Product data sheet
Characteristics
ZCMD25
limit switch body ZCMD - 1NO+1NC - silver -
slow-break
Main
Range of product
Series name
Device short name
Body type
Number of poles
OsiSense XC
Standard format
ZCMD
Plug-in body
2
Complementary
Product or component type
Design
Product compatibility
Associated head
Limit switch body
Miniature
XCMD
ZCE01
ZCE02
ZCE06
ZCE07
ZCE08
ZCE09
ZCE10
ZCE11
ZCE13
ZCE14
ZCE21
ZCE24
ZCE27
ZCE28
ZCE29
ZCE62
ZCE63
ZCE64
ZCE65
ZCE66
ZCE67
ZCEF0
ZCEF2
ZCEG1
ZCMC25L1
ZCMC25L10
ZCMC25L2
ZCMC25L3
ZCMC25L5
ZCMC25L7
Zamak
Plug-in without pre-cabled connection
1 NO + 1 NC
Zb
Slow-break, break before make
Silver plated contacts
With
6 m/min
Associated connec component
Body material
Electrical connection
Contacts type and composition
Contacts insulation form
Contacts operation
Contacts material
Positive opening
Minimum actuation speed
Feb 19, 2018
1
The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.
Contact code designation
B300; AC-15(Ue = 240 V, Ie = 1.5 A) conforming to EN/IEC 60947-5-1 appendix
A
R300; DC-13(Ue = 250 V, Ie = 0.1 A) conforming to EN/IEC 60947-5-1 appendix
A
300 V 3 CSA C22-2 No 14
300 V 3 UL 508
400 V 3 IEC 60947-5-1
< 25 mOhm IEC 60255-7 category 3
4 kV IEC 60664
4 kV IEC 60947-1
6 A cartridge fuse gG
5000000 cycles DC-13, 120 V 3 W, < 60 cyc/mn, load factor: 0.5 conforming to
IEC 60947-5-1 appendix C
5000000 cycles DC-13, 24 V 4 W, < 60 cyc/mn, load factor: 0.5 conforming to
IEC 60947-5-1 appendix C
5000000 cycles DC-13, 48 V 3 W, < 60 cyc/mn, load factor: 0.5 conforming to
IEC 60947-5-1 appendix C
30 mm
50 mm
16 mm
30 mm
52 mm
16 mm
Ui rated insulation voltage
Resistance across terminals
Uimp rated imp wstdvoltage
Short circuit protection
Electrical durability
Width
Height
Depth
CAD overall width
CAD overall height
CAD overall depth
Environment
Ambient air temp for storage
-40...70 °C
2
