PS2703-1-V datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> PS2703-1-V

PS2703-1-V: Description1 CHANNEL TRANSISTOR OUTPUT OPTOCOUPLER; CategoryLED optoelectronic/LED; File Size235KB，11 Pages; ManufacturerCEL; Websitehttp://www.cel.com/

Download Datasheet Parametric View All

PS2703-1-V Overview

1 CHANNEL TRANSISTOR OUTPUT OPTOCOUPLER

PS2703-1-V Parametric

Parameter Name	Attribute value
Maximum operating temperature	100 Cel
Minimum operating temperature	-55 Cel
Number of functions	1
Processing package description	SOP-4
state	ACTIVE
terminal coating	TIN LEAD
structure	SINGLE
Optoelectronic device type	TRANSISTOR OUTPUT
Minimum Coll-emtr Bkdn voltage	120 V
Maximum collector dark current	100 nA
Rated current transfer ratio	150 %
Maximum input control current	50 mA
Maximum insulation voltage	3750 V

Preview

Download Datasheet

View All

PHOTOCOUPLER

PS2703-1

HIGH ISOLATION VOLTAGE

HIGH COLLECTOR TO EMITTER VOLTAGE TYPE

−NEPOC

SOP MULTI PHOTOCOUPLER

DESCRIPTION

The PS2703-1 is an optically coupled isolator containing a GaAs light emitting diode and an NPN silicon

phototransistor.

This is mounted in a plastic SOP (Small Outline Package) for high density applications.

This package has shield effect to cut off ambient light.

Series−

FEATURES

• High isolation voltage (BV = 3 750 Vr.m.s.)

• High collector to emitter voltage (V

CEO

= 120 V)

• SOP (Small Outline Package) type

• Each isolated channel per package

• High-speed switching (t

, t

= 10

s TYP.)

• Taping product number: PS2703-1-F3, F4

• UL approved: File No. E72422 (S)

• VDE0884 approved (Option)

APPLICATIONS

• Hibrid IC

• Telephone/FAX

• FA/OA equipment

• Programmable logic controllers

• Power supply

ORDERING INFORMATION (Solder Contains Lead)

Part Number

PS2703-1

Package

4-pin SOP

Safety Standard Approval

Standard specification products

• UL approved

PS2703-1-V

4-pin SOP

VDE0884 specification products (Option)

ORDERING INFORMATION (Pb-Free)

Part Number

PS2703-1-A

Package

4-pin SOP

Safety Standard Approval

Standard specification products

• UL approved

PS2703-1-V-A

4-pin SOP

VDE0884 specification products (Option)

Document No. PN10242EJ01V0DS (1st edition)

(Previous No. P11308EJ6V0DS00)

Date Published February 2003 CP(K)

The mark

shows major revised points.
