ONE PHASE POWER
DISTRIBUTION BLOCKS
Quick mounting and wiring
IP20 Finger Safe
DIN Rail or Panel Mount
Blocks fit with other DIN Rail
mountable modular devices
(height 95mm, depth 44.5mm)
• Accessories increase the
number of outputs with only
one input (applies
only
to 38041
and 38032)
• No caps to open or remove
• Material
Housing: Polyamide
Metal Body: Brass
Part Number:
White
Gray
Approvals
Current Rating
Voltage Rating
No. of Inputs
Wire Range
Torque
Screw Type
No. of Outputs
Wire Range
Torque
Wire Range
Torque
Screw Type
Optional
Marking Tag
*(for DB16 and DB35)
80A
600V AC
1
8-4 AWG
13.5lb.-in.
•
•
•
•
38049
38041
SCCR: 100kA
38049
(UL File E98082)
DB16
(UL File E220514)
SCCR: 100kA
38041
(UL File E98082)
DB35
(UL File E220514)
80A
690V AC
1
6-16mm
2
1.5Nm
115A
600V AC
1
8-2 AWG
31lb.-in.
125A
690V AC
1
10-35mm
2
3.5Nm
UL1059
Pozi Drive 2
6
6
(2x)8-4 AWG
(2x)6-16mm
2
13.5lb.-in.
1.5Nm
(4x)14-10 AWG
(4x)2.5-6mm
2
7.2lb.-in.
0.8Nm
Pozi Drive 2
MT2*
40lb.-in.
for DB35
Pozi Drive 2
6
14-6 AWG
17.5lb.-in.
6
2.5-16mm
2
2Nm
Pozi Drive 2
MT2*
Dimensions:
38041
Fork Type Busbar
38045
38041
Accessories: Fork Type Busbar
Part No:
38045
to jump 2 Blocks
38046
to jump 8 Blocks
can be cut
26
Altech Corp.
®
• t 908-806-9400 • f 908-806-9490 • www.altechcorp.com
38076
38032
38074
SCCR: 100kA
Part Number:
Approvals
UL File E98082
SCCR: 100kA
38032
SCCR: 100kA
38074
38076
UL File E98082
UL File E98082
Current Rating
Voltage Rating
No. of Inputs
Wire Range
Torque
Screw Type
No. of Outputs
Wire Range
Torque
Screw Type
115A
600V AC
1
8-2 AWG
53lb.-in.
Hex 4
10
14-4 AWG
26.5lb.-in.
Hex 3
125A
690V AC
1
10-35mm
2
6Nm
10
2.5-16mm
2
3Nm
160A
600V AC
1
8-2/0AWG
35.5lb.-in.
Hex 5
6
14-6 AWG
17.5lb.-in.
Hex 3
160A
690V AC
1
10-70mm
2
4Nm
6
2.5-16mm
2
2Nm
175A
600V AC
1
6-2/0AWG
53lb.-in.
Hex 5
10
14-4 AWG
26.5lb.-in.
Hex 3
175A
690V AC
1
16-70mm
2
6Nm
10
2.5-16mm
2
3Nm
Dimensions:
17.4 mm
(0.69 in)
71 mm
(2.80 in)
17.4 mm
(0.69 in)
71 mm
(2.80 in)
17.4 mm
(0.69 in)
17.4 mm
(0.69 in)
17.4 mm
(0.69 in)
17.4 mm
(0.69 in)
17.4 mm
(0.69 in)
17.4 mm
(0.69 in)
38032
38032
Copper Jumper Bar
3803221
Accessories: Copper Jumper Bar
(6x15 mm)
Part No:
3803221
for 2 Blocks
3803231
for 3 Blocks
3803241
for 4 Blocks
can be cut
Altech Corp.
®
• t 908-806-9400 • f 908-806-9490 • www.altechcorp.com
UL1059
27
ONE PHASE POWER
DISTRIBUTION BLOCKS
Quick mounting and wiring
IP20 Finger Safe
DIN Rail or Panel Mount
Blocks fit with other DIN Rail
mountable modular devices
(height 95mm, depth 44.5mm)
• Accessories increase the
number of outputs with only
one input.
• No caps to open or remove
• Material
Housing: Polyamide
Metal Body: Brass
•
•
•
•
38020
38019
SCCR: 100kA
Part Number:
Approvals
UL File E98082
SCCR: 100kA
38019
38020
UL File E98082
Current Rating
Voltage Rating
No. of Inputs
Wire Range
Torque
Screw Type
No. of Outputs
Wire Range
Torque
Wire Range
Torque
Wire Range
Torque
Screw Type
230A
600V AC
1
2-4/0AWG
170lb.-in.
Hex 6
250A
690V AC
1
35-120mm
2
19Nm
310A
600V AC
1
3/0-350kcmil
230lb.-in.
Hex 8
400A
690V AC
1
95-185mm
2
25Nm
UL1059
11
11
(2x) 14-2AWG
(2x) 2.5-35mm
2
31lb.-in.
3.5Nm
(5x) 14-6AWG
(5x) 2.5-16mm
2
17.5lb.-in.
2Nm
(4x) 14-8AWG
(4x) 2.5-10mm
2
17.5lb.-in.
2Nm
standard screwdriver
11
11
(2x) 14-2AWG
(2x) 2.5-35mm
2
31lb.-in.
3.5Nm
(5x) 14-6AWG
(5x) 2.5-16mm
2
17.5lb.-in.
2Nm
(4x) 14-8AWG
(4x) 2.5-10mm
2
17.5lb.-in.
2Nm
standard screwdriver
Dimensions:
28
Altech Corp.
®
• t 908-806-9400 • f 908-806-9490 • www.altechcorp.com
