C-01
MT SERIES
(Ex-090 connector)
Features
The MT connector series has a 4 mm terminal pitch between
terminal poles.
This series consists of a 090 type (090, 250, and 305 types for the
hybrid model) classified according to terminal size, supporting use
in a variety of control circuits and low power circuits.
●These
connectors can be directly secured to a support on the car
body.
MT SERIES
INTERLOCKING TYPE
C-02
090(2.3
mm
)／STANDARD
Connection is disengaged by releasing the locking arm provided in the housing.
Structure
Connector M
Housing M
Connector F
Housing F
Terminal M
Terminal F
Terminal
(UNIT: mm)
Cable size (mm
2
)
Cable overall diameter (mm)
Material
Surface treatment
Reel (piece)
Thickness (mm)
0.2∼0.5
1.5∼2.0
Brass
Gold-plated
5000
0.3
Cable size (mm
2
)
Cable overall diameter (mm)
0.2∼0.5
1.5∼2.0
Brass
Gold-plated
5000
0.25
7
2.5
17.2
3
2
26.7
2.3
Material
Surface treatment
Reel (piece)
Thickness (mm)
M(8230-4419)
Cable size (mm
2
)
Cable overall diameter (mm)
Material
Surface treatment
Reel (piece)
Thickness (mm)
F(8240-4849)
Cable size (mm
2
)
Cable overall diameter (mm)
0.2∼0.5
1.5∼2.0
Brass
Tin-plated
5000
0.3
0.2∼0.5
1.5∼2.0
Brass
Tin-plated
5000
0.25
7
2.5
17.2
3
2
26.7
2.3
Material
Surface treatment
Reel (piece)
Thickness (mm)
M(8230-4272)
090
Cable size (mm
2
)
Cable overall diameter (mm)
Material
Surface treatment
Reel (piece)
Thickness (mm)
F(8240-4412)
Cable size (mm
2
)
Cable overall diameter (mm)
0.5∼1.25
1.6∼2.9
Brass
Tin-plated
5000
0.3
0.5∼1.25
1.6∼2.5
Brass
Tin-plated
5000
0.25
7
2.5
17.2
3
2
26.7
2.3
Material
Surface treatment
Reel (piece)
Thickness (mm)
M(8230-4282)
Cable size (mm
2
)
Cable overall diameter (mm)
Material
Surface treatment
Reel (piece)
Thickness (mm)
F(8240-4422)
Cable size (mm
2
)
Cable overall diameter (mm)
2.0（Cables to be used shall be AVSS.）
2.6
Brass
Tin-plated
5000
0.3
2.0（Cables to be used shall be AVSS.）
2.6
Heat-resistant copper alloy
Tin-plated
5000
0.25
2
26.7
2.3
Material
Surface treatment
Reel (piece)
Thickness (mm)
7
2.5
17.2
3
M(8230-4392)
F(8240-4652)
MT SERIES
SEMI-LOCKING TYPE
090(2.3
mm
)／STANDARD
Simplified locking mechanism allows quick disconnection without release operation.
C-05
Structure
Connector M
Housing M
Connector F
Housing F
Terminal M
Terminal F
Housing
(UNIT: mm)
Material／66
Nylon
Color／Natural
Ref: Terminal part No.
C-02
7.6
33.3
8.3
M(6242-1011)
1way
Ref: Terminal part No.
Note
C-02
With clamp for 7mm dia.
7.6
33.3
8.3
Plate thickness range for clamp：
t＝0.7∼1.6
M(6243-1011)
Ref: Terminal part No.
Note
C-02
With clamp for 7mm dia.
10.2
33.5
12.4
Plate thickness range for clamp：
t=0.7∼1.6
M(6243-1021)
2way
Ref: Terminal part No.
Note
C-02
With clamp for 7mm dia.
10.2
33.5
12.4
Plate thickness range for clamp：
t＝1.6∼3.0
M(6240-1016)
