Datasheet
D/A Converters
Standard 8bit 10ch/12ch
BH2223FV
BH2221FV
Key Specifications
VCC Power Source Voltage Range: 2.7V to 5.5V
VDD Power Source Voltage Range: 2.7V to V
CC
Current Consumption:
BH2223FV:
1.1mA(Typ)
BH2221FV:
1.6mA(Typ)
±1.0LSB
Differential Non Linearity Error:
Integral Non Linearity Error:
±1.5LSB
Output Current Performance:
±1.0mA
Settling Time:
100µs(Min)
Data Transfer Frequency:
10MHz(Max)
Action Temperature Range:
-20°C to +85°C
General Description
BH2223FV and BH2221FV are high performance 8bit
R-2R-type D/A converters with 10 and 12 channel
outputs, respectively.
A built-in RESET function ensures that the output
voltage at all channels is LOW during power up and a
broad power supply voltage range (2.7V - 5.5V)
provides design flexibility.
Features
■
■
■
Built-in RESET function
High speed output response characteristics
3-line serial interface
Packages
Applications
DVCs, DSCs, DVDs, CD-Rs, CD-RWs
W(Typ) x D(Typ) x H(Max)
SSOP-B16
5.00mm x 6.40mm x 1.35mm
SSOP-B20
6.50mm x 6.40mm x 1.45mm
Lineup
Number of channels
10ch
12ch
Input method
CMOS
Data latch method
LD method
Package
SSOP-B16 Reel of 2500
SSOP-B20 Reel of 2500
Orderable Part Number
BH2223FV-E2
BH2221FV-E2
○Product
structure：Silicon monolithic integrated circuit
www.rohm.com
© 2015 ROHM Co., Ltd. All rights reserved.
TSZ22111・14・001
○This
product has no designed protection against radioactive rays
1/15
TSZ02201-0M2M0GZ15060-1-2
06.Nov.2015 Rev.001
BH2223FV
BH2221FV
Pin Descriptions / Block Diagrams
(BH2223FV)
Terminal
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
(BH2221FV)
Terminal
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Terminal
name
NC
AO3
AO4
AO5
AO6
AO7
AO8
AO9
AO10
VDD
VCC
AO11
AO12
NC
LD
CLK
DI
AO1
AO2
GND
D/A converter standard
power source terminal
Power source terminal
Analog output terminal
Not connected yet
Serial data
Serial clock input terminal
Serial data input terminal
Analog output terminal
Ground terminal
Figure 2. BH2221FV
AO10
9
VDD
10
AO5
4
AO6
5
AO7
6
AO8
7
AO9
8
Analog output terminal
NC
1
VCC
VDD
VDD
Terminal
name
AO2
AO3
AO4
AO5
AO6
AO7
AO8
AO9
VCC
AO10
NC
LD
CLK
DI
AO1
GND
TOP VIEW
Function
AO2
AO3
Analog output terminal
AO4
AO5
AO6
Power source terminal
Analog output terminal
Not connected yet
Serial data load input terminal
Serial clock input terminal
Serial data input terminal
Analog output terminal
Ground terminal
Figure 1. BH2223FV
AO8
AO9
7
8
VCC
1
2
3
4
5
VCC
VCC
R2R
R2R
R2R
R2R
R2R
R2R
R2R
R2R
REG
VCC
VCC
16
GND
REG
R2R
VCC
VCC
VCC
REG
VCC
15
AO1
14
VCC
REG
VCC
VCC
Serial
Interface
VCC
DI
REG
VCC
13
CLK
VCC
REG
VCC
AO7
6
VCC
Power ON
Reset
VCC
VCC
12
1
11
LD
NC
REG
VCC
REG
VCC
REG
R2R
10
AO10
9
VCC
REG
VCC
Function
Not connected yet
TOP VIEW
20
GND
R2R
R2R
R2R
R2R
R2R
R2R
R2R
R2R
REG
REG
REG
REG
REG
REG
VDD
VCC
AO3
2
AO4
3
REG
VDD
R2R
R2R
VCC
VCC
19
AO2
18
AO1
17
VCC
VDD
REG
VCC
VCC
VDD
VCC
VDD
Serial
Interface
DI
16
CLK
VCC
VDD
VCC
VDD
Power ON
Reset
VCC
15
14
LD
NC
VCC
VDD
REG
REG
REG
VDD
R2R
R2R
13
AO12
12
AO11
11
VCC
VCC
VDD
REG
VCC
www.rohm.com
© 2015 ROHM Co., Ltd. All rights reserved.
TSZ22111・15・001
2/15
TSZ02201-0M2M0GZ15060-1-2
06.Nov.2015 Rev.001
BH2223FV
BH2221FV
Absolute Maximum Ratings (Ta=25°C)
Parameter
Power Source Voltage
Terminal Voltage
Storage Temperature Range
Power Dissipation
Symbol
V
CC
V
IN
Tstg
Pd
Rating
-0.3 to +7.0
-0.3 to V
CC
-55 to +125
0.65
(Note 1)
0.45
(Note 2)
Unit
V
V
°C
W
W
BH2221FV
BH2223FV
Remark
(Note 1) Derated at 6.5mW/°C at Ta>25°C
(Note 2) Derated at 4.5mW/°C at Ta>25°C
Caution: Operating the IC over the absolute maximum ratings may damage the IC. The damage can either be a short circuit between pins or an open circuit
between pins and the internal circuitry. Therefore, it is important to consider circuit protection measures, such as adding a fuse, in case the IC is operated over
the absolute maximum ratings.
