DUAL-IN-LINE
SOCKETS
SERIES 210...101 • MIL
-
DTL
-
83734 APPROVED, SOLDER TAIL • CLOSED FRAME
•
Sockets are XY stackable
•
Socket pins feature closed end construction
B
.015-.025
.010 .018
•
.110
.165
.146
.095
•
•
•
•
.125
.020 DIA.
See page 131 for Insulator Details
eliminating any solder wicking problems
Packaged in tubes compatible with automatic
insertion equipment
Hi-Rel, 4- nger BeCu #30 contact is rated at
3 amps. See page 253 for details
Series 210 uses MM #1001 pins. See page 165
for details
Insulators are high temperature thermoplastic,
suitable for all soldering operations
For Electrical, Mechanical and Environmental
Data, see page 264 for details
Total number
of pins
A
B
.100
C
Quantity
per tube
ORDERING INFORMATION
Mill-Max Part Number
210-XX-306-41-101000
210-XX-308-41-101000
210-XX-314-41-101000
210-XX-316-41-101000
210-XX-318-41-101000
210-XX-320-41-101000
210-XX-422-41-101000
210-XX-624-41-101000
210-XX-628-41-101000
210-XX-632-41-101000
210-XX-636-41-101000
210-XX-640-41-101000
210-XX-964-41-101000
A
0.3
0.4
0.7
0.8
0.9
1.0
1.1
1.2
1.4
1.6
1.8
2.0
3.2
B
0.3
0.3
0.3
0.3
0.3
0.3
0.4
0.6
0.6
0.6
0.6
0.6
0.9
C
0.4
0.4
0.4
0.4
0.4
0.4
0.5
0.7
0.7
0.7
0.7
0.7
1.0
Military Part Number
M83734/1-YYY
M83734/2-YYY
M83734/3-YYY
M83734/4-YYY
M83734/5-YYY
M83734/13-YYY
M83734/6-YYY
M83734/8-YYY
M83734/7-YYY
M83734/17-YYY
M83734/9-YYY
M83734/10-YYY
M83734/15-YYY
6
8
14
16
18
20
22
24
28
32
36
40
64
67
50
28
25
22
20
18
16
14
10
11
8
6
XX=Plating Code
See Below
SEE PAGE 103 FOR COMPLETE MIL DTL 83734 QPL
SPECIFY MILL MAX PLATING CODE XX =
FOR MILITARY PLATING CODE YYY =
6 PIN ONLY YYY =
32 PIN ONLY YYY =
Sleeve (Pin)
Contact (Clip)
33
031
025
013
30
µ”
min. Au
30
µ”
min. Au
83
032
026
014
300
µ”
Sn/Pb
30
µ”
min. Au
88
033
027
015
300
µ”
Sn/Pb
100
µ”
Sn/Pb
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 101 | IC SOCKETS / TO SOCKETS
