MOUNT
GMH6
GMH7
•
marking tags
GMH6, GMH7 mounted
directly on DIN Rail
GMH1, GMH2, GMH3,
GMH4, GMH5, GMH8
mounted on End Stops
MT1G, MT2G, can be
used with all these holders
or can be directly
mounted on all end stops
Material: Polyamide 66
Cat. No.
GMH6
Dimensions
46.5 x 44.5 x 9.5mm
Std. Pk.
50
Cat. No.
GMH7
Dimensions
Std. Pk.
46.5 x 44.5 x 19.5mm
50
MOUNT ON END STOP
Suitable for
CA602
GMH1
Suitable for
CA802
GMH4
Suitable for
CA702
GMH5
Cat. No.
GMH1
Dimensions
15.8 x 14.6 x 8mm
GMH2 / GMH3
Std. Pk.
100
Cat. No.
GMH4
Dimensions
16.2 x 14 x 8mm
GMH8 / GMH8N
Std. Pk.
100
Cat. No.
GMH5
Dimensions
13.7 x 14 x 8mm
MTG1 / MTG2
Std. Pk.
100
Suitable for
CA702 (GMH2)
CA802 (GMH3)
Suitable for
CA103
Mountable
on all End Clamps
Cat. No.
GMH2
GMH3
Dimensions
23.2 x 14 x 8mm
23 x 14 x 8mm
Std. Pk.
100
100
Std. Pk.
Dimensions
Cat. No.
100
GMH8 44.65 x 31.10 x 10mm
100
GMH8N 44.65 x 31.10 x 6mm
Cat. No.
MTG1
MTG2
Dimensions
4.3 x 34 x 17.8mm
4.3 x 34 x 8mm
Std. Pk.
50
50
Suitable for
CXDL Series
TM5
Cat. No.
TM5
Dimensions
38 x 17 x 5mm
Std. Pk.
50
110
Altech Corp.
®
• 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490
