Bussmann
®
Industrial HRC Fuse
13.8 x 58.7mm, BS88:
Offset Blade Tags
Part 6,
NSD
IEC 269-1
Time-Current Characteristic Curve
(Full Size Curves Available)
1,000
16
20
25
32
40
4
6
10
2
CURRENT
RATING
20M25
20M32
20M36
32M36
32M40
32M50
32M63
100
Dimensional Data:
D
TIME IN SECONDS
CATALOG SYMBOL: NSD
INDUSTRIAL HRC FUSE
OFFSET BLADE TAGS
PACKAGE QUANTITY: 20
80kA INTERRUPTING RATING
MOUNTS IN CAMLOC OR SAFELOC SERIES HOLDERS
10
1
N
A
F
B
.1
E
Electrical Characteristics
Catalog
Number
NSD2
NSD4
NSD6
NSD10
NSD16
NSD20
NSD25
NSD32
NSD20M25
NSD20M32
NSD20M36
NSD32M36
NSD32M40
NSD32M50
NSD32M63
Ampere
Rating
2
4
6
10
16
20
25
32
20M25
20M32
20M36
32M36
32M40
32M50
32M63
I
2
T (Amp
2
Seconds)
Pre-
Total At
Arcing
415V
1.3
4.6
8
27
29
100
120
400
120
470
260
1070
560
2300
710
3000
570
2350
770
3000
1150
5000
1150
5000
1500
6000
2700
8700
5000
13,550
Total At
550V
5
30
115
490
730
1700
3550
5000
—
—
—
—
—
—
—
Nom
Watts
Loss
0.9
1.4
1.8
2.1
1.8
1.8
2
2.9
1.2
0.95
0.88
2.4
1.9
1.4
1.0
Rated
Voltage
A
B
CURRENT IN AMPERES
Dimensions (Inches/mm)
D
E
F
N
550AC
34.6
.54
13.8
58.5
12.7
.03
.8
.14
3.5
415AC
34.6
.69
17.5
The only controlled copy of this BIF document is the electronic read-only version located on the Bussmann Network Drive. All other copies of this BIF document are by definition uncontrolled. This bulletin is intended to
clearly present comprehensive product data and provide technical information that will help the end user with design applications. Bussmann reserves the right, without notice, to change design or construction of any
products and to discontinue or limit distribution of any products. Bussmann also reserves the right to change or update, without notice, any technical information contained in this bulletin. Once a product has been select-
ed, it should be tested by the user in all possible applications.
12-28-98
SB98107
Rev. A
Form No. NSD
Page 1 of 1
BIF Doc #4100
1,000
100
10
1
.01
