Coaxial
Frequency Mixer
Level 7 (LO Power +7 dBm) 2000 to 4200 MHz
Maximum Ratings
Operating Temperature
Storage Temperature
RF Power
IF Current
-55°C to 100°C
-55°C to 100°C
50mW
40mA
ZFM-4212
Features
• low conversion loss, 5.44 dB typ.
• wideband, 100 to 2000 MHz
• rugged shielded case
SMA version shown
CASE STYLE: K18
Connectors Model
SMA
ZFM-4212
BRACKET (OPTION “B”)
Price
Qty.
$54.95 ea. (1-9)
$2.50
(1+)
Applications
• VHF/UHF
• MMDS
• ISM
• instrumentation
Coaxial Connections
LO
RF
IF
1
2
3
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site for
RoHS Compliance methodologies and qualifications.
Electrical Specifications
Outline Drawing
FREQUENCY
(MHz)
LO/RF
f
L
-f
U
2000-4200
DC-1300
1 dB COMP.: +1 dBm typ.
IF
—
X
CONVERSION LOSS
(dB)
Mid-Band
σ
Total
Range
Max. Max.
—
8.5
LO-RF ISOLATION
(dB)
LO-IF ISOLATION
(dB)
Typ.
25
Min.
17
Typ.
18
Min.
10
5.44 0.088
Typical Performance Data
Frequency
(MHz)
Conversion
Loss
(dB)
LO
1940.00
1983.75
2127.50
2271.25
2415.00
2558.75
2702.50
2846.24
2940.00
2990.00
3133.75
3277.50
3421.25
3565.00
3708.75
3852.50
3940.00
3996.25
4006.00
4059.00
Isolation
L-R
(dB)
LO
+7dBm
25.3
25.3
23.6
24.4
26.5
27.7
28.3
28.1
28.7
28.1
27.2
26.7
27.4
27.4
27.1
28.6
29.9
30.5
30.6
30.6
Isolation
L-I
(dB)
LO
+7dBm
13.6
13.5
13.9
14.0
14.6
15.9
16.2
17.2
18.2
18.5
18.7
19.2
17.9
16.5
16.0
15.6
15.5
15.4
15.3
15.2
VSWR
RF Port
(:1)
LO
+7dBm
1.99
1.99
1.99
1.91
2.01
2.35
2.43
2.37
2.40
2.43
2.27
2.10
2.25
2.12
2.30
2.30
2.18
1.96
1.91
1.73
VSWR
LO Port
(:1)
LO
+7dBm
6.73
6.26
5.85
6.05
6.49
6.49
6.49
6.26
6.73
7.60
8.72
8.31
8.72
5.49
4.32
4.53
4.42
4.32
4.32
4.12
RF
2000.00
2043.75
2187.50
2331.25
2475.00
LO
+7dBm
5.05
5.10
5.57
5.78
5.92
5.81
5.64
5.68
5.85
5.85
5.82
5.56
5.52
5.73
6.35
6.33
6.09
5.82
5.85
5.84
Outline Dimensions (
inch
)
mm
A
1.25
31.75
J
--
--
B
1.25
31.75
K
--
--
C
.75
19.05
L
.125
3.18
D
.63
16.00
M
1.688
42.88
E
.38
9.65
N
2.18
55.37
F
1.00
25.40
P
.75
19.05
G
.125
3.18
H
1.000
25.40
2618.75
2762.50
2906.24
3000.00
3050.00
3193.75
3337.50
3481.25
3625.00
3768.75
3912.50
4000.00
4056.25
4066.00
4119.00
Q
wt
.07 grams
1.78
70.0
Electrical Schematic
Mini-Circuits
ISO 9001 ISO 14001
CERTIFIED
RF/IF MICROWAVE COMPONENTS
®
minicircuits.com
REV. OR
M93678
ZFM-4200
DJ/TD/CP
061211
Page 1 of 2
EW
ALL N
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
The Design Engineers Search Engine
Provides ACTUAL Data Instantly From MINI-CIRCUITS At:
www.minicircuits.com
Performance Charts
ZFM-4212
CONVERSION LOSS
7.0
CONVERSION LOSS (dB)
6.5
6.0
5.5
5.0
4.5
4.0
2000
2550
3100
3650
FREQUENCY (MHz)
4200
at IF Freq of 60 MHz
ZFM-4212
ZFM-4212
L-R ISOLATION
40
L-R ISOLATION (dB)
35
30
25
20
15
2000
2550
3100
3650
FREQUENCY (MHz)
ZFM-4212
RF VSWR
4200
ZFM-4212
L-I ISOLATION
25
L-I ISOLATION (dB)
20
RF VSWR
2550
3100
3650
FREQUENCY (MHz)
ZFM-4212
LO VSWR
11.0
9.0
LO VSWR
7.0
5.0
3.0
1.0
2000
IF VSWR
2.0
1.8
1.6
1.4
1.2
1.0
3.0
2.5
2.0
1.5
1.0
2000
15
10
5
2000
4200
2550
3100
3650
FREQUENCY (MHz)
ZFM-4212
IF VSWR
4200
2550
3100
3650
FREQUENCY (MHz)
4200
0
200
400
600
800
1000
FREQUENCY (MHz)
1200
1400
Mini-Circuits
ISO 9001 ISO 14001
CERTIFIED
RF/IF MICROWAVE COMPONENTS
®
minicircuits.com
EW
ALL N
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
The Design Engineers Search Engine
Provides ACTUAL Data Instantly From MINI-CIRCUITS At:
www.minicircuits.com
Page 2 of 2
