SURFACE MOUNT AMPLIFIERS
AFSM SERIES
FEATURES
• Low noise at competitive prices in a
surface mount amplifier
• Reduce assembly costs at the
system level
• Substantial size reduction at the system
or board level
• High reliability due to:
Hermetic sealing
High input to output isolation
Mechanically rugged internal assembly
GAIN (dB)
28
26
24
• Both high and low frequency designs
available (0.1–20 GHz)
TYPICAL DATA
AFSM2-00100200-10-8P
GAIN (dB)
18
16
14
AFSM2-00050100-18-20P
CONNECTORIZED OPTION
NOISE FIGURE (dB)
NOISE FIGURE (dB)
2
1
0
3
2
1
0
0.05
0.24
0.43
0.62
FREQUENCY (GHz)
0.81
1
0.10
0.48
0.86
1.24
FREQUENCY (GHz)
1.62
2
OUTPUT POWER
@ 1 dB G.C.P. (dBm)
12
11
OUTPUT POWER
@ 1 dB G.C.P. (dBm)
13
23
22
21
INPUT
RETURN LOSS (dB)
RETURN LOSS (dB)
OUTPUT
-10
-20
-30
INPUT
-10
-20
-30
-40
-50
OUTPUT
-40
-50
2
0.10
0.48
0.86
1.24
FREQUENCY (GHz)
1.62
0.05
0.24
0.43
0.62
0.81
1
FREQUENCY (GHz)
MODEL
NUMBER
AFSM2-00100200-12-8P
AFSM2-00100300-12-8P
AFSM2-00100400-18-8P
AFSM2-00100600-18-8P
AFSM2-00500100-08-8P
AFSM2-01000200-08-8P
AFSM2-02000400-10-8P
AFSM2-04000800-20-8P
AFSM2-08001200-15-8P
AFSM2-02000600-12-8P
AFSM3-12001800-25-8P
AFSM3-02001800-40-8P
FREQUENCY
RANGE
(GHz)
0.1–2
0.1–3
0.1–4
0.1–6
0.5–1
1–2
2–4
4–8
8–12
2–6
12–18
2–18
GAIN
(dB, Min.)
22
20
20
18
25
25
21
20
20
20
20
18
16
12
13
13
12
GAIN
VARIATION
(±dB, Max.)
1
1
1
1.5
1
1
1
1
1
1
1
2.75
2.75
1
1
1
2.75
NOISE
FIGURE
(dB, Max.)
1.2
1.2
1.8
1.8
0.8
0.8
1
2
1.5
1.2
2.5
4
5
1.6
1.8*
1.6
7
VSWR
(Max.)
IN/OUT
2:1
2:1
2:1
2:1
2:1
2:1
2:1
2:1
2:1
2:1
2:1
2.5:1
2.5:1
2:1
2.5:1/2:1
2:1
2.5:1
OUTPUT POWER
@ 1 dB COMP.
(dBm, Min.)
8
8
8
8
8
8
8
8
8
8
8
8
8
16
20
20
19
NOM. DC
POWER
(+15 V, mA)
80
80
80
80
80
80
80
100
100
80
125
100
C-24C/Surface Mount 022707
AFSM3-00102000-50-8P 0.1–20
AFSM1-00100200-16-16P 0.1–2
AFSM1-00050100-18-20P 0.05–1
AFSM1-01000200-16-20P
1–2
AFSM2-02002000-70-19P 2–20
100
80
150
150
200
* Noise figure increases from .05–0.1 GHz.
NOTES: For connectorized option, add “-C” to part number.
Other frequency bands also available.
See page 63 for outline.