Recommended Operating Conditions (Ta=25°C)
Rating
Parameter
VCC Power Source Voltage
VDD Power Source Voltage
Terminal Input Voltage Range
Analog Output Current
Action Temperature Range
Serial Clock Frequency
Limit Load Capacitance
Symbol
V
CC
V
DD
V
IN
I
OUT
Topr
f
SCLK
C
L
Min
2.7
2.7
0
-1.0
-20
-
-
Typ
-
-
-
0
-
1.0
-
Max
5.5
V
CC
V
CC
+1.0
+85
10.0
0.1
Unit
V
V
V
mA
°C
MHz
µF
(Note 3)
(Note 3)
Remark
-
-
-
-
-
(Note 3) Set the power source voltage so that V
CC
≥ V
DD
.
Electrical Characteristics
(Unless otherwise specified, V
CC
=3.0V, V
DD
=3.0V, R
L
=OPEN, C
L
=0pF, Ta=25°C)
Parameter
Symbol
Min
-
-
-
GND
0.8V
CC
-10
GND
GND
V
CC
-0.1
V
CC
-0.3
-1.0
-1.5
100
-
Limit
Typ
0.6
1.0
1.1
-
-
-
-
-
-
-
-
-
-
1.9
Max
1.5
2.0
2.5
0.2V
CC
V
CC
+10
0.1
0.3
V
CC
V
CC
+1.0
+1.5
-
-
Unit
Conditions
<Current Consumption> CLK=1MHz, 80H Setting
VCC System
I
CC
VDD System
I
DD
VCC System
I
CC
<Logic Interface>
L input Voltage
V
IL
H input Voltage
V
IH
Input Current
I
IN
<Buffer Amplifier>
V
ZS1
Output Zero Scale Voltage
V
ZS2
V
FS1
Output Full Scale Voltage
V
FS2
<D/A Converter Precision>
Differential Non Linearity Error
DNL
Integral Non Linearity Error
INL
VCC Power Source Voltage Rise
t
rVCC
Time
Power ON Reset Release Voltage
V
POR
mA
mA
mA
V
V
µA
V
V
V
V
LSB
LSB
µs
V
BH2221FV
BH2223FV
00H setting, at no load
00H setting, I
OH
=1.0mA
FFH setting, at no load
FFH Setting, I
OL
=1.0mA
Input code 02H to FDH
Input code 02H to FDH
V
CC
=0V to 2.7V
www.rohm.com
© 2015 ROHM Co., Ltd. All rights reserved.
TSZ22111・15・001
3/15
TSZ02201-0M2M0GZ15060-1-2
06.Nov.2015 Rev.001
BH2223FV
Timing Chart
BH2221FV
(V
CC
= 3.0V, V
DD
= 3.0V, R
L
= OPEN, C
L
= 0pF, Ta = 25°C, unless otherwise specified.)
Parameter
CLK L Level Time
CLK H Level Time
DI Setup Time
DI Hold Time
LD Setup Time
LD Hold Time
LD H Level Time
Output Settling Time
Symbol
t
CLKL
t
CLKH
t
sDI
t
hDI
t
sLD
t
hLD
t
LDH
t
OUT
Limit
Min
50
50
20
40
50
50
50
-
Typ
-
-
-
-
-
-
-
-
Max
-
-
-
-
-
-
-
100
Unit
ns
ns
ns
ns
ns
ns
ns
µs
Conditions
C
L
=50pF, R
L
=10kΩ
t
CLKL
t
CLKH
0.8V
CC
0.2V
CC
CLK
DI
C
L
K
D
I
L
D
LAST DATA
t
sDI
t
hDI
t
sLD
0.8V
CC
0.2V
CC
t
LDH
t
hLD
0.8V
CC
0.2V
CC
90%
10%
t
OUT
LD
Analog output
Figure 3
www.rohm.com
© 2015 ROHM Co., Ltd. All rights reserved.
TSZ22111・15・001
4/15
TSZ02201-0M2M0GZ15060-1-2
06.Nov.2015 Rev.001
BH2223FV
BH2221FV
Typical Performance Curves
1.8
CC
CIRCUIT CURRENT:ICC[mA]
0.9
Circuit Current : I
DD
[mA]
CIRCUIT CURRENT:ICC[mA]
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0.0
0.0
1.0
2.0
3.0
4.0
5.0
6.0
Supply Voltage : V
CC
[V]
SUPPLY VOLTAGE:VCC[V]
Figure 4. Circuit Current vs Supply Voltage
(VCC Active Current Consumption)
-20°C
25°C
85°C
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
0.0
1.0
2.0
3.0
4.0
5.0
6.0
Supply Voltage : V
DD
[V]
SUPPLY VOLTAGE:VCC[V]
Figure 5. Circuit Current vs Supply Voltage
(VDD Active Current Consumption)
85°C
25°C
-20°C
Circuit Current : I
[mA]
V
CC
or V
DD
=3.0V
Differential Non Linearity Error : DNL [LSB]
Output
OUTPUT
Voltage : V
OUT
[mV]
VOLTAGE:Vo[mV]
3000
2500
2000
1500
1000
500
0
0
64
128
192
Input Code [dec]
0.4
V
CC
or V
DD
=3.0V
0.3
0.2
0.1
0.0
-0.1
-0.2
-0.3
-0.4
0
64
128
192
256
Input Code [dec]
DNL [ LSB]
INPUT CODE [dec]
Figure 6. Output Voltage vs Input Code
INPUT CODE [dec]
Figure 7. Differential Non Linearity Error vs Input Code
www.rohm.com
© 2015 ROHM Co., Ltd. All rights reserved.
TSZ22111・15・001
5/15
TSZ02201-0M2M0GZ15060-1-2
06.Nov.2015 Rev.001
