1 Watt
DC-DC-Converter
Family IZR1
Single, double & dual outputs
Input to output high isolated
I/O Electric strength test voltage 7 kVDC, 5 kVrms
Dual outputs: Output to output isolated
•
•
•
•
•
•
•
•
•
Input voltage tolerance • 10% (• 5%)
I/O Clearance and creepage distances 5 mm
High efficiency up to 65%
High reliability
Linear regulated output voltages
Continuous no-load and short-circuit proof
Extended ambient temperature range -40…+85ƒC
Made in Switzerland, accordingly ISO 9001:2000
2 years warranty
Standard Types
1
Input voltage
VDC
Single output
xx IZR1-05-T
4.75…5.25
xx IZR1-12-T
(nominal 5)
xx IZR1-15-T
Double output
10.8…13.2
xx IZR1-0505-T
(nominal 12)
xx IZR1-1212-T
xx IZR1-1515-T
13.5...16.5
Dual output
(nominal 15)
xx IZR1-05-05-T
xx IZR1-05-12-T
21.6…26.4
xx IZR1-05-15-T
(nominal 24)
xx IZR1-12-12-T
xx IZR1-15-15-T
1
Electromagnetic emission EN 55022 < B
Conducted and radiated emissions
5 IZR
12 IZR
15 IZR
20
35
24 IZR
12
40
mA typ.
mVpp typ.
Output 1
VDC
mA
5
12
15
• 5
• 12
• 15
5
5
5
12
15
200
80
66
• 50
• 40
• 33
100
100
100
40
33
Output 2
VDC
mA
-
-
-
-
-
-
5
12
15
12
15
-
-
-
-
-
-
100
40
33
40
33
No load input current
55
25
Output voltage noise
20
30
(20 MHz BW)
Switching frequency
Output voltage accuracy
Static line regulation
Static load regulation FL to NL
Efficiency
I/O Electric strength test voltage
O/O Electric strength test voltage
I/O Clearance and creepage distances
Coupling capacitance
Ambient temperature range
Case temperature range
Storage temperature range
Case material
MTBF, GB @ 40‚C case
(MIL-HDBK-217F, Notice 2)
260 kHz typ.
• 4%; 5 VDC outputs • 3% max.
• 0.2% typ.
• 0.3% typ.
60% to 65% typ.
7.0 kVDC, 5.0 kVrms (50 Hz, 1 min.)
1.5 kVDC, 1.0 kVrms (50 Hz, 1 min.)
5 mm
5 pF
-T: -25…+71‚C; -S: -40…+85‚C
-T: -25…+91‚C; -S: -40…+105‚C
-T: -55…+105‚C; -S: -55…+105‚C
Non-conductive plastic, UL94 V-0 rated
5.700.000 hours
To complete type number replace "xx" by the required nominal input
voltage, e.g. 5 IZR1-1515-T.
Extended temperature range -S is available for all types.
Replace -T by -S on type number, e.g. 24 IZR1-05-12-S.
Modifications and customs are available upon request.
Max. admissible capacitive load
100F
Dimensions in mm (inches)
Pin Configuration
Single output
Double output
+Vi
+Vi
+Vi
+Vi
No Pin
No Pin
No Pin
Go
No Pin
Go
-Go
No Pin
+Vo
-Vo
No Pin
+Vo
No Pin
No Pin
-Gi
-Gi
-Gi
-Gi
Pin
1
2
8
10
11
12
13
15
17
23
24
Dual output
+Vi
+Vi
-Go1
No Pin
No Pin
+Vo1
+Vo2
No Pin
-Go2
-Gi
-Gi
Specifications subject to change without notice
20.07.2004
More power with IBEK
€
!
Page 4
