1. DIMENSIONING AND TOLERANCING PER ANSI Y14.5M, 1982.
2. CONTROLLING DIMENSION: MILLIMETER.
3. MOLD GATE BURRS SHALL NOT EXCEED 0.13 MM PER SIDE.
4. LEADFRAME TO MOLDED BODY OFFSET IN HORIZONTAL
AND VERTICAL SHALL NOT EXCEED 0.08 MM.
5. DIMENSIONS A AND B EXCLUSIVE OF MOLD GATE BURRS.
6. NO MOLD FLASH ALLOWED ON THE TOP AND BOTTOM LEAD
SURFACE.
DIM
A
b
c
D
E
e
e1
L
H
E
q
MILLIMETERS
NOM
MAX
1.05
1.10
0.30
0.35
0.15
0.20
3.05
3.10
1.65
1.70
0.65 BSC
0.55 BSC
0.28
0.35
0.42
1.80
1.90
2.00
5° NOM
MIN
1.00
0.25
0.10
2.95
1.55
MIN
0.039
0.010
0.004
0.116
0.061
INCHES
NOM
0.041
0.012
0.006
0.120
0.065
0.025 BSC
0.022 BSC
0.011
0.014
0.071
0.075
5° NOM
MAX
0.043
0.014
0.008
0.122
0.067
0.017
0.079
e1
e
b
c
A
0.05 (0.002)
2.032
0.08
0.457
0.018
SOLDERING FOOTPRINT*
2.032
0.08
0.635
0.025
1.727
0.068
0.457
0.018
0.711
0.028
0.66
0.026
SCALE 20:1
mm
inches
0.178
0.007
0.711
0.028
0.66
0.026
SCALE 20:1
mm
inches
Basic
Style 4
*For additional information on our Pb−Free strategy and soldering
details, please download the ON Semiconductor Soldering and
Mounting Techniques Reference Manual, SOLDERRM/D.
