SY100EL91ZC datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Drivers and interfaces> SY100EL91ZC

SY100EL91ZC: Description3.3V TRIPLE LVPECL-to-ECL OR LVPECL-to-LVECL TRANSLATOR; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size85KB，5 Pages; ManufacturerMicrochip; Websitehttps://www.microchip.com

Download Datasheet Parametric Compare View All

SY100EL91ZC Overview

3.3V TRIPLE LVPECL-to-ECL OR LVPECL-to-LVECL TRANSLATOR

SY100EL91ZC Parametric

Parameter Name	Attribute value
Maker	Microchip
Parts packaging code	SOIC
package instruction	SOIC-20
Contacts	20
Reach Compliance Code	compli
maximum delay	0.75 ns
Input properties	DIFFERENTIAL
Interface integrated circuit type	PECL TO ECL TRANSLATOR
JESD-30 code	R-PDSO-G20
length	12.83 mm
Number of digits	1
Number of functions	3
Number of terminals	20
Maximum operating temperature	70 °C
Minimum operating temperature
Output latch or register	NONE
Output polarity	COMPLEMENTARY
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP20,.4
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Maximum seat height	2.65 mm
Maximum slew rate	11 mA
Maximum supply voltage	5.25 V
Minimum supply voltage	4.75 V
Nominal supply voltage	5 V
surface mount	YES
Temperature level	COMMERCIAL
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
width	7.5 mm

Preview

Download Datasheet

View All

NOT RECOMMENDED FOR NEW DESIGNS

Micrel, Inc.

TRIPLE

PECL-TO-ECL TRANSLATOR

SY100EL91

FEATURES

620ps typical propagation delay

Fully differential design

Supports standard operation

Available in 20-pin SOIC package

DESCRIPTION

The SY100EL91 is a triple PECL-to-ECL translator. It

receives standard voltage PECL signals and translates

them to different ECL output signals.

A V

output is provided for interfacing with single

ended PECL signals at the input. If a single ended input

is to be used, the V

output should be connected to the

D input. The active signal would then drive the D input.

When used, the V

output should be bypassed to ground

via a 0.01µF capacitor. The V

output is designed to act

as the switching reference for the EL91 under single

ended input switching conditions. As a result this pin can

only source/sink up to 0.5mA of current.

To accomplish the level translation the EL91 requires

three power rails. The V

supply should be connected

to the positive supply, and the V

pin should be

connected to the negative power supply. The GND pins

as expected are connected to the system ground plane.

Both V

and V

should be bypassed to ground via

0.01µF capacitors.

Under open input conditions, the D input will be biased

at V

/2 and the D input will be pulled to GND. This

condition will force the Q output to a LOW, ensuring

stability.

PIN NAMES

PECL_V

PECL Inputs

ECL Outputs

PECL Reference Voltage Output

Function

M9999-031306

hbwhelp@micrel.com or (408) 955-1690

Rev.: E

Amendment: /0

Issue Date: March 2006

SY100EL91ZC Related Products

	SY100EL91ZC	SY100EL91L	SY100EL91ZCTR	SY100EL91ZI	SY100EL91ZGTR	SY100EL91ZITR	SY100EL91ZG-TR	SY100EL91ZC-TR	SY100EL91ZI-TR
Description	3.3V TRIPLE LVPECL-to-ECL OR LVPECL-to-LVECL TRANSLATOR	3.3V TRIPLE LVPECL-to-ECL OR LVPECL-to-LVECL TRANSLATOR	3.3V TRIPLE LVPECL-to-ECL OR LVPECL-to-LVECL TRANSLATOR	3.3V TRIPLE LVPECL-to-ECL OR LVPECL-to-LVECL TRANSLATOR	3.3V TRIPLE LVPECL-to-ECL OR LVPECL-to-LVECL TRANSLATOR	3.3V TRIPLE LVPECL-to-ECL OR LVPECL-to-LVECL TRANSLATOR	IC TRNSLTR UNIDIRECTIONAL 20SOIC	IC TRNSLTR UNIDIRECTIONAL 20SOIC	IC TRNSLTR UNIDIRECTIONAL 20SOIC
Maker	Microchip	-	Microchip	Microchip	Microchip	Microchip	-	-	-
Parts packaging code	SOIC	-	SOIC	SOIC	SOIC	SOIC	-	-	-
package instruction	SOIC-20	-	SOIC-20	SOIC-20	SOIC-20	SOIC-20	-	-	-
Contacts	20	-	20	20	20	20	-	-	-
Reach Compliance Code	compli	-	compli	compli	compli	compli	-	-	-
maximum delay	0.75 ns	-	0.75 ns	0.75 ns	0.75 ns	0.75 ns	-	-	-
Input properties	DIFFERENTIAL	-	DIFFERENTIAL	DIFFERENTIAL	DIFFERENTIAL	DIFFERENTIAL	-	-	-
Interface integrated circuit type	PECL TO ECL TRANSLATOR	-	PECL TO ECL TRANSLATOR	PECL TO ECL TRANSLATOR	PECL TO ECL TRANSLATOR	PECL TO ECL TRANSLATOR	-	-	-
JESD-30 code	R-PDSO-G20	-	R-PDSO-G20	R-PDSO-G20	R-PDSO-G20	R-PDSO-G20	-	-	-
length	12.83 mm	-	12.83 mm	12.83 mm	12.83 mm	12.83 mm	-	-	-
Number of digits	1	-	1	1	1	1	-	-	-
Number of functions	3	-	3	3	3	3	-	-	-
Number of terminals	20	-	20	20	20	20	-	-	-
Maximum operating temperature	70 °C	-	70 °C	85 °C	85 °C	85 °C	-	-	-
Output latch or register	NONE	-	NONE	NONE	NONE	NONE	-	-	-
Output polarity	COMPLEMENTARY	-	COMPLEMENTARY	COMPLEMENTARY	COMPLEMENTARY	COMPLEMENTARY	-	-	-
Package body material	PLASTIC/EPOXY	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	-	-	-
encapsulated code	SOP	-	SOP	SOP	SOP	SOP	-	-	-
Encapsulate equivalent code	SOP20,.4	-	SOP20,.4	SOP20,.4	SOP20,.4	SOP20,.4	-	-	-
Package shape	RECTANGULAR	-	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	-	-	-
Package form	SMALL OUTLINE	-	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	-	-	-
Maximum seat height	2.65 mm	-	2.65 mm	2.65 mm	2.65 mm	2.65 mm	-	-	-
Maximum slew rate	11 mA	-	11 mA	11 mA	11 mA	11 mA	-	-	-
Maximum supply voltage	5.25 V	-	5.25 V	5.25 V	5.25 V	5.25 V	-	-	-
Minimum supply voltage	4.75 V	-	4.75 V	4.75 V	4.75 V	4.75 V	-	-	-
Nominal supply voltage	5 V	-	5 V	5 V	5 V	5 V	-	-	-
surface mount	YES	-	YES	YES	YES	YES	-	-	-
Temperature level	COMMERCIAL	-	COMMERCIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	-	-	-
Terminal form	GULL WING	-	GULL WING	GULL WING	GULL WING	GULL WING	-	-	-
Terminal pitch	1.27 mm	-	1.27 mm	1.27 mm	1.27 mm	1.27 mm	-	-	-
Terminal location	DUAL	-	DUAL	DUAL	DUAL	DUAL	-	-	-
width	7.5 mm	-	7.5 mm	7.5 mm	7.5 mm	7.5 mm	-	-	-
